4G LTE Cellular Modem plus
AC1900 WiFi Router
Model ML2410
Quick
Start
Guide

Advertisement

Table of Contents
loading

Related Manuals for Motorola ML2410

Summary of Contents for Motorola ML2410

  • Page 1 4G LTE Cellular Modem plus AC1900 WiFi Router Model ML2410 Quick Start Guide...
  • Page 2 Packaged with your ML2410 Power Adapter 2 LTE Antennas Ethernet Cable Para una Guía de Inicio Rápido en español, por favor vaya a www.motorolanetwork.com/ML2410ir...

  • Page 3: Let's Get Started

    First, insert the SIM card. Remove the battery cover on the ML2410’s back panel to access the SIM slot. Using a Phillips head screwdriver, remove the screw from the battery cover. Remove the battery cover and insert the SIM. The copper side of your SIM should be facing inwards and the notch in the SIM should be facing up.
  • Page 4 2 Next, attach the 2 LTE Antennas to the ML2410 by screwing them finger-tight into the 2 gold connectors located on the back of the unit. 3 Now, connect the supplied power adapter between the ML2410’s power jack and an electrical outlet. The ML2410 will power up and the power light on the front of the unit will turn green.
  • Page 5 Using the ML2410 for Cellular Backup If you wish to use the ML2410 as a back up option for your primary Internet connection, you should have first installed it as a cellular modem above. Then follow these steps. Connect the ML2410’s yellow Ethernet cable between the ML2410’s WAN port and the Ethernet port of a cable...
  • Page 6 Enter. • In the Login dialog box, enter the Login information printed on the bottom label of your ML2410. • The Basic Setup page will appear. If the Basic Setup page doesn’t appear, please see the Troubleshooting Tips below.

  • Page 7: Connect Your Devices

    Then use the ML2410 router’s WiFi Network Name (SSID) and WiFi Password/Key. The unique factory-set default settings are printed on a label on the bottom of the ML2410. If you prefer to use a different network name and password, the MotoManage™...
  • Page 8 Download the MotoManage app on your smartphone or tablet. 2 Open the app. 3 Scan the QR code on the bottom of your ML2410 to setup your device’s WiFi network. 4 Now enjoy the app. You can easily elect to keep your original name and password, as we recommend.

  • Page 9: Front Panel

    Front Panel LIGHT COLOR DESCRIPTION Green: ML2410 power on Green OFF: ML2410 power off Amber: ML2410 running on battery Power Blinking Low battery Amber Amber: Green: Connected in LTE mode Green Amber: Connected in 3G mode Blinking: Sending data Cell Status...

  • Page 10: Back Panel

    Back Panel RESET – Resets the ML2410 to factory defaults – WiFi Protected Setup ANT MAIN – Main cellular antenna ANT DIV – Diversity cellular antenna USB 3.0 PORT WAN PORT – Connect to your modem for cellular backup LAN PORTS – Connect a...

  • Page 11: Troubleshooting Tips

    I’m using cellular as my connection type and I can’t connect to the Internet after installing my ML2410. • Check that the ML2410 is powered on. The power LED on the front panel should be green. If it is not on then: o Check that the power button on the back of the unit is pushed in.
  • Page 12 My cellular connection seems slow. • You may need to move the ML2410 closer to a window in your house to improve the cellular signal. • During times of high cellular traffic, the bandwidth available to the ML2410 will be limited.
  • Page 13 Note that wireless performance depends on a number of factors. Please keep these things in mind: • Where possible, put the ML2410 in a central place so that it’s not too far away from your other wireless devices. • Don’t put the ML2410 close to interference-generating wireless devices such as Bluetooth headsets and stereos, microwave ovens, 2.4 GHz cordless phones and base stations,...

  • Page 14: Battery Purchase Or Replacement

    The ML2410 has battery back-up circuitry which allows your cell modem/router to still function even when your AC power is lost. The ML2410 typically does not ship with a battery included. Note that in the case of loss of power, the battery will provide up to 12 hours of usage.

  • Page 15: Limited Warranty

     Do not put the ML2410 or its power cube in water, since this is a shock hazard.  Protect the ML2410 from moisture and be careful about temperature.
  • Page 16 38 cm between the radiator and your body. MTRLC LLC PO Box 121147 Boston, MA 02112-1147 ©MTRLC LLC 2020. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license.
