ADTRAN Total Access 1100F Specification Sheet

Product Features

I Sealed GR-487 compliant unit
I Dual Optical GigE Network
feeds
I Networks with Total Access
1124 or 1148 DSLAM for fiber
deployment
7 Gbps switching capacity
I
I Easily configurable for both
electrical and optical expan-
sion interfaces
I Priority Queuing (802.1p)
I Integrated Security Support
Replication of Multicast Traffic
I
I Supports IEEE 802.1Q-in-Q
VLAN Tagging
I Compact size
(8"W x 9"H x 3"D)
I Line power from CO using 1 to
4 powering pairs – requires no
AC or battery backup
I Line powering can extend to
60,000 feet
I Local powering –48 VDC and
110 VAC options
Remotely provisioned and
I
managed through TL1, Telnet,
SNMP, or Total Access EMS;
saves truck dispatch cost
Passively cooled, no fan or
I
filter required
Total Access 1100F
Outside Plant Fiber and Ethernet Aggregation unit
The key to customer retention and contin-
ued revenue growth is to offer new, higher
bandwidth services to your customers. The
®
Total Access 1100F offers higher bandwith
delivery and cost improvement for next gen-
eration services
.
The Total Access 1100F is an Outside Plant
hardened Ethernet aggregation unit. It serves
up to four Total Access 1100 Series OSP
DSLAMs, logically combining them into a sin-
gle, high-bandwidth Ethernet/IP DSLAM. The
Total Access 1100F provides the high band-
width uplinks, Ethernet aggregation func-
tions, fiber and copper system interconnects,
and video enabling functions like IGMP proxy
and replication multicast. Additionally, it pro-
vides an array of security features needed to
enable and protect triple play service delivery
through Total Access 1100 Series OSP
DSLAMs. Carriers can deploy Total Access
1100 Series OSP DSLAMs today and migrate
to triple play service delivery with the simple
addition of the Total Access 1100F.
The Total Access 1100F is enclosed in an
environmentally sealed housing that is fully
OSP compliant. A single unit will support up
to four Total Access 1100 Series OSP DSLAMs
for a total subscriber density of up to 192
ports. Dual GigE network uplinks are
provided to interface the core switch/router.
Six SFPs within the 1100F case support a wide
variety of SFP plug-in modules for deploy-
ment flexibility.
The Total Access 1100F provides VLAN
tagging in accordance with IEEE 802.1Q spec-
ifications and prioritizes traffic based on IEEE
802.1p bits of the VLAN tag. Access technolo-
gies supported include ADSL, ADSL2, ADSL2+
and VDSL2 through appropriate Total Access
1100 Series OSP DSLAMs.
The Total Access 1100F and associated
Total Access 1100 Series OSP DSLAMs are
managed as a single unit either through a
local interface on the Total Access 1100F or
remotely through TELNET or SNMP. The OSP
DSLAM is fully supported by the Total Access
EMS, with remote management communica-
tion accomplished through SNMP. ADTRAN's
Total Access EMS provides comprehensive
management for ADTRAN's complete DSLAM
product line.
