Wells MOD-227TDM Specifications

Built-in modular warmers (12”x 27” with automatic water fill)
Hide thumbs Also See for MOD-227TDM:
1
2
3
4

Advertisement

Quick Links

Download this manual
W
M
E L L S
A N U F A C T U R I N G
BUILT-IN MODULAR WARMERS
(12"x 27" WITH AUTOMATIC WATER FILL)
MOD-427TDM/AF
Wells 12" x 27" Built-in Modular Warmers with AutoFill easily meet your volume needs, designed
with 33% more capacity than the standard modular warmers. Water Fill System automatically maintains
water at the proper level in all pans at all times, enabling you to serve fresh hot food to every customer
throughout the day.
Features
• All models have the automatic water fill
system that maintains the proper water level
in each pan through the use of a water sensor
and solenoid valve.
• These warmers are able to accommodate four
1/3-size pans up to 6" deep in each well.
• Each well is one-piece, deep-drawn, stainless
steel construction for maximum strength
and durability.
• Fully insulated for greater efficiency.
• A one-inch diameter drain manifold (DM)
is provided with each warmer to allow for
a single drain connection at the left or right
front corner.
• Individual thermostats (T) with positive-off
position give these warmers maximum versatility
on each well.
• Wellslok allows for quick and easy installation in
stainless steel countertops.
• The MOD series warmers are designed for wet
operation only.
• The MOD series Warmers are Underwriters
Laboratories, Inc. LISTED and meet the National
Sanitation Foundation and Canadian standards.
• A one-year warranty against defects covers
parts and labor.
R
A
I
S
I
N

Specifications

Temperature Settings:
Weights:
MOD-227 series:
MOD-327 series:
MOD-427 series:
MOD-527 series:
Accessories / Options
G
T
H
E
I T E M N O .
OFF/LO to HI
Installed
Shipping
Installed
Shipping
Installed
Shipping
Installed
Shipping
Wellslok Extension Kit, designed for installation in a
variety of countertops up to 1" thick, refer to installation
instructions, 22593
Drain Screen, 21709
Optional 72" Wiring, thermostatically
controlled warmers, priced per well
(standard length is 24")
S
T
A
N
D
Lbs.
KG
49
22
65
29
71
32
90
41
97
44
112
51
116
53
136
62
WELLS
A
R
D

Advertisement

loading

Related Manuals for Wells MOD-227TDM

Summary of Contents for Wells MOD-227TDM

  • Page 1: Specifications

    (12”x 27” WITH AUTOMATIC WATER FILL) MOD-427TDM/AF Wells 12” x 27” Built-in Modular Warmers with AutoFill easily meet your volume needs, designed with 33% more capacity than the standard modular warmers. Water Fill System automatically maintains water at the proper level in all pans at all times, enabling you to serve fresh hot food to every customer throughout the day.
  • Page 2 M O D - 2 2 7 T D M / A F E L E C T R I C A L S P E C I F I C AT I O N S : VOLTS WATTS AMPS PER LINE PHASE 3 AMPS SINGLE MODELS MOD-227TDM/AF 2480 MOD-227TDM/AF 3300 NOTE: Specifications are subject to change without notice.
  • Page 3 E L L S A N U F A C T U R I N G LISTED STD.4 E6070 E6070 D I M E N S I O N S : INCH (MM) (356) 2 1/4 (57) 1/4'' FPT WATER LINE CONNECTION 43 1/2 (1105)
  • Page 4 E L L S A N U F A C T U R I N G LISTED STD.4 E6070 E6070 D I M E N S I O N S : INCH (MM) (356) 2 1/4 (57) 1/4'' FPT WATER LINE 57 1/2 CONNECTION (1461)

This manual is also suitable for:

Mod-227tdm/afMod-327tdmMod-327tdm/afMod-427tdmMod-427tdm/afMod-527tdm ... Show all
