Installing the Zoneline

1. Plan for proper electrical supply, drains and ductwork
locations.
2. Install the wall plenum and louver.
3. Install and level the drain platform.
4. Complete condensate drain connections.
5. Install unit drain platform.
6. Level and secure drain platform.
7. Connect the top ductwork.
8. Connect the remote thermostat.
9. Connect auxiliary features, if required.
1. Plan for proper electrical supply, drains and ductwork locations.
2. Install the Wall Plenum and Louver
1. Install the wall plenum.
Refer to instructions included in the wall plenum kit RAVWPT15 for proper installation procedures.
2. Install the louver.
Refer to instructions included in the louver kit RAVAL3 for proper installation procedures.
3. Install the Zoneline Drain Platform
1. Refer to instructions included with Drain Platform kit RAVDPLAT for proper installation procedure.
2. Place the platform in the utility closet with the following clearance between it and the interior surface of the
walls/door/panel:
• Front Installation–
– 3" minimum clearance from front of case and 3" minimum from two sides
• Side Installation–
– 5" minimum clearance from front of case, 3" minimum from access side and 3" minimum from two sides.
3. Complete rough in plumbing for primary and secondary condensation drains.
Condensate Disposal System
The Condensate Disposal System increases energy efficiency utilizing a factory installed fan that slings the
condensate onto the hot outdoor coil.
When high outdoor humidity prevents the slinger from disposing of all condensate, the excess condensate
overflows into the condensate drain pan and out the 3/4" internal drain connections.
NOTE: If the condensate disposal system fails to remove all of the condensate from the unit, any
excess condensate will overflow from the drain pan into the secondary drain (if connected), and drain
outside the building. This is your indication that the chassis or drain requires servicing.
18
INSTALLATION SUMMARY
INSTALLATION INSTRUCTIONS
10. Make electrical connections to unit.
11. Install front panel with filter.
12. Install air return grille or access cover.
13. Review the final installation checklist.
14. Turn power on.
15. Program auxiliary control settings, if required.
16. Check operation of the unit.
