Sentry
Congratulations on the purchase of your Bushnell
Sentry
®
Spotting Scope, a versatile high-performance
spotting scope offering a wide range of terrestrial
viewing. The Sentry
®
coated prisms and lenses for increased light
transmission and image brightness, variable power
eyepieces, non-reflective armoring and built-in peep
sight (straight-thru models only) for ultra fast precision
viewing.
Complete with non-reflective tripod. A l l
Bushnell
®
Sentry
®
models come with a convenient
hard storage case (except for the 45-degree model).
MOUNTING
Remove the spotting scope and tripod from the hard
storage carrying case. Screw the tripod attachment
screw into the tripod mount hole located on the base
of the spotting scope. Spread the tripod legs and set
on a solid surface.
FOCUSING
The spotting scope is focused with the focus ring. For
models with a 50mm objective, the eyepiece will move
"in" and "out", depending on the direction the ring is
turned. When the tube is all the way "out", the spotting
scope is at the closest focus position.
MAGNIFICATION
To change magnification, grasp and rotate the knurled
portion of the eyepiece. It may be necessary to re-
focus when the magnification is changed.
USING THE TRIPOD
To pan side to side or up and down, unloosen the
tripod control handle by rotating it counterclockwise.
To lock into a desired position, rotate the tripod control
handle clockwise.
SPOTTING SCOPE USE
Remove the dust caps. Point the spotting scope as
desired (as described under FOCUSING).
CAUTION: DO NOT LOOK AT THE SUN
THROUGH THIS SPOTTING SCOPE AS SEVERE
DAMAGE TO YOUR EYES MAY RESULT!
®
Spotting Scope Instructions
Spotting Scope features fully
www.bushnell.com
®
CARE
The lenses of your spotting scope are 100% hard
magnesium
fluoride
transmission. As with any optical coated, special care
must be taken in cleaning the lenses. Moisten the
surface of the lens slightly and wipe dry using a circular
motion starting at the center of the lens. Wipe or brush
o ff any dirt or dust on the outside of the spotting scope
and tripod.
CAUTION
Never disassemble your spotting scope or tripod.
Special tools and equipment are required for service
and irreparable damage can result from untrained
attempted service. Unauthorized service may also void
the warranty.
LIFETIME LIMITED WARRANTY
Your Bushnell
®
spotting scope is warranted to be free of defects in materials
and workmanship for the lifetime of the original owner. The Lifetime Limited
Warranty is an expression of our confidence in the materials and mechanical
workmanship of our products and is your assurance of a lifetime of
dependable service. In the event of a defect under this warranty, we will, at
our option, repair or replace the product, provided that you return the
product postage prepaid. This warranty does not cover damages caused by
misuse or improper handling, installation or maintenance of the product.
Any return made under this warranty
must be accompanied by the items listed below:
1)A check in the amount of $10.00 to cover the cost of handling
2)Name and address for product return
3)An explanation of the defect
4)Product should be well packed in a sturdy outside shipping carton to
prevent damage in transit and return postage prepaid to the
address listed below:
IN U.S.A. Send To:
Bushnell Performance Optics
8500 Marshall Drive
Lenexa, Kansas 66214
For products purchased outside the United States and Canada please contact
your local dealer for applicable warranty information. This warranty gives you
specific legal rights. You may have other rights which vary from country
to country.
©2001 Bushnell Performance Optics
Lit # : 91-0094/03-01
coated
for
highest
IN CANADA Send To:
Bushnell Performance Optics
25A East Pearce Street, Unit 1
Richmond Hill, Ontario L4B 2M9
