Repair
Kits for HVLP Sprayers
For repair of components in HVLP sprayers.
Important Safety Instructions
Read all warnings and instructions in your sprayer and gun manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Related Manuals:
3A4967
FinishPro HVLP Sprayer
3A4980
HVLP Edge II/Edge II Plus Gun
Section
Turbine Repair, page 4
Control Board Repair,
page 6
Potentiometer Repair,
page 8
Compressor Repair
(ProComp Models
only), page 11
120VAC, 7.0 Models,
120VAC, 9.0 Models
120VAC, 9.5 Models
230VAC, 7.0 Models
230VAC, 9.0 Models
230VAC, 9.5 Models
120VAC, Standard Models
120VAC, ProContractor/ProComp Models
230VAC, Standard Models
230VAC, ProContractor/ProComp Models
Standard Models
ProContractor/ProComp Models
120VAC Models
230VAC Models
Description
3A5024B
EN
Kit #
17R936
17R937
17R938
17R939
17R940
17R941
17R942
17R943
17R944
17R945
17R946
17R948
17R962
17R964
Advertisement
Table of Contents
Related Manuals for Graco 17R936
Summary of Contents for Graco 17R936
- Page 1 Related Manuals: 3A4967 FinishPro HVLP Sprayer 3A4980 HVLP Edge II/Edge II Plus Gun Section Description Kit # 120VAC, 7.0 Models, 17R936 120VAC, 9.0 Models 17R937 120VAC, 9.5 Models 17R938 Turbine Repair, page 4 230VAC, 7.0 Models 17R939 230VAC, 9.0 Models 17R940 230VAC, 9.5 Models...
-
Page 2: Electric Shock Hazard
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. -
Page 3: Pressure Relief Procedure
Pressure Relief Procedure Pressure Relief Procedure Follow Pressure Relief If using a FlexLiner System: Procedure whenever you see this Disconnect tubing from gun to relieve symbol. pressure in the cup. The spray gun cup is pressurized. To reduce the risk of splashing from pressurized fluid, always follow the Pressure Relief Procedure before removing cup. -
Page 4: Standard Models
Turbine Repair Turbine Repair Standard Models Disconnect the motor leads from the control board (20). Remove the 3 turbine mounting bolts (13) and spacers (9 & 11). Remove the turbine assembly (12). NOTICE 10. Remove plate (10) and gasket (8). Use blue thread locker provided in turbine 11. - Page 5 Turbine Repair ProContractor & ProComp Loosen two mounting nuts (83) on the inner panel (15). Models Remove the three turbine mounting bolts (13) and spacers (9 & 11) (Some models only have a single spacer). 10. Remove the turbine assembly (12). Remove the mounting plate (10) and NOTICE gasket (8).
- Page 6 Control Board Repair Control Board Repair Standard Models Installation: Install new control board (20) using four screws (21). Torque to 15-20 in-lbs (1.7 - 2.3 N•m). Connect control board leads to the Refer to the Parts List - Standard Models, power switch (36) and power cord page 13.
- Page 7 Control Board Repair ProContractor & ProComp Peel off the paper backing and place sticky side of foam gasket (88) onto the Models TurboControl LED (20a). Install mounting screws (21) to top cover (31). Torque to 15-20 in-lbs (1.7 - 2.3 N•m). Route ribbon cable from TurboControl LED (20a), wires from potentiometer Refer to the Parts List - ProContractor...
- Page 8 Potentiometer Repair Potentiometer Repair Standard Models Rotate the shaft of the potentiometer (45) clockwise as far as it can go. Slide the knob (37) over the shaft and align the pointer to the maximum setting on the control label (35). While applying a light pressure to the knob (37), tighten the two set screws to 3-5 in-lb (0.3 - 0.6 N•m).
- Page 9 Potentiometer Repair ProContractor & ProComp Remove eleven screws (16) and the top cover (31). Models NOTE: Be cautious not to damage the wires that connect to the cover.. Remove mounting nut and washer of potentiometer (45) from the top cover (31).
- Page 10 Potentiometer Repair Installation: Fig. 3 Route the wire from the new potentiometer (47) through the foam gasket (90). Connect potentiometer (47) to the control board (20). Refer to Wiring Diagrams (ProContractor), page 19 and Wiring Diagrams (ProComp), page 20. For ProComp models, wrap the foam gasket (91) around the wire bundle to protect against damage from the compressor power switch (77).
-
Page 11: Compressor Repair
Compressor Repair (ProComp Models only) Compressor Repair (ProComp Models only) Installation: Install wire-tap connectors onto the new compressor (78) leads. For proper location, reference the compressor that Refer to the Parts List - ProComp Models, was removed and the Wiring Diagrams page 17. - Page 12 Parts Parts Ref. Torque 110-115 in-lb (12.5 - 13.0 N•m) Standard Models 20--25 in-lb (2.5 - 3.0 N•m) 15-20 in-lb (1.7 - 2.3 N•m) 10-15 in-lb (1.1 - 1.7 N•m) 35-40 in-lb (4.0 - 4.5 N•m) 3A5024B...
-
Page 13: Parts List - Standard Models
17U103 Model 17T980 17N375 9.0 Standard 120660 SWITCH, rocker KIT, repair, turbine (includes 6, 7, 8, 9, 10, 11, 13, 14, 18) 17N957 KNOB, potentiometer 17R936 Model 17N263, 17T980, CIRCUIT, breaker 17U105 114403 120V Models 17R937 Model 17N264 16A348 230V Models... -
Page 14: Procontractor Models
Parts Parts Ref. Torque 110-115 in-lb (12.5 - 13.0 N•m) ProContractor Models 20--25 in-lb (2.5 - 3.0 N•m) 15-20 in-lb (1.7 - 2.3 N•m) 10-15 in-lb (1.1 - 1.7 N•m) 35-40 in-lb (4.0 - 4.5 N•m) 3A5024B... -
Page 15: Parts List - Procontractor Models
17N377 9.5 ProContractor 17N930 DRAWER, tool KIT, repair, turbine (includes 6, 7, 8, 9, 10, 11, 13, 14, 17a) 44* 17R298 FILTER, air, turbine 17R936 Model 17N265 17P447 HOLDER, gun 17R937 Model 17N266 17R948 POTENTIOMETER, assy (includes 21, 37, 88, 90, 93) 17R938 Model 17N267, 17T982 61... -
Page 16: Procomp Models
Parts Parts Ref. Torque 110-115 in-lb (12.5 - 13.0 N•m) ProComp Models 20--25 in-lb (2.5 - 3.0 N•m) 15-20 in-lb (1.7 - 2.3 N•m) 10-15 in-lb (1.1 - 1.7 N•m) 35-40 in-lb (4.0 - 4.5 N•m) 5-8 in-lb (0.5 - 0.9 N•m) 20-23 ft-lb (28.0 - 31.0 N•m) 3A5024B... -
Page 17: Parts List - Procomp Models
Parts List - ProComp Models Parts List - ProComp Models Ref. Part Description Ref. Part Description 114689 BUSHING, strain relief 17R057 BOX, bottom, painted 40* 17R298 FILTER, air, motor 129604 GROMMET, rubber 17N467 COVER, filter 113817 BUMPER 129666 SCREW, mach 100057 SCREW, cap, hex hd 17N930 DRAWER, tool 111040 NUT, lock, insert, nylock, 5/16... -
Page 18: Wiring Diagrams (Standard)
Wiring Diagrams (Standard) Wiring Diagrams (Standard) 120V WIRING DIAGRAM BLACK POWER INLET BLACK GROUND GREEN / YELLOW TURBINE WHITE WHITE CONTROL BOARD CIRCUIT BREAKER BLACK BLACK POTENTIOMETER SWITCH 230V WIRING DIAGRAM BROWN BLUE POWER INLET TURBINE GROUND GREEN / YELLOW BROWN WHITE BLUE... -
Page 19: Wiring Diagrams (Procontractor)
Wiring Diagrams (ProContractor) Wiring Diagrams (ProContractor) 120V WIRING DIAGRAM BARRIER TURBINE BLACK WALL POWER BLACK INLET GREEN / YELLOW WHITE WHITE CIRCUIT YELLOW THERMISTOR BLACK BREAKER SWITCH PURPLE RIBBON GRAY GREEN CONTROL BOARD POTENTIOMETER BLACK POTENTIOMETER HARNESS PURPLE GRAY GREEN RIBBON 120V UK &... -
Page 20: Wiring Diagrams (Procomp)
Wiring Diagrams (ProComp) Wiring Diagrams (ProComp) 120V WIRING DIAGRAM BARRIER WHITE-COMPRESSOR WALL TURBINE BLACK POWER BLACK INLET CIRCUIT BREAKER GROUND GREEN / YELLOW WHITE WHITE THERMISTOR YELLOW BLACK BLACK SWITCH PURPLE RIBBON GRAY CONTROL GREEN BOARD POTENTIOMETER BLACK POTENTIOMETER HARNESS PURPLE GRAY GREEN... -
Page 21: Graco Information
Graco Information Graco Information For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. 3A5024B... - Page 22 Original instructions. This manual contains English. MM 3A5024 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2014, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
