On-Screen Display Settings
The adjustments for screen settings are located in the on-screen
display and can be viewed in one of five available languages.
The on-screen Main Menu displays the following nine
functions:
Size and Position - Adjusts the width, height, and horizontal
and vertical position of the screen.
Geometry - Provides adjustments to correct pincushion,
pincushion balance, trapezoid, parallelogram, and tilt.
Overscan - Zooms out and enlarges the screen.
Light Sensor - When turned on, compensates for ambient
room lighting by automatically adjusting the monitor's
brightness and contrast settings.
Color - Adjusts screen color balance, beam landing, and
convergence.
Moire - Minimizes interference patterns that occasionally
appear on the screen.
Degauss - Corrects image distortion or color impurity
caused by external magnetic fields.
Input: DSub (BNC) - Select when using a 15-pin signal
cable and BNC connectors together. If you are using only
one of these cables/connectors, this function automatically
adjusts.
Language - Lists five languages available to display on-
screen menus.
Management - Allows On/Off selection of power saving
and display modes; displays monitor serial number, and
performs a Master Reset (Master Reset resets all display
modes to their original settings).
Factory Reset - Resets the operating display mode to its
factory setting.
Some functions will have up to three menu levels.
This monitor uses an aperture grille CRT for excellent screen
performance. At times the shadows of two small horizontal
lines may appear on the screen background. This is not a
defect. The wires are there to reduce susceptibility to
horizontal vibration.
User's Guide 1-9
