ADTRAN Total Access 900 Series Quick Start

Quick Start
G S
ETTING TARTED
This Total Access unit ships with a statically assigned IP address of 10.10.10.1 and the ability to connect to a
Dynamic Host Control Protocol (DHCP) network and receive an IP address assignment from a DHCP server.
When connecting to a DHCP network, this device supports Zero-Touch Provisioning, allowing the Total Access
unit to download and apply configuration parameters from a configuration management server.
Regardless of the method you use to connect the Total Access unit to the network, there are two methods
available for configuration:
■ Web-based graphical user interface (GUI)
■ ADTRAN Operating System (AOS) command line interface (CLI)
The GUI lets you configure the main unit settings and provides online guidance and explanations for each
setting. However, using the AOS CLI may be necessary for more advanced configurations.
A
CCESS THE
You may access the GUI from a web browser in one of two ways:
Connect via the Static Address
1. Connect the Total Access unit to your PC using the port labeled ETH 0/1 on the back of the unit.
2. Set your PC to a fixed IP address of 10.10.10.2. To change your PC IP address, navigate to Computer
> Control Panel > Network Connections > Local Area Connection > Properties > IP (TCP/IP) and
select Use this IP Address. Enter these parameters:
IP Address: 10.10.10.2
Subnet Mask: 255.255.255.0
Default Gateway: 10.10.10.1
You do not need to enter any DNS server information. After the information is entered, select Ok twice,
and close the Network Connections dialog box. If you cannot change the PC's IP address, you will need
to change the unit's IP address using the CLI. (Refer to
page 2.)
3. Open a web browser and enter the unit's IP address in your browser address line as follows:
http://10.10.10.1. The default IP address is 10.10.10.1, but if you had to change the unit's IP address
using the CLI, enter that address in the browser line.
4. The initial GUI screen appears.
Connect via the DHCP Client Address
1. Connect the Total Access unit to an existing network that supports DHCP using the port labeled
ETH 0/1 on the back of the device. The NetVanta unit will automatically request an IP address assign-
ment from the DHCP server.
2. Check the DHCP server and record the IP address assigned to the Total Access unit.
3. Open a web browser on any network PC that can route to the IP address recorded in Step 2 and enter
the Total Access unit's IP address.
4. The initial GUI screen appears.
A
CCESS THE
Access the AOS CLI via the console port or a Telnet or SSH session. To establish a console connection to the
Total Access via the port labeled CRAFT, you need the following items:
■ PC with VT100 terminal emulation software
■ Straight-through serial cable with a DB-9 (male) connector on one end and the appropriate interface for
your terminal or PC communication port on the other end.
61213908F1-13A
Total Access
Total Access 900 Series
(3rd Generation)
GUI
CLI
"Manually Configuring the Unit's IP Address"
September 2020
61213908F1-13A
P/N: 1213908F1
4213916F1
4213924F1/F2
on
1
