- Page 1 Grandstream Networks, Inc. GRP26XX Carrier-Grade IP phones BLF Configuration User Guide...
-
Page 2: Table Of Contents
Table of contents INTRODUCTION ......................4 OVERVIEW OF FUNCTIONS ..................5 CONFIGURATION VIA WEB BROWSER ..................... 5 BLF KEYS CONFIGURATIONS ......................6 VISUAL INDICATORS ......................... 10 DIRECTED CALL PICKUP ........................11 P a g e GRP26XX Series - BLF Guide... - Page 3 Table of Figures Figure 1: Programmable Keys Settings ......................6 Figure 2: Configure Multi-Purpose Keys ....................... 7 Figure 3: Select Associated Account ......................7 Figure 4: Add Description ..........................8 Figure 5: Add Extension Value ........................8 Figure 6: Click “Save” ............................ 9 Table of Tables Table 1: Default Passwords for Login Page ....................
-
Page 4: Introduction
INTRODUCTION Busy Lamp Field (BLF) feature allows an end user, such as attendant, to monitor the hook status of a list of users. GRP26XX supports Busy Lamp Field (BLF) on the Multi-Purpose Keys on the phone. This document serves as an end user guide on how to configure Grandstream GRP Carrier-Grade IP Phones for Busy Lamp Field feature. -
Page 5: Overview Of Functions
OVERVIEW OF FUNCTIONS Grandstream GRP Carrier-Grade IP Phones supports Busy Lamp Filed (BLF) feature. GRP26XX supports this feature by changing the color and status of the MPK indicators, associated with the monitored users. GRP26XX phones support this feature by changing the LED keys color and status on the MPKs on phone body. -
Page 6: Blf Keys Configurations
• There are two default passwords for the login page: Table 1: Default Passwords for Login Page User Level User Password Web Pages Allowed Only Status and Basic Settings End User Level user Browse all pages Administrator Level admin admin The password is case sensitive with maximum length of 25 characters. -
Page 7: Figure 2: Configure Multi-Purpose Keys
Figure 2: Configure Multi-Purpose Keys 5. On the “Account” dropdown menu, select the account associated with the IP PBX that carries the extension being set up; Figure 3: Select Associated Account 6. In the “Description” field, type the name of the individual or department that you want to associate with the extension being set up;... -
Page 8: Figure 4: Add Description
Figure 4: Add Description 7. In the “Value” field, type the extension number for the extension being set up; Figure 5: Add Extension Value 8. Go to the bottom of the page and click on “Save”. P a g e GRP26XX Series - BLF Guide... -
Page 9: Figure 6: Click "Save
Figure 6: Click “Save” 9. Then in the bottom of the “Virtual Multi-Purpose Keys” page and click on “Save VPK”. Figure 7: Click “Save VPK” Note: If users would like to configure more VPKs than the ones displayed on the page to perform BLF, they can click on “Add VPK”... -
Page 10: Visual Indicators
Figure 8: Add VPK VISUAL INDICATORS The phone system is able to notify the end user the hook status of the monitored extension by changing the LED colors. For example, if the monitored extension is ringing, the BLF indicator status will be changed from solid green to blinking red;... -
Page 11: Directed Call Pickup
DIRECTED CALL PICKUP Directed call pickup feature allows GRP26XX phone system to be able to answer the calls to the monitored users. This feature is very useful for the attendant to help the specified callees to answer the call if the callees are not available to answer it.
