Setting up your router

1.
Attach the Australian plug onto the power adapter.
2. Plug the DC connector end of the power adapter into the DCIN port
of your router, and the plug end into a wall power outlet.
3. If you have a NBN connection box for your service:
Connect the Ethernet cable from the blue WAN port on your router
to the LAN or data port on the NBN device.
If you are not supplied with a NBN connection box for your service:
Connect the DSL cable from the grey DSL port on your router to a
NBN FTTN/B wall socket.
4.
Switch on both the wall power outlet and the router to start internet
connection automatically. Wait a few minutes until the DSL/WAN LED
turns solid white, indicating that the internet is up and running.
NBN FTTN/B
wall socket
4
DSL-AX5400
DSL LAN
Wall Power
WAN
Outlet
Power
Laptop
NBN FTTP /
FTTC / HFC /
Fixed Wireless
