RF and baseband. Fig 3.1 Block diagram of RF part A generic, high-level functional block diagram of L705iX is shown in Figure 3.1-1. One antenna collects base station forward link signals and radiates handset reverse link signals. The antenna connects with receive and transmit paths through a Diplexer.
Page 15
ISDB-T 1seg receive path include an LNA, Mixer, IF Part and OFDM demodulator which are accommodated in ENT34606 IC. L705iX power supply voltages are managed and regulated by the PM6650 Power Management IC. This versatile device integrates all wireless handset power management, general housekeeping, and user interface support functions into a single mixed signal IC.
■ Insertion loss : This component is also in the receive and transmit paths; In the L705iX typical losses : UMTS2100_ Tx = 1.5dB, UMTS2100_ Rx = 1.8dB and UMTS800_ Tx =1.5dB, UMTS800_ Rx = 2.4dB ■ Out-of-band rejection or attenuation : The duplexer provides input selectivity for the receiver, output filtering for the transmitter, and isolation between the two.
Page 46
GP1_DRV_N(MPP7) Figure.3.11.3 Schematic of USB block(MSM6280Side & PM6650 Side) L705iX has a protective circuit for non-booting from USB. When the phone is booted from USB_VBUS without Battery, booting current might be insufficient. Sometimes, this scheme can break the USB port on a computer.
4. TROUBLE SHOOTING 4.7 USB USB Initial sequence of L705iX is : USB connected to L705iX power on → USB_VBUS(Q301 PIN4) go to 5V → USB_D+ go to 3.3V (D300 PIN1) → USB_VP and USB_VN is triggered → USB work. Start...
LGMDP is designed to be simple to use and easy enough for the beginner to upload executable images to the handset. LGMDP supports Windows 2000/XP where the LG USB modem driver is installed. Additionally, LGMDP allows multi downloading up to 8 handsets at the same time.
