Sharp CD-G10000 Service Manual

Mini componentsystem speaker system
Hide thumbs Also See for CD-G10000:
Table of Contents

Advertisement

Quick Links

CHAPTER 1. GENERAL DESCRIPTION
[1]
Specifications ......................................... . ....... 1-1
[2]
Names of parts....................................... . ....... 1-2
[1]
Mechanism section ................................ . ....... 2-1
[2]
Tuner section ......................................... . ....... 2-1
[3]
TEST MODE .......................................... . ....... 2-2
[4]
CD SECTION ......................................... . ....... 2-4
[5]
CD section.............................................. . ....... 2-4
[6]
Error Message Display Contents ........... . ....... 2-4
[7]
CD Changer mechanism section ........... . ....... 2-5
CHAPTER 3. MECHANISM BLOCKS
[1]
Caution on disassembly ......................... . ....... 3-1
[2]
CHAPTER 4. DIAGRAMS
[1]
Block diagrams....................................... . ....... 4-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for
maintaining the safety and performance of the set.
SERVICE MANUAL
MODEL
CP-G10000S Speaker System consisting of CP-G10000S (front
speaker system) and CP-SW10000S (active subwoofer).
CONTENTS
SHARP CORPORATION
MINI COMPONENTSYSTEM
CD-G10000
MODEL
CD-G10000 Mini Component System consisting of CD-G10000
(main unit) and GBOXSA090AWM1 (rear speaker system).
SPEAKER SYSTEM
CP-G10000S
In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
[1]
Notes on schematic diagram .........................5-1
[2]
Types of transistor and LED ..........................5-1
[3]
Waveforms of CD circuit ................................5-2
[4]
Voltage...........................................................5-3
CHAPTER 6. CIRCUIT SCHEMATICS AND PARTS
LAYOUT
[1]
Schematic diagram........................................6-1
[2]
Wiring side of PWB......................................6-13
CHAPTER 7. FLOWCHART
[1]
Troubleshooting .............................................7-1
[1]
Function table of IC .......................................8-1
[2]
FL Display....................................................8-10
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CD-G10000/CP-G10000S
No. S1506CDG10000

Advertisement

Table of Contents
loading

Related Manuals for Sharp CD-G10000

Summary of Contents for Sharp CD-G10000

  • Page 1: Table Of Contents

    CD-G10000/CP-G10000S SERVICE MANUAL No. S1506CDG10000 MINI COMPONENTSYSTEM CD-G10000 MODEL CD-G10000 Mini Component System consisting of CD-G10000 (main unit) and GBOXSA090AWM1 (rear speaker system). SPEAKER SYSTEM CP-G10000S MODEL CP-G10000S Speaker System consisting of CP-G10000S (front speaker system) and CP-SW10000S (active subwoofer).
  • Page 2 CD-G10000/CP-G10000S IMPORTANT SERVICE NOTES BEFORE RETURNING THE AUDIO PRODUCT BEFORE RETURNING THE AUDIO PRODUCT (Fire & Shock Hazard) Before returning the audio product to the user, perform the following safety checks. 1. Inspect all lead dress to make certain that leads are not pinched or...

  • Page 3: Specifications

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 1. GENERAL DESCRIPTION [1] Specifications FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER TO THE OPERATION MANUAL. CD-G10000 CP-G10000S General Type 2-way type speaker system 2" (5 cm) tweeter 1...

  • Page 4: Names Of Parts

    CD-G10000/CP-G10000S [2] Names of parts CD-G10000 Front panel 1. Disc Trays 2. Timer Indicator 3. Power On/Stand-by Button 4. Disc Track Up or Fast Forward, Tape 2 Fast Forward, Tuner Preset Up, Time Up Button 5. Clock/Timer Button 6. Tuning Up Button 7.
  • Page 5 CD-G10000/CP-G10000S CD-G10000 Remote control 1. Remote Control Transmitter 2. Disc Number Select Buttons 3. Clock/Timer Button 4. Character Input/Disc Direct Search Buttons 5. MP3 Disc Navigation Mode Select Button 6. Enter Button 7. Memory/Set Button 8. Tape 2 Record Pause Button 9.

  • Page 6: Chapter 2. Adjustments

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 2. ADJUSTMENTS • FM RF Signal generator: 1 kHz, 40 kHz dev., FM modulated [1] Mechanism section Test Frequency Frequency Setting/ Instrument Stage Display Adjusting Connection • Driving Force Check Point FM Band —...

  • Page 7: Test Mode

    CD-G10000/CP-G10000S [3] TEST MODE • Setting the test mode During stand-by mode, press ON/STAND-BY button while pressing down the button and X-BASS/DEMO button. then, press the CD button to enter the test mode. IL isn’t done T E S T OPEN/CLOSE operation is using manual.
  • Page 8 CD-G10000/CP-G10000S <<MEMORY>> key input. Laser ON. <<MEMORY>> key input. Tracking OFF play at that specific point. <<MEMORY>> key input. Tracking ON play from that specific point. <<MEMORY>> key input. Adjustment result automatically will display as below for each 2 sec: a) “FOF_XXXX”...

  • Page 9: Cd Section

    CD-G10000/CP-G10000S [4] CD SECTION [5] CD section • Adjustment CD Error code description Since this CD system incorporates the following automatic adjust- Error Explanation ment functions, readjustment is not needed when replacing the When Pickup set inner position, inner switch cannot detect pickup.

  • Page 10: Cd Changer Mechanism Section

    CD-G10000/CP-G10000S [7] CD Changer mechanism section • A number in the drawing sheet is the number of the parts guide (CHANGER MECHANISM PARTS). HALF GEAR MUST ARRANGE AS SHOWN 2 – 5...
  • Page 11 CD-G10000/CP-G10000S APPLY SANKOL BEFORE FIX FIX ITEM 1 ACCORDING TO THE SHOWN PICTURE ABOVE ROTATE MODE BIG GEAR UNTIL REACH AS SHOWN IN PICTURE 2 – 6...
  • Page 12 CD-G10000/CP-G10000S APPLY GREASE PULL THE LEVER UNITIL REACH THE ARROW MARK 2 – 7...
  • Page 13 CD-G10000/CP-G10000S FIGURE 2 FIGURE 1 APPLY GREASE SLOT CLAMP SW ARM INSIDE BASE SLOT 2 – 8...
  • Page 14 CD-G10000/CP-G10000S APPLY GREASE AT BOTTOM SIDE OF GEAR FOLLOW MARKING NO NEED APPLY GREASE AT BOTTOM SIDE APPLY GREASE AT TOP SIDE OF GEAR FOLLOW MARKING OTHER THAN FIGURE 1 DIRECTION ALL N.G BLACK MARK FIGURE 1 2 – 9...
  • Page 15 CD-G10000/CP-G10000S APPLY GREASE AT HALF GEAR AREA ROTATE CLOCKWISE UNTIL REACH HERE (MAXIMUM) 2 – 10...
  • Page 16 CD-G10000/CP-G10000S CHANGE COLOR TO BLACK 2 – 11...
  • Page 17 CD-G10000/CP-G10000S TRAY BIG GEAR MUST FREE FROM GREASE THE SHOWN AREA CHANGE COLOR TO BLACK O . K GREASE APPLICATION LENGTH GREASE APPLICATION PORTION N . G TRAY BIG GEAR CHANGE COLOR TO BLACK SHOWN HOLE MUST FACING ARROW DIRECTION...
  • Page 18 CD-G10000/CP-G10000S APPLY GREASE AT BOTTOM SIDE ONLY TR-RE JOINT GEAR C APPLY GREASE ONLY AT TOP SIDE GEAR MUST FIX ACCORDING TO THE HOLE'S 2 – 13...
  • Page 19 CD-G10000/CP-G10000S 2 – 14...
  • Page 20 CD-G10000/CP-G10000S APPLY GREASE WHEN FIXING ITEM 2 MUST FOLLOW AS SHOWN 2 – 15...
  • Page 21 CD-G10000/CP-G10000S FIGURE 1 FIGURE 2 APPLY GREASE APPLY GREASE SC141 FIGURE 3 2 – 16...
  • Page 22 CD-G10000/CP-G10000S ITEM 2 , 3 MUST APPLY GREASE ON TOP SIDE GEAR ONLY GEAR 112 GEAR 112 O . K N . G TOP VIEW AFTER FIX REVERSE N.G ASSY 2 – 17...
  • Page 23 CD-G10000/CP-G10000S APPLY GREASE BEFORE FIX MOVE 112 UNTIL TOUCH THE WALL DURING GEAR A ROTATE MUST PRESS SHOWN AREA AND LEVER B WILL MOVE ARROW DIRECTION THEN FIX PART 108 SCREW TORQUE +0.5 kgf-cm 803 x6 APPLY GREASE CONFIRM WHETHER...
  • Page 24 CD-G10000/CP-G10000S APPLY GREASE BEHIND THE LEVER NEED TO APPLY GREASE PULL IT THEN LEVER WILL MOVE IN 2 – 19...
  • Page 25 CD-G10000/CP-G10000S APPLY GREASE APPLY GREASE BEFORE FIX APPLY GREASE AT BOSS SPRING MUST ARRANGE UNDER THE HOOK O.K LR JOINT LEV BOARD R LR JOINT LEV BOARD R 2 – 20...
  • Page 26 CD-G10000/CP-G10000S ASSY REVERSELY N.G APPLY GREASE BIG SLOT MUST FACING OUT WHEN FIX & AFTER FIX TO BASE CHASSIS AFTER ASSY CONFIRM THE FREE DROP GEAR POSITION DURING FIXING 2 – 21...
  • Page 27 CD-G10000/CP-G10000S ASSY REVERSELY N.G APPLY GREASE BIG SLOT MUST FACING OUT WHEN FIX & AFTER FIX TO BASE CHASSIS AFTER ASSY CONFIRM THE FREE DROP GEAR POSITION DURING FIXING CONFIRM BOTH GEAR SIT PROPELY & LOCKED 2 – 22...
  • Page 28 CD-G10000/CP-G10000S AFTER FIX OUTER UP/DOWN LEVER HOLD SHOWN PORTION AND MOVE UP/DOWN THEN CONFIRM LEVER GO INSIDE THE HOLE OR NOT IF GO INSIDE HOLE IS O.K BIGGER SLOT FACING OUT IF NO GO INSIDE HOLE IS N.G BIGGER SLOT FACING OUT...
  • Page 29 CD-G10000/CP-G10000S BIG SLOT FACING OUT 2 – 24...
  • Page 30 CD-G10000/CP-G10000S PUSH THE LEVER ACCORDING TO ARROW DIRECTION THEN FIX WHEN FIX MAIN BASE ASSY FOLLOW ACCORDING TO O.K PICTURE MAKE SURE MECHA HOLDER SHAFT FIX PROPELY TO LEVER 2 – 25...
  • Page 31 CD-G10000/CP-G10000S APPLY SANKOL APPLY SANKOL ON TOP APPLY SANKOL INSIDE THE SLOT & OTHER SHOWN PORTION COSMO GUIDE TRAY HAVE MARKING AS SHOWN FIX TRAY NO 1 FIRST THAN FOLLOW OTHER APPLY SANKOL AT TRAY SLIDING PORTION 2 – 26...
  • Page 32 CD-G10000/CP-G10000S GEAR UP/DOWN BOARD APPLY GREASE AT INNER & OUTER GEAR SLIDING PORTION WHEN FIX GEAR UP/ DOWN BOARD THE TWO LEVER MUST AT PARALLEL LINE & POSITION AT TOP MAX SIDE AFTER ASSY GEAR UP/DOWN BOARD 2 – 27...
  • Page 33 CD-G10000/CP-G10000S SCREW TORQUE +0.5 kgf-cm 2 – 28...
  • Page 34 CD-G10000/CP-G10000S AFTER ASSY TOP PLATE FIX THE FFC FFC4 AFTER PUSH MAKE SURE SNAP PROPELY PRESS IN BACK PORTION AFTER FIX PUSH FOLLOW ARROW DIRECTION SLOT IN BEFORE LOCK AFTER LOCK BEFORE LOCK MUST CONFIRM AFTER LOCK BEFORE LOCK AFTER LOCK MUST CONFIRM 2 –...
  • Page 35 CD-G10000/CP-G10000S CAUTION 1. MAKE SURE NO PWB CHIP INSIDE SET .( BEFORE FIX MAKE SURE PWB NO DUST , GREASE & ETC ) 2 – 30...
  • Page 36 CD-G10000/CP-G10000S THE TWO SLOT MUST FREE FROM GREASE ASSEMBLY SEQUENCE APPLY GREASE BELOW THE MARKING FOR 1. APPLY GREASE TO MAIN BASE BOTH PORTION GREASE APPLICATION AREA ALL BOSS APPLY GREASE APPLY GREASE AT 3 HALF MOON APPLY GREASE APPLY GREASE...
  • Page 37 CD-G10000/CP-G10000S REFERENCE ONLY MOTOR GEAR HEIGHT FROM MAIN BASE 12.2 MOTOR SCREWING HOLE SCREW TORQUE + 0.5 MUST HAVE GAP M1,2 AFTER SCREW MOTOR,CONFIRM THE ARRANGEMENT AS IN FIGURE 2 FIGURE 2 APPLY GREASE 2 – 32...
  • Page 38 CD-G10000/CP-G10000S 3.1 + 0.1 SHAFT X 3 DIM AFTER INSERTION APPLY SANKOL MUST CONFIRM EVERYDAY SANKOL APPLICATION AREA 109-2 APPLY GREASE AT THE SLIDING PORTION APPLY GREASE UP / DOWN HOLDER CHANGE TO NATURE COLOR 2 – 33...
  • Page 39 CD-G10000/CP-G10000S BEFORE MELT IT AFTER MELT IT ( MUST FLAT ) WHEN FITTING STABILIZER PLATE TO STABILIZER, ROTATE STABILIZER ANTI CLOCKWISE BY JIG AFTER ASSY TO HOLDER STABILIZER NEED CLEAN ( BY HAND CANNOT X ) WITH ALCOHOL DISC TOUCHING SURFACE...
  • Page 40 CD-G10000/CP-G10000S APPLY GREASE MUST MAKE SURE SNAP PROPELY BOTH SIDE ALL SURFACE MUST TOUCH O . K 2 – 35...
  • Page 41 CD-G10000/CP-G10000S NO GAP HAVE GAP 2 – 36...

  • Page 42: Caution On Disassembly

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 3. MECHANISM BLOCKS [1] Caution on disassembly Caution on Disassembly Follow the below-mentioned notes when disassembling the unit and reassembling it, to keep it safe and ensure excellent performance: 1. Take cassette tape and compact disc out of the unit.
  • Page 43 CD-G10000/CP-G10000S (F2)x1 (K1)x4 M3x10mm Front Panel Tape Mechanism Lug Wire Open (F1)x6 M3x10mm (K2)x1 Cassette Cover Lug Wire Changer Front Panel Mechanism Unit Display PWB (G3)x5 (G2)x10 M2.6x10mm (L1)x4 (G1)x1 M2.6x10mm CD Mechanism Game Input (H1)x2 M3x10mm Changer Mechanism Unit...
  • Page 44 CD-G10000/CP-G10000S CP-G10000S GBOXSA090AWM1 REMOVAL PROCEDURE REMOVAL PROCEDURE STEP STEP Woofer 1. Front Panel ....(A1) x1 Woofer 1. Front Panel ....(A1) x1 2. Screw ...... (A2) x8 2. Screw ...... (A2) x8 Tweeter 1. Screw ...... (B1) x2 (A1)x1...
  • Page 45 CD-G10000/CP-G10000S Speaker Box Ass'y CP-SW10000S Front Panel STEP REMOVAL PROCEDURE Rear Cabinet 1. Screw ...... (A1) x1 2. Screw ....(A2) x13 Power PWB/Fan 1. Screw ...... (B1) x8 2. Screw ...... (B2) x2 Motor Transformer 3. Socket ..... (B3) x5 4.

  • Page 46: Removing And Reinstalling The Main Parts

    CD-G10000/CP-G10000S [2] Removing and reinstalling the main parts 1. TAPE MECHANISM SECTION Perform steps 1 to 5 and 6 of the disassembly method to remove the tape mechanism. 1.1. How to remove the record/playback and erase heads (TAPE 2) (See Fig. 1) 1.
  • Page 47 CD-G10000/CP-G10000S 2. CD MECHANISM SECTION Perform steps 1, 2, 9 10 and 11 of the disassembly method to remove Reduction gear C the CD mechanism. 2.1. Remove the pickup. (See Fig. 1) 1. Remove the stop washer (A1) x 1 pc., to remove the gear (A2) x 1 2.
  • Page 48 CD-G10000/CP-G10000S 3.2. How to Remove the tray motor/main cam motor/5- Changer Motor PWB (See Fig. 6) 1. Remove the screws (A1)x 2 pcs., to remove tray motor/main cam motor/5-Changer Motor PWB. Changer Mechanism Unit Tray Motor Main Cam Motor 5-Changer...
  • Page 49 CD-G10000/CP-G10000S —— MEMO —— 3 – 8...

  • Page 50: Block Diagrams

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 4. DIAGRAMS [1] Block diagrams CD-G10000 TO DISPLAY SECTION TO MAIN SECTION CNP5 14 13 12 CNP2 68 67 66 65 64 63 62 51 53 59 69 LVDD MO_B-/CONT2 RVDD MO_B+/CONT3...
  • Page 51 CD-G10000/CP-G10000S LV16256-35T D-RAM MDATA0 MDATA3 MDATA0 MDATA4 MDATA7 MDATA7 MDATA8 SI3033LUS DWEB VOLTAGE DRASB REGULATOR MDATA15 ADRS0 RASB LC78683E ADRS3 MP3 DECODER ADRS4 ADRSB ADRS8 ADRS7 D0EM MDATA8 DCASUB ADRS0 MDATA11 DCASLB MDATA12 MDATA15 43 44 45 68 61 51 31 21 11 77 73 66...
  • Page 52 CD-G10000/CP-G10000S CD-G10000 IC301 ZD351 TA7358AP 5.1V FM FRONT END ANTENNA FM IF 10.7 MHz T302 CF303 BF301 X351 450 kHz CF351 456 kHz B.P.F T351 CF352 SO302 FM ANTENNA AM IF TERMINAL FM RF L312 T301 AM LOOP ANTENNA OSC BUFF...
  • Page 53 CD-G10000/CP-G10000S FL701 FL DISPLAY TAPE MECHANISM ASS'Y RX701 59 40 28 26 25 13 27 REMOTE SENSOR IC701 VLOAD AVDD IXA054AW SYSTEM SW701-SW707 SW712-SW723 MICROCOMPUTER SW725-SW735 (1/2) 1 2 3 4 5 6 7 11 12 16 21 24 20 17 18 19...
  • Page 54 CD-G10000/CP-G10000S CP-SW10000S IC901 STK41244 POWER AMP. L902 Q903 Q904 Q902 D902 D901 Q901 L901 D912 D910 Q907 Q908 D911 Q909 VR502 VOLUME Q501 IC502 KIA4558P OPE AMP. D801 +12V VR501 D802 CROSSOVER FREQUENCY IC501 KIA4558P D803~D806 IC801 OPE AMP. KIA7812AP...
  • Page 55 CD-G10000/CP-G10000S M401 FAN MOTOR D908 L902 RL901 L1_OUT R1_OUT Q905 Q906 L901 Q402 D912 D910 Q908 Q401 D911 D907 Q909 SUBWOOFER D801 SW802 POWER F805 6.3A/125V F801 D802 F804 6.3A/125V 6.3A/125V F806 500mA/125V AC POWER SUPPLY CORD 120 V, 60 Hz T.F.

  • Page 56: Chapter 5. Circuit Description

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 5. CIRCUIT DESCRIPTION • The indicated voltage in each section is the one measured by Digi- tal Multimeter between such a section and the chassis with no sig- nal given. [1] Notes on schematic diagram 1.

  • Page 57: Waveforms Of Cd Circuit

    CD-G10000/CP-G10000S [3] Waveforms of CD circuit Stopped Stopped 1999/04/07 09:51:15 CH1=500 mV CH3=500 mV 500 ms/div CH1=200 mV CH2=500 mV 500 ms/div DC 10:1 DC 10:1 (500 ms/div) DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s NORM:20 kS/s IC1 21...

  • Page 58: Voltage

    CD-G10000/CP-G10000S [4] Voltage CD-G10000 IC301 IC601 IC701 NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE 3.20 V 2.10 V 4.74 V 1.61V 2.20 V 4.65 V 1.61 V 2.10 V 0.29 V 1.60 V 2.20 V 0.20 V...
  • Page 59 CD-G10000/CP-G10000S — M E M O — 5 – 4...

  • Page 60: Schematic Diagram

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 6. CIRCUIT SCHEMATICS AND PARTS LAYOUT [1] Schematic diagram CD-G10000 BI601 CNS601 R601 R-CH A_GND L-CH R602 CD_GND A +10V CD_GND IC601 LC75341 C653 C601 C602 220P 220/16 0.022 CD+5V AUDIO PROCESSOR...
  • Page 61 CD-G10000/CP-G10000S GAME INPUT PWB-B2 WTM901 FW901 M_+13V P6-6 11-B SP_RLY TO POWER PWB R-CH CNP901 D690 D691 JK691 VIDEO OUT DS1SS133 DS1SS133 L-CH C693 0.01 CNS603 VIDEO IN R693 C601 C602 L-CH 220/16 0.022 R691 C691 R603 6.8K 390P AUX/VIDEO...
  • Page 62 CD-G10000/CP-G10000S CD-G10000 C302 0.001 AM TRACKING AM ANTENNA T303 C331 0.047 C323 0.022 C332 0.022 0.001 C338 D301 DS1SS133 R365 DS1SS133 D302 VD301 SVC347S AM OSC. R358 T306 3.3K C335 560P AM BAND COVERAGE fL B.P.F BF301 IC301 AM LOOP...
  • Page 63 CD-G10000/CP-G10000S R365 R358 C371 1/50 3.3K R350 2.7K C372 1/50 C367 1/50 C358 10 11 1/50 R352 R355 C357 3.3K 2.2/50 T351 C356 0.001 AM IF R393 L352 C389 0.001 ZD351 100 µH DZ5.1BSB C396 100/10 C395 C397 C394 0.022 C392 0.022...
  • Page 64 CD-G10000/CP-G10000S CD-G10000 IC901 STK41244 POWER AMP. L902 R903 3 µH Q903 KTC3875 GR R917 ZD902 ZD903 0.1(5W) R918 DZ12BSB DZ12BSB C917 R934 2.2K 0.01 C916 C918 100/50 100/50 R919 R925 R926 R910 1.5K 1.5K 1.5K D906 (1/2W) (1/2W) DS1SS133 Q902...
  • Page 65 CD-G10000/CP-G10000S MAIN PWB-A1 (3/3) FM SIGNAL FAN MOTOR L902 DRIVER 3 µH D912 DS1SS133 R949 R942 680(2W) 1K(1/2W) M901 C931 R947 R943 680(2W) R950 10/50 MOTOR R934 L1_OUT Q907 R959 KTC3203 Y R1_OUT RL914 R951 CNP901 FW901 R935 M_+13V P6-2 10-A...
  • Page 66 CD-G10000/CP-G10000S CD-G10000 DISPLAY PWB-A2 FL701 FL DISPLAY LED DRIVER Q710 KRC102 S 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17...
  • Page 67 CD-G10000/CP-G10000S FL701 FL DISPLAY 8 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 R795 C701 1/50 2 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100...
  • Page 68 CD-G10000/CP-G10000S CD-G10000 CD SERVO PWB-C 100P(CH) 0.022 100P(CH) 100P(CH) CD SIGNAL 100P(CH) 100P(CH) 100P(CH) 47/25 0.022 4.7K PICKUP UNIT(306) 0.01 0.22 4.7K 4.7K 0.047 FFC1 0.01 0.001 KTA1504 Y VREF VREF 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 0.001...
  • Page 69 CD-G10000/CP-G10000S ONLY FCLK FLASH FFC704 CNP4 47/10 4.19MHz 4.7K 4.7K 100K 0.01 CD RES RESET FSYNC 2.2K 2.2K MP3-RES CDEMPH SYS-DI DISC SYS-DO IXA006AW CLAMP MICRO- TRAY SW1 SYS-CL TRAY SW2 COMPUTER SYS-CE PHOTO INTB 2.2K AVDD AVREF SUB_CE 0.01 3 4 5 6 7 8 9 10 2.2K...
  • Page 70 CD-G10000/CP-G10000S CP-SW10000S IC901 STK41244 POWER AMP. R903 C907 100P L902 Q903 3 µH KTC3199 GR R916 ZD901 (5W) DZ12BSB C917 (ML) 0.01 R922 R921 R910 D902 1.5K 1.5K 1N4148H (1/2W) (1/2W) 0.22 Q902 KTC3199 GR C911 Q901 (ML) KTC3199 GR...
  • Page 71 CD-G10000/CP-G10000S POWER PWB-A1 SUBWOOFER SIGNAL M401 FAN MOTOR D908 1N4148H CNP402 CNS402 L902 R936 RL901 3 µH 9 GR 1.5K L1_OUT C404 R1_OUT 47/25 C926 C927 0.22 0.22 R409 C929 C928 Q905 0.22 0.22 KTC3199 GR Q906 Q402 KTC3199 GR...

  • Page 72: Wiring Side Of Pwb

    CD-G10000/CP-G10000S [2] Wiring side of PWB CD-G10000 MAIN PWB-A1 C376 C379 C302 R374 R373 X352 R378 C378 R372 R388 C382 1 2 3 4 5 6 7 8 9 10 11 IC302 C381 R376 R379 C387 C395 JP303 TP301 22 21 20 19 18 17 16 15 14 13 12...
  • Page 73 CD-G10000/CP-G10000S R138 R122 R124 C134 C120 R136 C135 C128 R158 R132 C126 C133 C131 R135 C127 R130 C129 R150 C125 R133 R126 R131 C121 C124 FFC701 R129 R128 CNP701B C143 C123 P6-19 4-E R127 FROM TAPE 1 PLAYBACK HEAD R137...
  • Page 74 CD-G10000/CP-G10000S CD-G10000 DISPLA PWB-A2 JOG701 VOLUME R780 SW704 SW706 TUNING EQUALIZER RD05 R785 Q707 DOWN RD04 RD06 SW705 R775 FAST REWIND/ JP701 R776 PRESET DOWN R778 RD03 JP717 B C E Q715 Q716 R779 JP707 R728 SW703 JP718 R725 R726...
  • Page 75 CD-G10000/CP-G10000S P6-20 5-A P6-19 3-B TO POWER PWB TO TAPE MECHANISM PWB CNP802 FFC702 FW701 OG701 SW716 OLUME SW726 SW727 X-BASS/ STOP REC/ DEMO WTM705 RD24 PAUSE CNP702A JP701 RD25 Q708 R790 SW728 B C E MEMORY/ Q712 R786 R779...
  • Page 76 CD-G10000/CP-G10000S CD-G10000 1110 70 75 50 55 CD/MP3 PWB-D (TOP VIEW) Figure 6-17 WIRING SIDE OF PWB (5/11) 6 – 17...
  • Page 77 CD-G10000/CP-G10000S FFC1 FFC4 CNS3B P6-19 5-F FROM CD MOTOR PWB CNP5 CNP2 CD/MP3 PWB-D (BOTTOM VIEW) CNS601 FFC704 P6-14 11-E FROM MAIN PWB CNP704 P6-16 11-D TO DISPLAY PWB Figure 6-18 WIRING SIDE OF PWB (6/11) 6 – 18...
  • Page 78 CD-G10000/CP-G10000S CD-G10000 P6-16 7-A COLOR TABLE TAPE MECHANISM TO DISPLAY PWB BROWN ASSEMBLY CNP702 RD ( R ) ORANGE TAPE MECHANISM PWB-D FFC702 YELLOW GREEN BLUE VIOLET GRAY W H ( W ) WHITE BLACK PINK SOLENOID SOLENOID TAPE MOTOR...
  • Page 79 CD-G10000/CP-G10000S CD-G10000 P6-14 14-G FROM MAIN PWB POWER PWB-B1 CNS801 R841 1 2 3 4 5 6 CNP802 D853 R844 D801 CNP801 C811 R858 C841 C810 C804 D802 C843 R842 C808 F802 5A/125V Q841 B C E R843 PT801 MAIN POWER TRANSFORMER T.F.
  • Page 80 CD-G10000/CP-G10000S CP-SW10000S POWER PWB-A1 LG902 R409 D805 D804 D803 D806 R924 Q402 R935 R934 C810 F804 C804 6.3A/125V C808 C803 R801 F805 6.3A/125V C806 C805 R925 C918 D801 ZD902 R922 C916 R921 ZD901 R914 C902 R902 C904 R904 C908 R942...
  • Page 81 CD-G10000/CP-G10000S TRANSFORMER PWB-A2 CNP802 CNS802 P6-23 4-E FROM POWER SWITCH PWB COLOR TABLE BROWN RD(R) ORANGE YELLOW GREEN BLUE VIOLET AC POWER SUPPLY CORD GRAY AC 120 V, 60 Hz W H ( W ) WHITE CNP804 BLACK PINK CNS801...
  • Page 82 CD-G10000/CP-G10000S CP-SW1000S RD(R) W H ( W ) COLOR TABLE BROWN ORANGE YELLOW GREEN BLUE VIOLET GRAY WHITE BLACK PINK VOLUME VR502 LED B PWB-B4 IC502 R527 R524 R537 BI502 R525 LED502 VR501 CNP501 CNS502 CROSSOVER C514 FREQUENCY CNS504 CNS902...

  • Page 83: Troubleshooting

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 7. FLOWCHART [1] Troubleshooting 1. When the CD does not function The CD section may not operate when the objective lens of the optical pickup is dirty. Clean the objective lens, and check the playback operation.
  • Page 84 CD-G10000/CP-G10000S (1) Focus-HF system check. Stopped CH1=500 mV CH3=500 mV 500 ms/div Although a CD is inserted and the cover is closed, “NO DISC” is DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s displayed. Press the Tray1 CD Eject Button without inserting a disc, and try starting the playback operation.
  • Page 85 CD-G10000/CP-G10000S (2) Focus-HF system check. Check the TE waveform at pin 15 on IC1. If the waveform shown in Figure 4 appears and soon after NO The tracking servo is not activated. DISC appears? Check the peripheral circuits at pins 16, 17 and 22 on IC1, and FFC1.
  • Page 86 CD-G10000/CP-G10000S (4) PLL system check. 1999/04/05 17:33:17 CH1=500 mV CH3=1 V CH4=1 V 500 ms/div DC 10:1 DC 10:1 DC 10:1 (500 ms/div) When a disc is loaded, start play operation. NORM:20 kS/s PDO1 The HF waveform is normal, but the TOC data cannot be read.

  • Page 87: Function Table Of Ic

    CD-G10000/CP-G10000S Audio CD-G10000/CP-G10000S Service Manual CD-G10000/CP-G10000S Market CHAPTER 8. OTHERS [1] Function table of IC IC1 VHiLC78648E-1: CD Servo (LC78648E) (1/2) Pin No. Terminal Name Input/Output Setting in Reset Function AVDD1 Output — Analog power supply pin 1. SLCO Output —...
  • Page 88 CD-G10000/CP-G10000S IC1 VHiLC78648E-1: CD Servo (LC78648E) (2/2) Pin No. Terminal Name Input/Output Setting in Reset Function RCHO Output RVDD /2 Right channel R channel Power supply pin. RVDD — — D/A converter R channel output supply pin. XVSS — —...
  • Page 89 CD-G10000/CP-G10000S IC1 VHiLC78648E-1: CD Servo (LC78648E) 75 74 72 71 69 68 66 65 63 62 AVDD1 DVDD SLCO DATA EFMIN DATACK LRSY ASDFIN JITTC ASDACK ASLRCK F16MOUT OUT1 F16MIN LC78648E IOMODE PHLPF/RFMON XVDD VREF XOUT XVSS RVDD RCHO TEIN...
  • Page 90 CD-G10000/CP-G10000S IC2 VHILA6261//-1: Focus/Tracking/Spin/Sled Driver (LA6261) Pin No. Terminal Name Function VO3+ BTL Output pin (+) for channel 3. VO3- BTL Output pin (-) for channel 3. VO2+ BTL Output pin (+) for channel 2. VO2- BTL Output pin (-) for channel 2.
  • Page 91 CD-G10000/CP-G10000S IC2 VHILA6261//-1: Focus/Tracking/Spin/Sled Driver (LA6261) VOLTAGE CONTROL AMP DUFFER AMP DUFFER AMP For VREF For 1/2 VCC Reference voltage Band gad Figure 8-5 BLOCK DIAGRAM OF IC 8 – 5...
  • Page 92 CD-G10000/CP-G10000S IC601 VHiLC75341/-1: Audio Processor (LC75341) Pin No. Terminal Name Function Pin No. Terminal Name Function 13-16 R1-4 Input signal pin. Serial data and clock input pin for con- RSEL0 Input selector output pin. trol. Volume + equalizer output pin Chip enable pin.
  • Page 93 CD-G10000/CP-G10000S IC701 RH-iXA054AWZZ: System Microcomputer (IXA054AW) (1/2) Pin No. Port Name Terminal Name Input/Output Function Input (+) Power supply 5 V. -20dBATT Output -20dB Attenuator. T BIAS Output Tape record bias control. T_REC/PLAY Output Tape REC/PLAY control. T_T1/T2 Output Tape T1/T2 Control.
  • Page 94 CD-G10000/CP-G10000S IC701 RH-iXA054AWZZ: System Microcomputer (IXA054AW) (2/2) Pin No. Port Name Terminal Name Input/Output Function 73-78 FIP26-FIP21 S15-S10 Output FL segment driver. VLOAD VLOAD Input VLOAD -35 V 80-88 FIP20-FIP11 S9-S1 Output FL segment driver. 89-100 FIP10-FIP0 G12-G1 Output FL grid driver.
  • Page 95 CD-G10000/CP-G10000S IC851 VHIAN80T53/-1: Multi Regulator (AN80T53) Terminal Name Function REG4 Output 5.1 V power supply with a minimum peak out current of 1200 mA. REG3 Output 13 V power supply with a minimum peak out current of 1350 mA. Connected to Power supplies.

  • Page 96: Fl Display

    CD-G10000/CP-G10000S [2] FL Display FL701 VVKNA12MM44-1 GRID ASSIGNMENT col2 Dot2 col1 Dot1 2G 3G 4G 5G 6G 7G h j k (1G) (2G~11G) ANODE CONNECTION FOLDER TITLE-1 TITLE-2 TOTAL TITLE-3 D5-a PTYI D5-b D5-c SLEEP DAILY D4-a D4-b D4-c D3-a...

  • Page 97: Parts Guide (Cd-G10000)

    CD-G10000/CP-G10000S PARTS GUIDE No. S1506CDG10000 MINI COMPONENT SYSTEM CD-G10000 MODEL CD-G10000 Mini Component System consisting of CD-G10000 (main unit) and GBOXSA090AWM1 (rear speaker system). CONTENTS [1] INTEGRATED CIRCUITS [12] CD MECHANISM PARTS [2] TRANSISTORS [13] CHANGER MECHANISM PARTS [3] DIODES...
  • Page 98 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [1] INTEGRATED CIRCUITS CD Servo,LC78648E VHILC78648E-1 Focus/Tracking/Spin/Sled Driver,LA6261 VHILA6261//-1 MP3 Decoder,LC78684E VHILC78684E-1 D-RAM,LV6125635T VHILV1625635T Microcomputer,IXA006AW RH-IXA006AWZZ Voltage Regulator,SI3033LUS1 VHISI3033LUS1 Playback and Record/Playback Amp.,AN7345K IC101 VHIAN7345K/-1 FM Front End,TA7358AP IC301 VHITA7358AP-1 PLL (Tuner),LC72131...
  • Page 99 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [3] DIODES Silicon,D10XB60F D801 VHDD10XB60F-1 Silicon,D10XB60F D802 VHDD10XB60F-1 Silicon,1N4004S D803 VHD1N4004S/-1 Silicon,1N4004S D804 VHD1N4004S/-1 Silicon,1N4004S D805 VHD1N4004S/-1 Silicon,1N4004S D806 VHD1N4004S/-1 Silicon,1N4004S D842 VHD1N4004S/-1 Silicon,1N4004S D843 VHD1N4004S/-1 Silicon,1N4004S D844 VHD1N4004S/-1 Silicon,1N4004S D845...
  • Page 100 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [9] CAPACITORS 47 µ F,25V,Electrolytic VCEAZA1EW476M 0.01 µ F,16V VCKYCY1CB103K 47 µ F,25V,Electrolytic VCEAZA1EW476M 0.001 µ F,50V VCKYCY1HB102K 0.047 µ F,16V VCKYCY1CB473K 0.01 µ F,16V VCKYCY1CB103K 0.0027 µ F,50V VCKYCY1HB272K 3.3 µ F,16V,Electrolytic RC-EZ0004AWZZ 0.1 µ...
  • Page 101 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [9] CAPACITORS 0.039 µ F,25V C114 VCTYPA1EX393K 560 pF,50V C115 VCKYCY1HB561K 560 pF,50V C116 VCKYCY1HB561K 47 µ F,25V,Electrolytic C117 VCEAZA1EW476M 47 µ F,25V,Electrolytic C118 VCEAZA1EW476M 0.0022 µ F,50V C119 VCKYCY1HB222K 0.0022 µ F,50V...
  • Page 102 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [9] CAPACITORS 47 pF,50V C383 VCCSBT1HL470J 0.001 µ F,50V C384 VCKYCY1HB102K 0.01 µ F,50V C385 VCKYCY1HB103K 330 pF,50V C386 VCKYCY1HB331K 0.022 µ F,25V C387 VCKYCY1EF223Z 0.001 µ F,50V C388 VCKYCY1HB102K 0.001 µ F,50V...
  • Page 103 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [9] CAPACITORS 4700 µ F,25V,Electrolytic C850 VCEAZW1EW478M 0.1 µ F,50V,Mylar C851 VCQYKA1HM104K 0.1 µ F,50V,Mylar C852 VCQYKA1HM104K 220 µ F,25V,Electrolytic C854 VCEAZA1EW227M 10 µ F,50V,Electrolytic C855 VCEAZA1HW106M 0.1 µ F,50V,Mylar C856 VCQYKA1HM104K 22 µ...
  • Page 104 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [10] RESISTORS 2.2 kohms,1/16W VRS-CY1JB222J 10 ohm,1/16W VRS-CY1JB100J 4.7 kohms,1/16W VRS-CY1JB472J 330 ohms,1/16W VRS-CY1JB331J 8.2 kohms,1/16W VRS-CY1JB822J 6.8 kohms,1/16W VRS-CY1JB682J 6.8 kohms,1/16W VRS-CY1JB682J 6.8 kohms,1/16W VRS-CY1JB682J 4.7 kohms,1/16W VRS-CY1JB472J 1 kohm,1/16W...
  • Page 105 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [10] RESISTORS 33 kohms,1/16W VRS-CY1JB333J 270 ohms,1/16W VRS-CY1JB271J 2.2 Mohms,1/16W VRS-CY1JB225J 1 kohm,1/16W R101 VRS-CY1JB102J 1 kohm,1/16W R102 VRS-CY1JB102J 2.2 kohms,1/16W R103 VRS-CY1JB222J 2.2 kohms,1/16W R104 VRS-CY1JB222J 3.3 kohms,1/16W R105 VRS-CY1JB332J 3.3 kohms,1/16W...
  • Page 106 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [10] RESISTORS 150 ohms,1/4W R382 VRD-ST2EE151J 5.6 kohms,1/16W R383 VRS-CY1JB562J 5.6 kohms,1/6W R384 VRD-ST2CD562J 5.6 kohms,1/16W R385 VRS-CY1JB562J 22 kohms,1/6W R386 VRD-ST2CD223J 5.6 kohms,1/6W R387 VRD-ST2CD562J 3.9 kohms,1/16W R388 VRS-CY1JB392J 270 ohms,1/4W...
  • Page 107 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [10] RESISTORS 10 kohm,1/16W R762 VRS-CY1JB103J 1 kohm,1/16W R763 VRS-CY1JB102J 10 kohm,1/16W R766 VRS-CY1JB103J 10 kohm,1/16W R767 VRS-CY1JB103J 10 kohm,1/16W R768 VRS-CY1JB103J 1 kohm,1/6W R769 VRD-ST2CD102J 5.6 kohms,1/16W R770 VRS-CY1JB562J 4.7 kohms,1/6W...
  • Page 108 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [10] RESISTORS 10 ohm,1/2W R940 VRD-RT2HD100J 10 ohm,1/2W R941 VRD-RT2HD100J 680 ohms,2W R942 VRS-VV3DA681J 680 ohms,2W R943 VRS-VV3DA681J 1.5 kohms,1/6W R944 VRD-ST2CD152J 1.5 kohms,1/6W R945 VRD-ST2CD152J 47 kohms,1/16W R946 VRS-CY1JB473J 15 kohms,1/16W...
  • Page 109 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [11] OTHER CIRCUITRY PARTS F804 QFS-D202BSJNI Fuse,2A/125V Fuse,6A/125V F805 QFS-D602DAWNI Flat Cable,16Pin FFC1 QCNWNA088AWPZ Flat Cable,11Pin FFC4 QCNWN2701AWPZ Flat Cable,16Pin FFC701 QCNWN2716AWPZ Flat Cable,7Pin FFC702 QCNWN2495AWZZ Flat Cable,16Pin FFC704 QCNWN2718AWPZ Ferrit Bead...
  • Page 110 CD-G10000/CP-G10000S [12] CD MECHANISM PARTS 306-2 306-1 306-3 703x2 305x2 NSW1 PWB-F...
  • Page 111 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [12] CD MECHANISM PARTS Gear,Middle NGERH0011AWZZ Gear,Drive NGERH0012AWZZ Shaft,Guide NSFTM0020AWFW Cushion 92LMCUSN1524A Pickup Unit Ass'y 92LHPC1LFASY — Pickup Unit (Not Replacement Item) 306- 1 -------- Gear,Rack 306- 2 NGERR0043AFZZ Spring,Rack 306- 3...
  • Page 112 CD-G10000/CP-G10000S [13] CHANGER MECHANISM PARTS 803x6 801x2 PWB-E 109-3 109-5 803x2 109-1 109-4 109-2...
  • Page 113 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [13] CHANGER MECHANISM PARTS Disc Tray GCOVA1513AWZZ Guide Tray GCOVA1514AWZZ Outer Tray Guide LANGG0008AWZZ Inner Tray Guide LANGG0009AWZZ Main Base LCHSM0194AWZZ CD Mechanism Holder LHLDZ9017AWZZ Top Plate LPLTP0014AWZZ Gear Plate LPLTP0015AWZZ...
  • Page 114 CD-G10000/CP-G10000S [14] CABINET PARTS BELT CONNECTION CHANGER FF/REW Tape FF/REW MECHANISM UNIT 601x5 ROLLER Motor ROLLER ASS'Y ASS'Y FLYWHEEL FLYWHEEL ASS'Y ASS'Y MAIN BELT TAPE2 TAPE1 PWB-D 601x3 605x6 MECHANISM 603x4 601x3 601x2 M901 602x4 604x10 PWB-C 602x2 605x2 601x11...
  • Page 115 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [14] CABINET PARTS Front Panel Ass'y CCABA6232AW01 — Front Panel (Not Replacement Item) 201- 1 -------- Cover,Cassette [Tape 1] 201- 2 GCOVA1521AWSA Cover,Cassette [Tape 2] 201- 3 GCOVA1522AWSA Holder,Cassette [Tape 1]...
  • Page 116 CD-G10000/CP-G10000S [15] SURROUND SPEAKER BOX PARTS SP1, 2 910x4 SP3, 4 910x4 903x4 SP3, SPEAKER SP1, SPEAKER SP3, SPEAKER SP1, SPEAKER...
  • Page 117 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [15] SURROUND SPEAKER BOX PARTS Speaker Box Ass'y GBOXSA043AW01 Front Panel HPNLSA016AWSA Leg Cushion PCUSGA020AWZZ Cushion,Front Panel Support PCUSSA015AWZZ Lead Wire Ass'y QCNWNA148AWZZ Decoration Panel HDECQA062AWSA Speaker Ring Ass'y CDECQA063AW01 Label,Specifications...
  • Page 118 CD-G10000/CP-G10000S INDEX INDEX PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK MLEVP0135AWZZ 13-116 [ C ] CCABA6232AW01 14-201 MLEVP0136AWZZ 13-117 MLEVP0137AWZZ 13-118 CDECQA063AW01 15-907 MLEVP0138AWZZ 13-119 [ G ] MLEVP0139AWZZ 13-120 GBOXSA043AW01 15-901 MLIF-A001AWZZ...
  • Page 119 CD-G10000/CP-G10000S PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK " 11-CNP701A RRLYD0018AWZZ 11-RL841 QCNWGA003AWPZ RRMCG0395AWSA 17-1 QCNWHA004AWZZ RSP-ZA041AWZZ 15-SP1 QCNWNA088AWPZ 11-FFC1 " 15-SP2 QCNWN1860AWZZ 14-212 " 15-SP3 QCNWN2495AWZZ 11-FFC702 " 15-SP4 QCNWN2561AWZZ 11-BI901 RTRNP0483AWZZ...
  • Page 120 CD-G10000/CP-G10000S PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK " 9-C817 " 9-C606 " 9-C864 VCFYFA1HA224J 9-C607 " 9-C865 " 9-C608 VCEAZA1EW227M 9-C854 VCKYBT1HB101K 9-C318 VCEAZA1EW476M 9-C1 VCKYBT1HB102K 9-C320 " 9-C3 " 9-C389 "...
  • Page 121 CD-G10000/CP-G10000S PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK VCKYCY1HB103K 9-C304 " 3-D844 " 9-C315 " 3-D845 " 9-C385 " 3-D853 " 9-C693 " 3-D909 " 9-C715 " 3-D910 " 9-C917 VHDD10XB60F-1 3-D801 "...
  • Page 122 CD-G10000/CP-G10000S PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK " 10-R602 " 10-R795 " 10-R603 VRD-ST2EE221J 10-R158 " 10-R704 VRD-ST2EE271J 10-R391 " 10-R705 " 10-R392 " 10-R707 VRD-ST2EE393J 10-R927 " 10-R708 " 10-R928 "...
  • Page 123 CD-G10000/CP-G10000S PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK " 10-R78 " 10-R947 " 10-R101 " 10-RD20 " 10-R102 " 10-RD32 " 10-R352 VRS-CY1JB182J 10-R359 " 10-R356 VRS-CY1JB183J 10-R121 " 10-R372 " 10-R122 "...
  • Page 124 CD-G10000/CP-G10000S PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK " 10-R52 " 2-Q5 " 10-R56 VSKRA107S//-1 2-Q607 " 10-R79 " 2-Q608 " 10-R84 " 2-Q711 " 10-R86 " 2-Q715 " 10-R87 " 2-Q717 "...
  • Page 125 CD-G10000/CP-G10000S PRICE PART PARTS CODE RANK MARK RANK 92LMTR1854BASY 11-NM2 " 12-NM2 92LMTR5515CASY 11-NM1 " 12-NM1 92LMTR5529BASY 11-M1 " 11-M2 " 13-M1 " 13-M2 92LNBAND1318A 14-208 92LPWB5534PWRS 18-PWB-B 92LPWB5612CDUS 18-PWB-C 92LPWB5813SPKS 18-PWB-G 92LPWB6232MANS 18-PWB-A 92LSWICH1401AT 11-SW701 " 11-SW702 " 11-SW703 "...
  • Page 126 CD-G10000/CP-G10000S...

  • Page 127: Parts Guide (Cp-G10000S)

    CD-G10000/CP-G10000S PARTS GUIDE No. S1506CDG10000 SPEAKER SYSTEM CP-G10000S MODEL CP-G10000S Speaker System consisting of CP-G10000S (front speaker system) and CP-SW10000S (active subwoofer). CONTENTS [1] INTEGRATED CIRCUITS [10] OTHER CIRCUITRY PARTS [2] TRANSISTORS [11] FRONT SPEAKER BOX [3] DIODES PARTS [4] TRANSFORMER...
  • Page 128 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [1] INTEGRATED CIRCUITS Ope Amp.,KIA4558P IC501 VHIKIA4558P-1 Ope Amp.,KIA4558P IC502 VHIKIA4558P-1 Voltage Regulator,KIA7812AP IC801 VHIKIA7812AP1 Power Amp.,STK41244 IC901 VHISTK41244-1 [2] TRANSISTORS Silicon,NPN,KTC3205 Y Q401 VSKTC3205Y/-1 Silicon,NPN,KTC3203 Y Q402 VSKTC3203Y/-1 Silicon,NPN,KTC3199 GR...
  • Page 129 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [8] CAPACITORS 100 pF,50V C523 VCCSPA1HL101J 10 µ F,50V,Electrolytic C526 VCEAZA1HW106M 10 µ F,50V,Electrolytic C529 VCEAZA1HW106M 0.1 µ F,50V,Mylar C803 VCQYKA1HM104K 0.1 µ F,50V,Mylar C804 VCQYKA1HM104K 0.22 µ F,100V,Thin Film C805 VCFYDA2AA224J 0.22 µ...
  • Page 130 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [9] RESISTORS 1 kohm,1/6W R909 VRD-ST2CD102J 1 kohm,1/6W R910 VRD-ST2CD102J 100 ohm,1/4W,Fusible R911 VRG-ST2EC101J 100 ohm,1/4W,Fusible R912 VRG-ST2EC101J 0.22 ohms,5W R913 VRN-CM05NR22J 0.22 ohms,5W R914 VRN-CM05NR22J 0.1 ohm,5W R915 VRN-CM05N0R1J 0.1 ohm,5W...
  • Page 131 CD-G10000/CP-G10000S [11] FRONT SPEAKER BOX PARTS SP1, 2 910x4 SP5, 6 909x2 SP3, 4 910x4 SP5, TWEETER Capacitor 905x4 2.7 µF, 250 V Electrolytic SP3, WOOFER SP1, WOOFER 911x2 SP5, TWEETER Capacitor 2.7 µF, 250 V Electrolytic SP3, WOOFER SP1,...
  • Page 132 PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [11] FRONT SPEAKER BOX PARTS Tweeter Ring Ass'y CDECQA061AW01 Woofer Ring Ass'y CDECQA063AW01 Speaker Box Ass'y GBOXSA042AW01 Front Panel HPNLSA015AWSA Cushion,Leg PCUSGA020AWZZ Lead Wire Ass'y (with Capacitor C1,2) QCNWNA147AWZZ Label,Specifications TSPC-A313AWZZ Screw,M3x12mm XMBSF30P12000 Screw,M4x16mm XMBSF40P16000...
  • Page 133 CD-G10000/CP-G10000S [12] SUBWOOFER BOX PARTS 946x2 952x4 946x2 955x4 954x13 926x2 947x2 946x8 PWB-A1 923x4 Silicon Grease 930x4 929x2 927x3 949x4 932x6 939x2 946x2 IC901 946x2 M401 952x4 948x2 955x4 923x4 940x4 955x2 930x4 932x2 927x3 PWB-A2 941x2 937x4 PWB-A3...
  • Page 134 CD-G10000/CP-G10000S PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [12] SUBWOOFER BOX PARTS Decoration Bar Ass'y CDECQA064AW01 Decoration Cover,Front 901- 1 HDECQA064AWSA White Reflector 901- 2 LHLDZA013AWZZ Edge Light Panel 901- 3 HDECQA066AWSA Decoration Cover,Rear 901- 4 HDECQA065AWSA Duct Port Ass'y...
  • Page 135 CD-G10000/CP-G10000S INDEX INDEX PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK [ C ] [ R ] CDECQA061AW01 11-901 RC-EZ0085AWZZ 8-C922 CDECQA063AW01 11-902 " 8-C923 CDECQA064AW01 12-901 RC-EZ0124AWZZ 8-C920 CDUC-A016AW01A 12-902 " 8-C921 CPNLSA017AW01...
  • Page 136 CD-G10000/CP-G10000S PRICE PART PRICE PART PARTS CODE PARTS CODE RANK MARK RANK RANK MARK RANK VCKYPA1HB102K 8-C501 " 9-R938 VCQYKA1HM103K 8-C917 VRD-ST2CD272J 9-R510 " 8-C919 " 9-R514 VCQYKA1HM104K 8-C516 VRD-ST2CD333J 9-R942 " 8-C803 VRD-ST2CD472J 9-R404 " 8-C804 " 9-R535 "...
  • Page 137 CD-G10000/CP-G10000S −− MEMO −−...
  • Page 138 CD-G10000/CP-G10000S −− MEMO −−...
  • Page 139 HOW TO ORDER REPLACEMENT PARTS To have your order filled promptly and correctly, please furnish the For U.S.A. only following information. Contact your nearest SHARP Parts Distributor to order. 1. MODEL NUMBER 2. REF. No. 3. PART NO. 4. DESCRIPTION For location of SHARP Parts Distributor, Please call Toll-Free;...
  • Page 140 CD-G10000/CP-G10000S © COPYRIGHT 2005 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

This manual is also suitable for:

Cp-g10000s

Table of Contents
