TKD 1481 / TKD 1491 / TKD 1500

Advertisement

Table of Contents
loading

Related Manuals for Teka TKD 1481

Summary of Contents for Teka TKD 1481

  • Page 1 TKD 1481 / TKD 1491 / TKD 1500...

  • Page 2: Table Of Contents

    CONTENTS SAFETY INSTRUCTIONS Safety Instructions ..........INSTALLATION Product Description ..........Installation ............OPERATION Quick Start ............. Before Each Washing ..........Detergent Dispenser ..........Control Panel ............Programmes............Option..............MAINTENANCE Cleaning and Care ..........Trouble Shooting ............ Technical Specifications ......... Product Fiche ............

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Safety Instructions Please read the following safety information thoroughly and follow it strictly to minimize the risk of fire or explosion, electric shock and to prevent property damage, personal injury or loss of life. Failing to follow these instructions shall void any warranty. ！...
  • Page 4 SAFETY INSTRUCTIONS •The appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 5: Installation

    SAFETY INSTRUCTIONS •Do not operate the machine in rooms with a temperature of below 5°C. This can cause damages to parts of it. If it is unavoidable, make sure to drain the water completely from the appliance after every use (see “Maintenance - Cleaning of drain pump filter“) to avoid damages caused by frost.
  • Page 6 SAFETY INSTRUCTIONS •Water and electrical connections must be carried out by a qualified technician in accordance with the manufacturer‘s instructions and local safety regulations. ！ Warning! •Don´t use multiple plugs or extension cords. •The appliance must not have an external switching device such as a timer or connected to a circuit that is regularly switched on and off.
  • Page 7 SAFETY INSTRUCTIONS OPERATION AND MAINTENANCE •Never use any flammable, explosive or toxic solvents. Do not use gasoline and alcohol etc. as detergents. Only select detergents that are suitable for machine washing. •Make sure that all pockets are emptied. Sharp and rigid items such as coins, brooches, nails, screws, stones etc.
  • Page 8 SAFETY INSTRUCTIONS •Always unplug the appliance and close the water tap before cleaning and maintenance and after each use. •Never pour water over the appliance for cleaning purpose. Risk of electric shock! •Repairs shall only be carried out by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Page 9 SAFETY INSTRUCTIONS Packaging/Old appliance This marking indicates that this product should not be disposed with other household wastes throughout the EU.To prevent possible harm to the environment or human health from uncontrolled waste disposal,recycle it responsibly to promote the sustainable reuse of material resources.To return your used device, please use the collection systems or contact the retailer where the product was purchased.

  • Page 10: Product Description

    INSTALLATION Product Description Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Door Service flap Drain hose Note! • The product picture is for illustration only, please refer to real product as reference. Accessories 4 x Cover caps 1 x Owner’s manual 1 x Supply hose cold water...

  • Page 11: Installation

    INSTALLATION Installation Installation area ！ Warning! • Stability is important to prevent the product from wandering! Make sure the machine is standing leveled and stable. • Make sure that the product does not stand onto the power cord. W> 20mm •...
  • Page 12 INSTALLATION Remove transport bolts ！ Warning! • You must remove the transport bolts from the backside before using the product. Loosen the 4 transport Remove the bolts Close the holes using the bolts with a spanner. including the rubber parts cover caps.
  • Page 13 INSTALLATION Drain Hose ！ ！ Warning! Warning! • Do not kink or protract the drain hose. • Position drain hose properly ,otherwise damage might result of water leakage. There are two ways to place the end of drain hose: 1.Put it into the water trough. 2.Connect it to the branch drain pipe of the trough.

  • Page 14: Operation

    OPERATION Quick Start Caution! • Before washing, please make sure the washing machine is installed properly. • Your appliance was thoroughly checked before it left the factory. To remove any residual water and to neutralize potential odors, it’s recommended to clean your appliance before first use.
  • Page 15 OPERATION 1. Before Washing earth terminal Main wash Softener Prewash Close door Plug in Open tap Load Add detergent Note! • Detergent need to be added in compartment I if the pre-wash function is selected. 2. Washing Select programme Select function or Power On Press remain default...

  • Page 16: Before Each Washing

    OPERATION Before Each Washing • The ambient temperature of the washing machine should be 5-40°C. If used under 0°C, the inlet valve and draining system may be damaged. If the machine is installed under freezing conditions, it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose can unfreeze before use.

  • Page 17: Detergent Dispenser

    OPERATION Detergent Dispenser Pre wash Main wash Softener Release button to pull out the dispenser Caution! • Detergent only need to be added in "compartment I “after selecting pre-wash function. Programme Programme Cotton Intensive ECO 40-60 Synthetic Delicate Baby Care Jeans Wool Sport Wear...
  • Page 18 OPERATION Detergent Recommendation Recommended washing Washing Wash cycles Type of laundry and textile detergent temp. Heavy-duty detergent with White laundry made from bleaching agents and 20/30 Cotton ECO 40-60 Mix, boil-proof cotton or linen optical brighteners 40/60 Jeans,Intensive Coloured laundry made Colour detergent without Cotton,ECO40-60,Mix, Cold/20/...

  • Page 19: Control Panel

    OPERATION Control Panel Model:TKD 1481/TKD 1491 1200 Press 3 sec to set My Cycle Note! • The chart is for reference only, Please refer to real product as standard. On/Off Start/Pause Product is switched On/Off. Press the button to start or pause the washing cycle.
  • Page 20 OPERATION Control Panel Model:TKD 1500 1500 1200 Press 3 sec to set My Cycle Note! • The chart is for reference only, Please refer to real product as standard. On/Off Start/Pause Product is switched On/Off. Press the button to start or pause the washing cycle.

  • Page 21: Programmes

    OPERATIONS Programmes Model:TKD 1481/TKD 1491/TKD 1500 Programme Load(kg) Default Time 10.0 8.0/9.0/10.0 Cotton 10.0 3:39 Synthetic 3:17 Baby Care 10.0 1:42 Jeans 10.0 1:35 10.0 1:20 10.0 1:01 ℃ 10.0 0:20 Rinse&Spin 10.0 0:12 Spin Only 10.0 3:48 Intensive 10.0...
  • Page 22 OPERATION Programmes TKD 1481 Cycle 20℃ 1:01 0.15 65% / 1000 Cotton(60℃） 3:44 1.498 53% / 1400 Intensive 3:48 1.100 70% / 800 1:20 0.75 70% / 800 Quick 15' 0:15 0.030 Cold 75% / 800 3:38 0.857 53%/1400 ECO 40-60 2:48 0.504...
  • Page 23 OPERATION Programmes TKD 1491 Cycle 20 ℃ 1:01 65% / 1000 Cotton(60℃） 3:44 1.603 53% / 1400 Intensive 3:48 1.205 70% / 800 1:20 70% / 800 Quick 15' 0:15 0.030 Cold 75% / 800 3:48 0.935 53%/1400 ECO 40-60 2:54 0.63 53%/1400...
  • Page 24 OPERATION Programmes TKD 1500 Cycle 20℃ 1:01 0.25 65% / 1000 Cotton(60℃） 10.0 3:44 1.708 53% / 1500 Intensive 10.0 3:48 1.305 70% / 800 10.0 1:20 0.85 70% / 800 Quick 15' 0:15 0.030 Cold 75% / 800 10.0 3:59 1.062 53%/1500...
  • Page 25 OPERATION Programmes Programmes are available according to the laundry type. Programmes Hard-wearing textiles, heat-resistant textiles made of cotton or Cotton linen. Wash synthetic articles, for example: shirts, coats, blending. Synthetic While washing the knitting textiles, detergent quantity shall be reduced due to its loose string construction and easily forming bubbles.
  • Page 26 OPERATION 1) The highest temperature reached by the laundry in the wash cycle for at least 5 minutes. 2) Residual moisture after the wash cycle in water content percent and the spin speed at which this was achieved. 3) The ECO 40-60 programme is able to clean normally soiled cotton laundry declared to be washable at 40°C or 60°C, together in the same cycle.
  • Page 27 OPERATION Option Default Default spin speed in rpm Temp.(℃) 1400 1500 Quick 15’ Cold Rapid 45' Sport Wear Wool Delicate ECO 40-60 1400 1500 Intensive Spin Only 1000 1000 Rinse & Spin 1000 1000 1000 1000 20℃ 1000 1000 Jeans Baby Care 1200 1200...
  • Page 28 OPERATION Delay Set the Delay function: 1. Select a programme; 2.Press the Delay button to choose the time(the delaying time is 0-24 H.); 3.Press [Start/Pause] to commence the delay operation Delay Setting time Start Choose the Programme Cancel the Delay function: Press the [Delay] button until the display be 0H.It should be pressed before starting the programme.
  • Page 29 OPERATION Reload This operation can be executed during the washing progress. When the drum is still rolling and there is large amount of water with high temperature in the drum. The state is unsafe and the door cannot be opened forcefully. To press Start/Pause for 3 sec.
  • Page 30 OPERATION Mute the buzzer Spin Temp. Choose the Programme Press the [Temp.]and[Spin] for 3sec., the buzzer is mute. To act the buzzer function, press the button again for 3 seconds. The setting will be kept until the next reset. Caution! •...

  • Page 31: Maintenance

    MAINTENANCE Cleaning and Care ！ Warning! • Always unplug the appliance and close the water tap before cleaning and maintenance. Cleaning the Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary.
  • Page 32 MAINTENANCE Cleaning the Inlet Filter Note! • Diminishing water flow is a sign that the filter need to be cleaned. 1. Close the tap and remove the water supply hose from it. 2. Clean the filter with a brush. 3. Unscrew the water supply hose from the backside of the machine.
  • Page 33 MAINTENANCE Cleaning the Drain Pump Filter Warning! • Make sure that the machine has finished the washing cycle and is empty. Switch it off and unplug it before cleaning the drain pump filter. • Be careful of hot water. Allow the water to cool down. Risk of scalding! •...

  • Page 34: Trouble Shooting

    MAINTENANCE Trouble Shooting Whenever there is a problem with the appliance, check if you can solve it following the tables below. If the problem persists, please contact the customer service. Description Possible cause Solution Appliance does Door is not closed properly. Close the door properly and not start Clothes are stuck.

  • Page 35: Technical Specifications

    • This appliance is heavy. Transport with care. Never hold any protruding part of the machine when lifting. The machine door cannot be used as a handle. Technical Specifications Power Supply 220-240V~,50Hz MAX.Current Standard Water Pressure 0.05MPa~1MPa 2000W TKD 1481 8.0kg 595*565*850 68kg 2000W TKD 1491 9.0kg 595*565*850 71kg...

  • Page 36: Product Fiche

    MAINTENANCE Product fiche concerning to EN 60456:2016 With (EU)No.1061/2010. TKD 1481 A+++ Intensive Intensive 0.82kwh Intensive 0.75kwh Intensive 0.73kwh 11000 Intensive 1400 Intensive Intensive Intensive 280min Intensive 270min Intensive 270min 1min 79dB 60/40 ℃; Energy test program: Intensive Speed: the highest speed; Other as the default.
  • Page 37 MAINTENANCE TKD 1481 10 24 10 36...
  • Page 38 MAINTENANCE Product fiche concerning to EN 60456:2016 With (EU)No.1061/2010. TKD 1491 A+++ Intensive Intensive 0.85kwh Intensive 0.71kwh Intensive 0.70kwh 11880 Intensive 1400 Intensive Intensive Intensive 270min Intensive 270min Intensive 265min 1min 79dB 60/40 ℃; Energy test program: Intensive Speed: the highest speed; Other as the default. 10 24 10 37...
  • Page 39 MAINTENANCE TKD 1491 10 24 10 38...
  • Page 40 MAINTENANCE Product fiche concerning to EN 60456:2016 With (EU)No.1061/2010. TKD 1500 A+++ the standard cotton standard 60 ℃ cotton 0.80kwh standard 60 ℃ cotton 0.70kwh ℃ standard 40 cotton 0.68kwh 12980 the standard cotton 1500 Intensive Intensive the standard 60 ℃...
  • Page 41 MAINTENANCE TKD 1500 10 24 10 40...
  • Page 42 MAINTENANCE 1) The actual energy consumption will depend on how the appliance is used. 2) The actual water consumption will depend on how the appliance is used and on the hardness of the water. 3) Delivery of the spare parts within 15 working days after having received the order. Product Data Sheet concerning (EU) 2019/2014 The product data sheet for your appliance can be found online.
