- Page 1 Stacking XGS1910 Series Ethernet Switch Support Notes Version 1.00 September 2012...
- Page 2 2. If multiple switches claim to have been master for more than 30 seconds, then the switch which has been master for the longest period of time will become master. 3. The switch with the lowest master priority. 4. The switch with the lowest MAC address. All contents copyright (c) 2012 ZyXEL Communications Corporation.
-
Page 3: Application Scenario
10G ports for uplink usage. 4. If you want to use 10G to connect XGS4528 or XGS1910, use XFP on XGS4528 and SFP-Plus on XGS1910. Then they will connect successfully. All contents copyright (c) 2012 ZyXEL Communications Corporation. -
Page 4: Configuration Guide
1.1 XGS1910-48_1F Configuration steps: Step 1 : Monitor > System > Information to check the firmware version. Step 2 : Configuration > System > IP to configure an IP address on the switch. All contents copyright (c) 2012 ZyXEL Communications Corporation. - Page 5 Step 3 : Configuration > Stack to enable the stacking function. Note : After enabling the stacking function, the switch MUST be rebooted. Step 4 : Maintenance > Restart Device to reboot the switch. Step 5 : Check stacking status. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 6 Stacking Support Note Step 6 : Configuration > Stack to set Switch ID and Priority for the switch. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 7 1.2 XGS1910-24_1F Configuration steps: Step 1 : Monitor > System > Information to check the firmware version. Step 2 : Configuration > System > IP to configure an IP address on the switch. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 8 Step 3 : Configuration > Stack to enable the stacking function. Note : After enabling the stacking function, the switih MUST be rebooted. Step 4 : Maintenance > Restart Device to reboot the switch. Step 5 : Check stacking status. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 9 Step 6 : Configuration > Stack to set Switch ID and Priority for the switch. 1.3 XGS1910-24_2F Configuration steps: Step 1 : Monitor > System > Information to check the firmware version. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 10 Step 3 : Configuration > Stack to enable the stacking function. Note : After enabling the stacking function, the switch MUST be rebooted. Step 4 : Maintenance > Restart Device to reboot the switch. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 11 Stacking Support Note Step 5 : Check stacking status. Step 6 : Configuration > Stack to set Switch ID and Priority for the switch. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 12 XGS1910-48_1F: XGS1910-24_1F: XGS1910-24_2F: Based on the rules of master election, the XGS1910-48_1F will become the Master switch. You can now connect the 10G links between all switches. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 13 Stacking Support Note Verification Step 1 : Log in to XGS1910-48_1F. All switches will behave as one switch. Step 2 : Check the stacking status. All contents copyright (c) 2012 ZyXEL Communications Corporation.
- Page 14 Step 1 : Configuration > Aggregation > LACP. Enable LACP on XGS1910-48_1F (Switch 1). Step 2 : Configuration > Aggregation > LACP. Enable LACP on XGS1910-24_1F (Switch 2). Verification Step 1 : Monitor > LACP > System Status. All contents copyright (c) 2012 ZyXEL Communications Corporation.
