31MEG7100
2015 Shadow Aero (VT750C)
P. 2
P. 16
P. 30
P. 76
P. 99
P. 120
P. 124
MOM 15084 (1407)

Advertisement

Table of Contents
loading

Related Manuals for Honda Shadow Aero 2015

Summary of Contents for Honda Shadow Aero 2015

  • Page 1: Table Of Contents

    Contents Motorcycle Safety P. 2 Operation Guide P. 16 Maintenance P. 30 Troubleshooting P. 76 Information P. 99 Specifications P. 120 Index P. 124 2015 Shadow Aero (VT750C) MOM 15084 (1407) 31MEG7100...
  • Page 2 Honda dealer knows your motorcycle Honda motorcycle. Your selection of a best. If you have the required mechanical Honda makes you part of a worldwide family “know-how” and tools, you can purchase an of satisfied customers who appreciate official Honda Service Manual to help you Honda’s reputation for building quality into...

  • Page 3: Motorcycle Safety

    A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this motorcycle safely is You WILL be KILLED or SERIOUSLY an important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...
  • Page 4 Motorcycle Safety This section contains important information for safe riding of your motorcycle. Please read this section carefully. Safety Guidelines .........P. 3 Safety Labels ..........P. 7 Safety Precautions ........P. 9 Riding Precautions ........P. 10 Accessories & Modifications......P. 13 Loading ............P. 14...

  • Page 5: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you and your passenger are both wearing specified in this manual.
  • Page 6 Safety Guidelines We recommend that all riders take a certified Make Yourself Easy to See course approved by the Motorcycle Safety Make yourself more visible, especially at night, Foundation (MSF). New riders should start with by wearing bright reflective clothing, the basic course, and even experienced riders positioning yourself so other drivers can see will find the advanced course beneficial.
  • Page 7 Safety Guidelines check the tightness of critical nuts and bolts, Keep Your Honda in Safe Condition and check the handlebar, control levers, brakes, It’s important to keep your motorcycle properly and wheels. Ride slowly and cautiously. maintained and in safe riding condition.
  • Page 8 Safety Guidelines Carbon Monoxide Hazard Exhaust contains poisonous carbon monoxide, a colorless, odorless gas. Breathing carbon monoxide can cause loss of consciousness and may lead to death. If you run the engine in confined or even partly enclosed area, the air you breathe could contain a dangerous amount of carbon monoxide.

  • Page 9: Safety Labels

    Safety Labels Safety Labels hazards that could cause serious injury. Read these labels carefully and don’t remove them. Safety and information labels on your If a label comes off or becomes hard to read, motorcycle provide important safety contact your dealer for a replacement. information and may warn you of potential continued...
  • Page 10 Safety Labels...

  • Page 11: Safety Precautions

    Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the ● handlebar and feet on the footpegs. Look for a DOT (Department of Keep passenger’s hands on to the seat strap Transportation) certification label on any helmet ●...

  • Page 12: Riding Precautions

    Riding Precautions ❙ Riding Precautions Boots or Riding Shoes Sturdy boots with non-slip soles and ankle protection Break-in Period ❙ During the first 300 miles (500 km) of running, Jacket and Pants follow these guidelines to ensure your Protective, highly visible, long-sleeved jacket motorcycle’s future reliability and performance.
  • Page 13 Riding Precautions ❙ Exercise caution on low traction surfaces. Combined ABS (VT750CS only) ● The tires slip more easily on such surfaces Your motorcycle’s rear brake system is linked to and braking distances are longer. the front brake. This means that operating the Avoid continuous braking.
  • Page 14 Riding Precautions ❙ Engine Braking Make sure that high-temperature parts ● Engine braking helps slow your motorcycle cannot come into contact with flammable down when you release the throttle. For further materials. slowing action, downshift to a lower gear. Use Do not touch the engine, muffler, brakes and ●...

  • Page 15: Accessories & Modifications

    Use only unleaded gasoline. ● accessories that were not specifically designed Use recommended octane number. Using or approved for your motorcycle by Honda or ● lower octane gasoline will result in decreased make modifications to your motorcycle from its engine performance.

  • Page 16: Loading

    Loading Loading WARNING Carrying extra weight affects your ● Improper accessories or modifications motorcycle’s handling, braking and stability. can cause a crash in which you can be Always ride at a safe speed for the load you seriously hurt or killed. are carrying.

  • Page 17: Operation Guide

    Parts Location Rear brake fluid reservoir (VT750CS) (P59) Main fuse (VT750C) (P96) Fuse box (VT750C) (P95) Front brake fluid reservoir (P59) Front brake lever (P59) Fuel fill cap (P27) Throttle grip (P73) Air cleaner (P71) Crankcase breather tube (P72) Engine oil fill cap/dipstick (P53) Engine oil drain bolt (P55)
  • Page 18 Clutch lever (P65) Battery (P50) Main fuse (VT750CS) (P98) Fuse box (VT750CS) (P97) FI fuse (VT750CS) (P98) Seat (P48) Rear suspension spring preload adjuster (P74) Final drive oil fill hole cap (P69) Final drive oil drain bolt (P70) Side stand (P68) Shift lever (P26)
  • Page 19 Instruments Odometer [ODO], Tripmeter [TRIP 1/2] & Clock Select/Reset button switches between odometer, tripmeters & clock. • Odometer: Total distance ridden. • Tripmeter: Distance ridden since tripmeter was reset (press and hold Select/Reset button to reset to 0.0 mile/km). Odometer Select/Reset button Tripmeters Clock...
  • Page 20 To set the clock: Press the Select/Reset button until the desired minute is displayed. Turn the ignition switch on. Select the digital clock mode. Press and hold the Select/Reset button until Press and hold the Select/Reset button until the hour digits start flashing. the display stops flashing.
  • Page 21 Indicators ABS (Anti-lock Brake System) indicator (VT750CS) Comes on when the ignition switch is turned on. Goes off when your speed reaches approximately 6 mph (10 km/h). If it comes on while riding: (P80) PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned on with the engine stop switch in the (Run) position.
  • Page 22 Fuel reserve indicator When this indicator comes on, remaining fuel approximately 0.92 US gal (3.5 liters) Turn signal indicator High beam indicator Neutral indicator Comes on when the transmission is in Neutral.
  • Page 23 Switches Engine stop switch Should normally remain in the (Run) position. In an emergency, switch to the (Off) position (the starter motor will not operate) to stop the engine. Horn button Start button Turn signal switch Headlight turns off when operating the Pressing the switch turns the starter motor.
  • Page 24 Ignition Switch Turns electrical system Switches the electrical system on/off. on for starting/riding. Key can be removed when in the OFF position. Turns engine off. Steering Lock ❙ Lock the steering when parking to help Locking prevent theft. Turn the handlebars all the way to the left. A U-shaped wheel lock or similar device is Insert the key in the steering lock and turn it also recommended.
  • Page 25 Starting the Engine Start your engine using the following NOTICE procedure, regardless of whether the engine • If the engine does not start within 5 seconds, turn the is cold or warm. ignition off and wait 10 seconds before trying to start the engine again to recover battery voltage.
  • Page 26 If the engine does not start: Open the throttle fully and press the start button for 5 seconds. Repeat the normal starting procedure. If the engine starts, open the throttle slightly if idling is unstable. If the engine does not start, wait 10 seconds before trying steps &...
  • Page 27 Shifting Gears ❙ Your motorcycle transmission has 5 forward Recommended Shift Points gears in a one-down, four-up shift pattern. Shifting Up From 1st to 2nd 12 mph (20 km/h) From 2nd to 3rd 19 mph (30 km/h) From 3rd to 4th 25 mph (40 km/h) From 4th to 5th 31 mph (50 km/h)
  • Page 28 Refueling Opening the Fuel Fill Cap Lock cover Open the lock cover, insert the ignition key, Fuel fill cap and turn it clockwise to open the fuel fill cap. Ignition key Lower edge of Closing the Fuel Fill Cap filler neck After refueling, align the fuel cap latch with the slot in the filler neck.
  • Page 29 Storage Equipment Helmet holder is located on the left side WARNING below the seat. Riding with a helmet attached to the Helmet holder holder can interfere with the rear wheel or suspension and could cause a crash in which you can be seriously hurt or killed.
  • Page 30 Space to store a document bag is located The tool kit is in the compartment box under the seat. behind the left side cover. (VT750C) Document bag Tool kit Ignition key Insert the ignition key and turn it counterclockwise to unlock. (VT750CS) Tool kit ❙...

  • Page 31: Maintenance

    Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. An optional larger tool kit may be available. Check with your Honda dealer’s parts department. Importance of Maintenance ......P. 31 Final Drive Oil ..........P. 69 Maintenance Schedule.......P.

  • Page 32: Importance Of Maintenance

    Importance of Maintenance For information about the exhaust emission and Importance of Maintenance noise emission requirements of the U.S. Keeping your motorcycle well-maintained is Environmental Protection Agency (EPA), the absolutely essential to your safety and to California Air Resources Board (CARB), and protect your investment, obtain maximum Environment Canada (EC).
  • Page 33 Importance of Maintenance Maintenance Safety Always read the maintenance instructions before you begin each task, and make sure that you have the tools, parts, and skills required. We cannot warn you of every conceivable hazard that can arise in performing maintenance.

  • Page 34: Maintenance Schedule

    Honda’s standards and specifications by properly trained and Honda recommends that your dealer should equipped technicians. Your dealer meets all road test your motorcycle after each periodic of these requirements. Keep an accurate maintenance is carried out.
  • Page 35 Evaporative Emission Control – System* Maintenance Level : Intermediate. We recommend service by your Honda dealer, : Technical. In the interest of safety, have your motorcycle unless you have the necessary tools and are mechanically serviced by your dealer. skilled. Procedures are provided in an official Honda Service Manual ( 115).
  • Page 36 Maintenance Schedule Frequency Odometer Reading* × 1,000 mi Refer to page Items × 1,000 km 12.8 19.2 25.6 32.0 38.4 Final Drive Oil Brake Fluid* Brake Shoe/Pad Wear VT750C Brake Pad Wear VT750CS Brake System Brake Light Switch Headlight Aim Clutch System Side Stand Suspension...

  • Page 37: Maintenance Fundamentals

    Maintenance Fundamentals Brakes (VT750C)-Check operation; ● Pre-ride Inspection Front: check brake fluid level ( 59) and To ensure safety, it is your responsibility to pads wear. P. 60 perform a pre-ride inspection and make sure Rear: check shoes wear ( 64) and freeplay that any problem you find is corrected.
  • Page 38 Maintenance Fundamentals Periodic Checks You should also perform other periodic maintenance checks at least once a month regardless of how often you ride, or more often if you ride frequently. Also, check the odometer reading against the Maintenance Schedule and perform all maintenance that is due.
  • Page 39 Maintenance Fundamentals Replacing Parts Color label Always use Honda Genuine Parts or their equivalents to ensure reliability and safety. When ordering colored components, specify the model name, color, and code mentioned on the color label. The color label is attached to the frame behind the left side cover.
  • Page 40 Maintenance Fundamentals Electrolyte splashes into your mouth: ● Battery Rinse mouth thoroughly with water, and Your motorcycle has a maintenance-free type do not swallow. battery. You do not have to check the battery WARNING electrolyte level or add distilled water. Clean the battery terminals if they become dirty or The battery gives off explosive corroded.
  • Page 41 30 days using a charger designed specifically for 3. If the terminals are heavily corroded, clean your Honda, which can be purchased from your the terminals with a wire brush or sandpaper. dealer. Read the information that came with Wear safety glasses.
  • Page 42 Jump starting using an automobile battery can damage your motorcycle’s electrical system and is not recommended. Bump starting is also not recommended. NOTICE Installing non-Honda electrical accessories can overload the electrical system, discharging the battery and possibly NOTICE damaging the system.
  • Page 43 Use SG or higher oils, excluding oils marked as “Energy If you use non-Honda engine oil, check the label Conserving” or “Resource Conserving” on the to make sure that the oil satisfies all of the circular API service symbol.
  • Page 44 Recommended Coolant NOTICE Pro Honda HP coolant is a pre-mixed solution of Brake fluid can damage plastic and painted surfaces. antifreeze and distilled water. Wipe up spills immediately and wash thoroughly.
  • Page 45 Maintenance Fundamentals Air Cleaner Tires (Inspecting/Replacing) ❙ Checking the Air Pressure This motorcycle is equipped with a viscous type air cleaner element which cannot be cleaned Visually inspect your tires and use an air with compressed air or otherwise without pressure gauge to measure the air pressure at degrading its performance.
  • Page 46 Maintenance Fundamentals ❙ Inspecting for Abnormal Wear WARNING Inspect the tires for signs of abnormal Riding on tires that are excessively wear on the contact worn or improperly inflated can cause surface. a crash in which you can be seriously hurt or killed.
  • Page 47 Always use the size and type of tires Have the wheel balanced with Honda ● recommended in this owner’s manual. Genuine balance weights or equivalent after the tire is installed.
  • Page 48 Maintenance Fundamentals ❙ Tire Identification Number (TIN) Tire Service Life The tire identification number (TIN) is a group of The service life of your tires is dependent on numbers and letters located on the sidewall of many factors, including, but not limited to, the tire.

  • Page 49: Removing & Installing Body Components

    Removing & Installing Body Components ❙ Seat Installation 1. Insert the tab into the frame cross member. Seat mounting bolt A 2. Tighten the seat mounting bolts securely. Seat Frame cross member Seat mounting bolts B ❙ Removal 1. Remove the mounting bolt A and bolts B. 2.

  • Page 50: Side Cover

    Removing & Installing Body Components Side Cover Side Cover Grommets (VT750C) The right side cover must be removed for the fuse maintenance. The left side cover must be removed to access the storage compartment and check the color label. Side cover (VT750CS) Prongs The left side cover must be removed for the...

  • Page 51: Battery

    Removing & Installing Body Components Battery ❙ Battery Removal Make sure the ignition switch is off. VT750C 1. Remove the seat. P. 48 Screw 2. Remove the battery cover by removing the Battery screw. cover 3. Disconnect the negative terminal from the battery.

  • Page 52: Spark Plug

    Spark Plug Checking Spark Plug Spark plug cap For the recommended spark plug, see “Specifications.” P. 121 Use only the recommended type of spark plug in the recommended heat range. NOTICE Using spark plugs an improper heat range can cause engine damage.
  • Page 53 Spark Plug Checking Spark Plug 5. Check the spark plug gap using a wire- 8. Tighten the spark plug: type feeler gauge. If the old plug is good: ● If adjustment is necessary, bend the 1/8 turn after it seats side electrode carefully.

  • Page 54: Engine Oil

    Engine Oil Checking the Engine Oil Oil fill cap/ dipstick 1. If the engine is cold, idle the engine for 3 to 5 minutes. 2. Turn the ignition switch off, and wait for 2 Upper to 3 minutes. level 3. Remove the oil fill cap/dipstick and wipe it clean.
  • Page 55 Engine Oil Adding Engine Oil Adding Engine Oil 2. Securely reinstall the oil fill cap/dipstick. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient oil can level mark, add the recommended engine oil. cause damage to your engine.
  • Page 56 Changing Engine Oil & Filter Changing the oil and filter requires special tools. We recommend that you have your motorcycle serviced by your dealer. Use a new Honda Genuine oil filter or equivalent specified for your model. Sealing NOTICE washer...
  • Page 57 Engine Oil Changing Engine Oil & Filter 6. Remove the oil filter with a filter wrench 7. Apply a thin coat of engine oil to the and let the remaining oil drain out. Make rubber seal of a new oil filter. sure the prior seal is not stuck to the 8.

  • Page 58: Coolant

    Coolant Checking the Coolant If the coolant level is dropping noticeably or the reserve tank is empty, you likely have a 1. Place your motorcycle on a firm, level serious leak. Have your motorcycle inspected surface. by your dealer. 2. Hold your motorcycle in an upright ❙...
  • Page 59 Coolant Checking the Coolant ❙ Changing Coolant WARNING Have your dealer change the coolant unless Removing the radiator cap while the you have the proper tools and are engine is hot can cause the coolant to mechanically qualified. spray out, potentially scalding you. Always let the engine and radiator cool down before removing the radiator cap.

  • Page 60: Brakes/Clutch

    Brakes/Clutch Checking Brake Fluid If the brake fluid level in either reservoir is below the LOWER level mark or the brake 1. Place your motorcycle in an upright lever and pedal freeplay becomes excessive, position on a firm, level surface. inspect the brake pads for wear.
  • Page 61 Brakes/Clutch Inspecting the Brake Pads Inspecting the Brake Pads Inspect the brake pads from the Front bottom of the brake caliper. Check the condition of the brake pad wear Inspect the brake pads Rear (VT750CS) indicators. from the rear right of the motorcycle. The pads need to be replaced if a Front If necessary have the pads replaced by your...
  • Page 62 Brakes/Clutch Inspecting the Rear Brake Pedal Freeplay (VT750C only) Inspecting the Rear Brake Pedal Stopper Freeplay (VT750C only) bolt ❙ Pedal Height Adjustment Lock nut The stopper bolt is provided to allow adjustment of the pedal height. Freeplay 1. Loosen the lock nut and turn the stopper bolt.
  • Page 63 Brakes/Clutch Adjusting Rear Brake Pedal Freeplay (VT750C only) Adjusting Rear Brake Pedal Freeplay (VT750C only) Make sure the cut-out on the adjusting nut is seated on the brake arm pin when adjusting Decrease Brake the freeplay. Freeplay arm pin Adjusting nut Adjusting Brake arm pin Increase...
  • Page 64 Brakes/Clutch Adjusting Rear Brake Pedal Freeplay (VT750C only) 3. Push the brake arm to confirm that there NOTICE is a gap between the rear brake adjusting Do not turn the adjuster beyond its natural limits. nut and brake arm pin. Brake arm Push Brake...
  • Page 65 Brake arrow See your dealer for this service. panel When the brake service is necessary, see your dealer. Use only Honda Genuine Parts or its equivalent. Reference mark Brake...
  • Page 66 Brakes/Clutch Checking the Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary have it replaced by your ❙ Checking the Clutch Lever Freeplay dealer. Lubricate the clutch cable with a Check the clutch lever freeplay. commercially available cable lubricant to Freeplay at the clutch lever: prevent premature wear and corrosion.
  • Page 67 Brakes/Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Upper lock Freeplay – ❙ Upper Adjustment Attempt adjustment with the upper clutch cable adjuster first. 1. Loosen the upper lock nut. Upper clutch 2. Turn the upper clutch cable adjuster until cable adjuster the freeplay is 3/8 to 13/16 in (10 to 20 mm).
  • Page 68 Brakes/Clutch Adjusting the Clutch Lever Freeplay 1. Loosen the upper lock nut and turn the Lower adjusting nut upper clutch cable adjuster all the way in (to provide maximum freeplay). Tighten the upper lock nut. 2. Loosen the lower lock nut. 3.

  • Page 69: Side Stand

    Side Stand 5. Lower the side stand all the way. The Side stand engine should stop as you lower the side spring stand. If the engine doesn’t stop, have your motorcycle inspected by your dealer. 1. Check that the side stand operates smoothly.

  • Page 70: Final Drive Oil

    Final Drive Oil Checking the Final Drive Oil Adding Final Drive Oil 1. Place your motorcycle on the side stand If the final drive oil level is low, check for oil on a level surface. leaks. Add the recommended final drive oil 2.
  • Page 71 Final Drive Oil Changing Final Drive Oil Changing Final Drive Oil 4. Install a new sealing washer onto the drain bolt. Tighten the drain bolt. 1. Place your motorcycle on the side stand Torque: 9 lbf·ft (12 N·m, 1.2 kgf·m). on a level surface.

  • Page 72: Air Cleaner

    Air Cleaner Changing Air Cleaner Element Air cleaner housing cover Use a new Honda Genuine air cleaner Bolts element or an equivalent specified for your motorcycle. NOTICE Using the wrong air cleaner element can result in serious damage to the engine.

  • Page 73: Crankcase Breather

    Crankcase Breather 1. Remove the crankcase breather tube and drain deposits. 2. Reinstall the crankcase breather tube. Crankcase breather tube...

  • Page 74: Throttle

    Throttle Checking the Throttle Adjusting the Throttle Freeplay With the engine off, check that the throttle 1. Slide the cable boot. rotates smoothly from fully closed to fully 2. Loosen the lock nut. open in all steering positions and throttle 3.

  • Page 75: Other Adjustments

    Other Adjustments Adjusting the Rear Suspension Adjusting the suspension requires a pin spanner. We recommend that you have your motorcycle serviced by your dealer. ❙ Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Pin spanner Use the pin spanner to turn the adjuster.

  • Page 76: Headlight Aim

    Other Adjustments Adjusting the Headlight Aim Adjusting the Headlight Aim Adjusting the Brake Light Switch You can adjust vertical aim of the headlight for proper alignment. To move the headlight Check the operation of the brake light case, loosen the bolts. switch.

  • Page 77: Troubleshooting

    Troubleshooting Engine Will Not Start .........P. 77 Electrical Trouble ........P. 91 Overheating (High coolant temperature Battery Goes Dead ........P. 91 indicator is on)..........P. 78 Burned-out Light Bulb....... P. 91 Warning Indicators on or Flashing....P. 79 Blown Fuse ..........P. 95 Low Oil Pressure Indicator......P.

  • Page 78: Engine Will Not Start

    Engine Will Not Start ❙ ❙ Starter Motor Operates But Engine Starter Motor Does Not Operate Does Not Start Check the following items: Check the following items: Make sure engine stop switch is (Run) ● Check the correct engine starting position P.

  • Page 79: Overheating (High Coolant Temperature Indicator Is On)

    Overheating (High coolant temperature indicator is on) The engine is overheating when the 2. Check that the radiator fan is operating, following occurs: and then turn the ignition switch to the High coolant temperature indicator comes OFF position. ● If the fan is not operating: Acceleration becomes sluggish Suspect a fault.

  • Page 80: Warning Indicators On Or Flashing

    Warning Indicators on or Flashing Low Oil Pressure Indicator If the engine oil level goes down rapidly, your motorcycle may have a leak or another If the low oil pressure indicator comes on, serious problem. Have your motorcycle pull safely to the side of the road and stop inspected by your dealer.

  • Page 81: Abs (Anti-Lock Brake System) Indicator (Vt750Cs Only)

    Warning Indicators on or Flashing ABS (Anti-lock Brake System) Indicator (VT750CS only) ABS (Anti-lock Brake System) The ABS indicator may come on if you turn the rear wheel while your motorcycle is lifted Indicator (VT750CS only) off the ground. In this case, turn the ignition switch off and then on again.

  • Page 82: Tire Puncture

    Tire Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. We recommend you have this type of service Riding your motorcycle with a performed by your dealer. temporary tire or tube repair can be After an emergency repair, always have the risky.
  • Page 83 Tire Puncture Removing Wheels (VT750CS only) 4. Support your motorcycle securely and When removing and installing the wheel, be raise the front wheel off the ground using careful not to damage the wheel speed a maintenance stand or a hoist. sensor and pulser ring.
  • Page 84 Tire Puncture Removing Wheels Installation 4. Tighten the left axle pinch bolts. 1. Attach the side collars to the wheel. Torque: 16 lbf·ft (22 N·m, 2.2 kgf·m). 2. On the left side, place the wheel 5. Tighten the axle bolt. between the fork legs and insert the front axle shaft, through the left fork leg Torque: 44 lbf·ft (59 N·m, 6.0 kgf·m).
  • Page 85 Tire Puncture Removing Wheels 7. Check the clearances between each If a torque wrench was not used for surface of the brake disc and the brake installation, see your dealer as soon as bracket (not the brake pads) are possible to verify proper assembly. symmetrical.
  • Page 86 Tire Puncture Removing Wheels 3. Remove the exhaust pipe joint nuts. 4. Remove the muffler bracket bolts and nuts, washers. Exhaust pipe joint nuts 5. Remove the mufflers. Muffler bracket bolts Washers Nuts continued...
  • Page 87 Tire Puncture Removing Wheels Wheel Removal (VT750C) 7. While holding the other end of the rear 1. Park on a firm, level surface. axle shaft with a wrench, remove the 2. Support your motorcycle securely and rear axle nut. raise the rear wheel off the ground using 8.
  • Page 88 Recommended molybdenum disulfide 6. Adjust the rear brake pedal freeplay. paste: P. 62 (USA only) Pro Honda Moly 60 Paste or 7. Tighten the rear axle nut. equivalent Torque: 65 lbf·ft (88 N·m, 9.0 kgf·m). 1. Position the wheel between the swingarm 8.
  • Page 89 Tire Puncture Removing Wheels Wheel Removal (VT750CS) Axle holding 1. Park on a firm, level surface. bolt 2. Support your motorcycle securely and raise the rear wheel off the ground using a maintenance stand or a hoist. Brake 3. Loosen the axle holding bolt. bracket 4.
  • Page 90 Recommended molybdenum disulfide hose. Do not twist the brake hose. paste: Avoid getting grease, oil, or dirt on the (USA only) Pro Honda Moly 60 paste or disc or pad surfaces. equivalent Do not push the brake pedal while the 1.
  • Page 91 Tire Puncture Removing Wheels 5. Tighten the nut and bolt. Muffler Installation Before installing the muffler, replace the Rear brake bracket bolt: muffler gasket with a new gasket. Torque: 51 lbf·ft (69 N·m, 7.0 kgf·m). 1. Tighten the nuts and bolts. Rear axle nut: Torque: 65 lbf·ft (88 N·m, 9.0 kgf·m).

  • Page 92: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the motorcycle Turn the ignition switch to the OFF position. before charging.
  • Page 93 Electrical Trouble Burned-out Light Bulb ❙ Headlight Bulb 1. Remove the bolts from the headlight case. 2. Gently pull the lower end of the headlight Bolts Headlight forward and remove the headlight. 3. Disconnect the connector. 4. Remove the seat rubber. 5.
  • Page 94 Electrical Trouble Burned-out Light Bulb ❙ ❙ Brake/Taillight Bulb Front/Rear Turn Signal Bulb Screws Taillight lens Lens packing Turn signal lens Bulb Screw Bulb 1. Remove the taillight lens by removing the screws. 1. Remove the turn signal lens and lens 2.
  • Page 95 Electrical Trouble Burned-out Light Bulb ❙ License Plate Light Bulb Bulb License light 1. Remove the screws and license light cover cover. 2. Pull the bulb out of the socket without turning it. 3. Install a new bulb and parts in the reverse order of removal.

  • Page 96: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse 1. Remove the right side cover. P. 49 2. Open the fuse box cover. Before handling fuses, see “Inspecting and 3. Pull the fuses out one by one check for a Replacing Fuses.” P. 41 blown fuse.
  • Page 97 Electrical Trouble Blown Fuse ❙ Main Fuse 1. Remove the right side cover. P. 49 2. Disconnect the wire connector of the (VT750C) starter magnetic switch. Wire connector 3. Pull the main fuses out and check for a blown fuse. Always replace a blown fuse with a spare of the same rating.
  • Page 98 Electrical Trouble Blown Fuse ❙ Fuse Box Fuses 1. Remove the left side cover. P. 49 2. Remove the fuse box cover. (VT750CS) 3. Pull the fuses out one by one check for a Fuse box cover blown fuse. Always replace a blown fuse with a spare of the same rating.
  • Page 99 Electrical Trouble Blown Fuse ❙ Main Fuse & FI Fuse 4. Reinstall parts in the reverse order of removal. (VT750CS) Starter magnetic switch cover FI fuse Main fuse 1. Remove the left side cover. P. 49 2. Remove the starter magnetic switch cover.

  • Page 100: Information

    Information Keys ............P. 100 Honda Contacts ........P. 117 Instruments, Controls, & Other Features ...P. 101 Reporting Safety Defects....P. 119 Caring for Your Motorcycle ....P. 102 Storing Your Motorcycle......P. 105 Transporting Your Motorcycle ....P. 105 You & the Environment ......P. 106 Vehicle Identification Number ....

  • Page 101: Keys

    Keys Keys Ignition key Be sure to record the key number provided with the original keys. Store the spare key and recorded key number in a safe location. To make a duplicate, take the spare key or the key number to a locksmith. If you lose all keys and the key number, the ignition switch assembly will probably have to be removed by your dealer to determine the key...

  • Page 102: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & Odometer Other Features The display locks at 999,999 when the readout exceeds 999,999. Ignition Switch Tripmeter The headlight is always on when the ignition switch is ON. Leaving the ignition switch ON The tripmeter returns to 0.0 when the read-out with the engine stopped will drain the battery.

  • Page 103: Caring For Your Motorcycle

    Frequent cleaning and polishing is important to 3. Thoroughly rinse your motorcycle with plenty ensure the life of your Honda. A clean of clean water and dry with a soft, clean motorcycle makes it easier to spot potential cloth.
  • Page 104 Caring for Your Motorcycle ❙ Washing Precautions Do not direct water near the headlight: ● Follow these guidelines when washing: Any condensation inside the headlight Do not use high-pressure washers: should dissipate after a few minutes of ● High-pressure water cleaners can damage running the engine.
  • Page 105 Caring for Your Motorcycle Aluminum Components Exhaust Pipe and Muffler Aluminum will corrode from contact with dirt, The exhaust is made of stainless steel, which mud, or road salt. Clean aluminum parts can become tarnished with burn marks if regularly and follow these guidelines to avoid splattered with oil or other substances when scratches: hot.

  • Page 106: Storing Your Motorcycle

    For more information about storage, If you won’t be riding for an extended period, refer to the Honda Winter Storage Guide, follow these guidelines: available from your dealer. Wash your motorcycle and wax all painted ●...

  • Page 107: You & The Environment

    You & the Environment You & the Environment drain or on the ground. Used oil, gasoline, coolant, and cleaning solvents contain poisons Owning and riding a motorcycle can be that can hurt refuse workers and contaminate enjoyable, but you must do your part to protect drinking water, lakes, rivers, and oceans.

  • Page 108: Vehicle Identification Number

    Vehicle Identification Number Vehicle Identification Number The VIN and engine serial numbers uniquely identify your motorcycle and are required in order to register your motorcycle. They may also be required when ordering replacement parts. The VIN is stamped on the right side of the steering head and also appears on the Safety Certification Label attached to the right side of the frame.

  • Page 109: Emission Control Systems

    Emission Control Systems Emission Control Systems Engine number Your motorcycle engine emits combustion byproducts, including carbon monoxide (CO), oxides of nitrogen (NOx), and hydrocarbons (HC). Gasoline evaporation also emits hydrocarbons. Controlling the production of NOx, CO, and HC is important for the environment.
  • Page 110 January 1, 1983 comply with applicable noise Compliance with the terms of the Distributor’s emission standards for one year or 3,730 miles Warranties for Honda Motorcycle Emission (6,000 km) after the time of purchase when Control Systems is necessary in order to...
  • Page 111 The exhaust emission control system includes air into the exhaust gas to help improve the following components that should not need emission control performance. adjustment, although periodic inspection by your Honda dealer is recommended. ❙ Catalytic Converters The exhaust system contains one or more ❙...
  • Page 112 Emission Control Systems Crankcase Emissions Control System Noise Emission Control System ❙ TAMPERING WITH THE NOISE CONTROL The engine is equipped with a closed crankcase SYSTEM IS PROHIBITED: system to prevent discharging crankcase emissions into the atmosphere. U. S. federal law prohibits, and Canadian Blow-by gas is returned to the combustion provincial laws may prohibit, the following acts chamber through the air cleaner and the intake...
  • Page 113 FOLLOWING ACTS: Have your motorcycle inspected and repaired by Removal of, or puncturing the muffler, ● your Honda dealer if you experience any of the baffles, header pipes or any other component following symptoms: which conducts exhaust gases. Hard starting or stalling after starting ●...

  • Page 114: Catalytic Converter

    A defective catalytic converter contributes to air riding and turn off the engine. Have your pollution and can impair your engine’s motorcycle serviced as soon as possible. performance. A replacement unit must be an original Honda part or equivalent.

  • Page 115: Oxygenated Fuels

    Oxygenated Fuels Oxygenated Fuels If you accidentally fill your fuel tank with an oxygenated fuel containing higher percentages, Some conventional fuels blended with alcohol you may experience performance problems. To or an ether compound are available in some resolve the problem, have your dealer drain the locales to help reduce emissions to meet clean fuel tank and replace with the correct fuel.

  • Page 116: Authorized Manuals

    Authorized Manuals various systems on Honda motorcycles, scooters, and all-terrain vehicles. The Service Manual used by your authorized dealer is available from your Honda dealer or These Honda manuals are written for the Helm, Inc. professional technician. However, if you possess...

  • Page 117: Warranty Coverage And Service

    Coverage Your warranty coverage is not voided if you Your new Honda is covered by the following perform your own maintenance. However, warranties: failures that occur due directly to improper Motorcycle Limited Warranty ●...

  • Page 118: Honda Contacts

    You will be asked to American Honda Motor Co., Inc. authorize that inspection, and your dealer will If you wish to contact Honda directly to return the results of the inspection. If a problem comment on your experiences with your...
  • Page 119 Protection Plan to extend almost all of your ● Dealer name and address warranty coverage (USA only). ● We will likely ask your Honda dealer to respond, Your Honda dealer can also supply information or possibly acknowledge your comments about, riding events, and information about directly.

  • Page 120: Usa

    Highway Traffic Safety Administration Washington, DC 20590. (NHTSA) in addition to notifying You can also obtain other information American Honda Motor Co., Inc. about motor vehicle safety from: http://www.safercar.gov If NHTSA receives similar complaints, it may open an investigation, and if it finds...

  • Page 121: Specifications

    Specifications Specifications ■ Main Components Maximum weight 401 lb (182 kg) capacity* Type RC50 96 lb (43.5 kg) Overall length 98.8 in (2,510 mm) Maximum luggage Luggage 40 lb (18 kg) Overall width 36.2 in (920 mm) weight* Accessories 56 lb (25.5 kg) Overall height 44.3 in (1,125 mm) Passenger capacity...
  • Page 122 160/80-15M/C (74S) Recommended SAE 10W-30, JASO T 903 standard MA, Pro Tire type bias-ply, tube engine oil Honda GN4 4-stroke oil (USA & Canada) or DUNLOP D404 FG Honda 4-stroke oil, or an equivalent Front BRIDGESTONE G701 motorcycle oil CHENG SHIN M6002...
  • Page 123 Specifications ■ Bulbs ■ Torque Specifications Headlight 12V-60/55W Engine oil drain bolt 21 lbf·ft (29 N·m, 3.0 kgf·m) Brake/Taillight 12V-21/5W Oil filter 19 lbf·ft (26 N·m, 2.7 kgf·m) Front turn signal lights 12V-21/5W x 2 Final drive oil fill hole cap 9 lbf·ft (12 N·m, 1.2 kgf·m) Rear turn signal lights 12V-21W x 2...
  • Page 124 Information Record Engine No. Color Label & Code Owner’s Name Address City/State Phone Dealer’s Name Address City/State Phone Service Manager...

  • Page 125: Index

    Index Index ABS (Anti-lock Brake System) Caring for Your Motorcycle ....102 Indicator..........20, 80 Clock ............18 Accessories ..........13 Clutch System..........65 Authorized Manuals ....... 115 Color Label ..........38 Compartment Owner’s Manual ........29 Battery ..........39, 50 Coolant..........43, 57 Brake Light Switch ........75 Brakes Fluid ............
  • Page 126 Loading Guidelines ........14 Headlight Aim........... 75 Low Oil Pressure Indicator ....20, 79 Headlight Dimmer Switch ......22 Helmet Holder........... 28 High Beam Indicator......... 21 High Coolant Temperature Indicator ..........20, 78 Honda Contacts........117 Horn Button ..........22...
  • Page 127 Maintenance Parking ............12 Fundamentals........... 36 Parts Location ..........16 Importance..........31 PGM-FI (Programmed Fuel Injection) Safety............32 malfunction indicator lamp (MIL)..20, 79 Schedule ..........33 Protective Apparel........9 Maximum Weight Limit ......14 Modifications..........13 Recommended Final Drive Oil..........43 Neutral Indicator ........21 Fuel ............27 Refueling............27 Removal...
  • Page 128 Safety Labels ..........7 Throttle ............73 Safety Precautions ........9 Tires Shifting Gears..........26 Air Pressure ..........44 Side Stand..........68 Puncture........... 81 Side Stand Ignition Cut-off System..68 Replacing ..........46 Specifications .......... 120 Transporting Your Motorcycle ....105 Start Button..........
