Blodgett SB-10G Specifications

SB-G
Convection Steamer
on a Gas Fired Boiler Base
SB-6G shown
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Increased Input Options (SB-6G & SB-10G only)
200,000 BTU for 24" or 36" bases
250,000 BTU for 36" bases
300,000 BTU for 36" bases
36" (914 mm) wide boiler base for SB-6G & SB-10G
Stainless steel rear panel
Correctional package
Steam take off kit
Water in "Y" strainer
Stainless steel frame
Load compensation timer
One year extended warranty
CAPACITY
Model SB-6G is comprised of two 3 pan compartments
Model SB-10G is comprised of two 5 pan compartments
Model SB-16G is comprised of two 8 pan compartments
44 Lakeside Avenue, Burlington, VT 05401 • Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183 • www.blodgett.com
Project
Item No.
Quantity
Model SB-6G (6 pan convection steamer on a 24" gas boiler base)
Model SB-10G (10 pan convection steamer on a 24" gas boiler base)
Model SB-16G (16 pan convection steamer on a 36" gas boiler base)
STEAMER CONSTRUCTION
#4 Satin finish 304 stainless steel
Welded stainless steel door with removable inner stainless steel liner
Full perimeter door gasket
Positive lock and seam mechanism with spring release on door
Stainless steel control housing
One piece welded 316 stainless steel cooking chamber
Coved corners
Stainless steel pan supports
Stainless steel drip trough integrally connected to drain
STEAMER OPERATION
Separate controls for each compartment
Control panel accessible through removable side panel
Ready and Cooking indicator lights
60 minute electric timer with audible alarm to signal end of cook cycle
Steam flow to the cooking chamber is cut off when the door is opened during
the cooking cycle and reactivated when the door is closed
BOILER BASE CONSTRUCTION
Full perimeter painted angle iron frame
Reinforced steamer and boiler mountings
Stainless steel exterior
Hinged door(s) with magnetic latch
6" (152 mm) stainless steel legs with adjustable bullet feet on front and
adjustable flanged feet on rear for securing to floor
BOILER BASE OPERATION
Automatic water level control
Automatic boiler blowdown
On/off power switch with indicator light
Pressure and Water gauges
Pressure control with pressure safety control
Safety relief valve
Cathodic protector
CSD-1 secondary low water cut off
STANDARD FEATURES
115 VAC, 1 phase, 60 Hz
140,000 BTU - SB-6G
200,000 BTU - SB-10G
300,000 BTU - SB-16G
Electromechanical controls
Electronic ignition
Split water lines
Startup inspection service by factory authorized service agent
One year parts and labor steamer warranty*
Five year limited steamer door warranty*
* For all international markets, contact your local distributor.
