SERVICE MANUAL
1st Edition

Advertisement

Table of Contents
loading

Related Manuals for Sony DSC-HX350

Summary of Contents for Sony DSC-HX350

  • Page 1 DIGITAL STILL CAMERA DSC-HX350 SERVICE MANUAL 1st Edition...
  • Page 2 Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente uniquement. DSC-HX350...
  • Page 3 Be sure to keep your PC used for service and checking of this 修理時に使用するパソコンは，ウィルス検出ソフトが常にアッ プデートを行っているパソコンを使用してください。もし，修 unit always updated with the latest version of your anti-virus software. In case a virus affected unit was found during service, 理を行うセット，もしくはパソコンがウィルスに感染している 事が判明した場合は，ソニーグループ内は社内技術相談窓口に， contact your Service Headquarters. 特約店様は特約店様専用電話窓口（修理窓口）にご相談くださ い。 DSC-HX350...
  • Page 4 CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU PUBLISHED BY SONY.
  • Page 5 Model Information Model HX350 Destination UC2, E33 CE3, CEH, RU3, E32, IN5, AU2, EA8, Color system NTSC Wi-Fi DSC-HX350...

  • Page 7: Table Of Contents

    Final Inspection..................... . . 4-32 DSC-HX350...
  • Page 8 Frame Wiring......................... . . 6-1 Revision History DSC-HX350...

  • Page 9: Purpose Of This Manual

    • Help Guide (Web manual) Refer to “Help Guide” for in-depth instructions on the many functions of the camera. • Adjust Manual (Available on request) The adjustment software is necessary for adjustment and various checking of this unit for the service. DSC-HX350...

  • Page 11: Trouble Shooting

    Check whether this error is due to the lens or the board. Replace the faulty lens or board. Continued Function of this code is not provided in this unit. DSC-HX350...
  • Page 12 When the lens block was replaced, start the Adjust Manual in the Adjust Station and execute the necessary adjustment items. After the adjustment, make sure with the STEADYSHOT turned ON that the steadyshot functions appropriately in the handheld operation. After check, be sure to perform “Process after Fixing Flash Error”. DSC-HX350...
  • Page 13 Replace the board that contains this peripheral circuit. Electronic compass hardware error The peripheral circuit of the electronic compass may be (GPS hardware error) faulty. Replace the board that contains this peripheral circuit. Function of this code is not provided in this unit. DSC-HX350...

  • Page 14: Process After Fixing Flash Error

    When “FLASH error” (Self-diagnosis Code E:91:01) occurs, to prevent any abnormal situation caused by high voltage, setting of the flash is changed automatically to disabling charge and flash setting. After fixing, this setting needs to be deactivated. Method of initializing the flash error code: Reset Flash Error using the Flash Error Repair Tool Ver_[].[].exe. DSC-HX350...

  • Page 15: Service Note

    The charging capacitor for the flash has been charged at high voltage. Therefore, there is a possibility of an electric shock if you directly handle this capacitor. The high-voltage charge will not be discharged by simply turning off the unit’s power. Make sure any remaining voltage is discharged by short-circuiting the flash capacitor with a Short Jig. DSC-HX350...
  • Page 16 In order to prevent an electric shock, wrap insulating tape completely around the resistor and its leads. Resistor with a rated value of approximately 1 k  /1 W (Part No. 1-215-869-11). Small clip Small clip Wrap insulating tape completely around the resistor and its leads. DSC-HX350...

  • Page 17: Precaution On Replacing The Sy-1034 Board

    Start the Adjust Manual in the Adjust Station and execute the “Angular velocity sensor sensitivity adj” on the ADJUST tab. Note The sensitivity of the angular velocity sensor is indicated only on the repairing board, but is not indicated on mass production boards. DSC-HX350...

  • Page 19: Adjustment

    It is the software to adjust and check digital cameras and camcorders for service. The installer of the Adjust Manual and the installation manual are attached, be sure to confirm the contents of them. Note Be sure to install Adjust Station first. DSC-HX350...

  • Page 21: Replacement Of Main Parts

    BTH Block • ST-1013 Board • BT-2005 Flexible Board VF Block • SE-1008 Flexible Board Control Switch Block (RL63980) SY-1034 Board SY Holder Assy • UM-1002 Flexible Board Lens Section • CD-1003 Flexible Board Cabinet (Front) Section • PR-1006 Board DSC-HX350...
  • Page 22 View Position Top View Left View Back View Front View Right View Bottom View DSC-HX350...

  • Page 23: Disassembly

    4-2. Disassembly 4-2-1. Overall Section • Refer to “Overall Section” on exploded view for Ref. No. Main Board Section LCD902 (Claws) #140 #140 Rear Section DSC-HX350...
  • Page 24 Disassembly Places [1]: #2 x 8 Back View Left View Bottom View [2]: #12 x 2, #140 x 2 Back View #140 DSC-HX350...

  • Page 25: Main Board Section

    4-2-2. Main Board Section • Refer to “Main Board Section” on exploded view for Ref. No. Lens Section BT4500 #257 #257 SP901 Disassembly Places [1]: #12 x 2 Back View DSC-HX350...
  • Page 26 [2]: #257 x 3 Back View #257 [3]: #257 x 3 Back View #257 [6]: #12 x 2 Back View DSC-HX350...

  • Page 27: Lens Section

    4-2-3. Lens Section • Refer to “Lens Section” on exploded view for Ref. No. ST/BT Section #291 Lens Block Section Disassembly Places [1]: #291 x 4 Back View #291 #291 DSC-HX350...

  • Page 28: St/Bt Section

    If the GP-1017 Flexible Board is bent, it separates from the adhesion part and the detection switch does not function normally. GP-1017 Flexible Board Detection switch Sheet (Ground Plate MIC) (490) 組立時にGP-1017フレキシブル基板を曲げないように注意してください。 GP-1017フレキシブル基板が接着部から浮いてしまい, 検出スイッチが正常に動作しな くなります。 GP-1017フレキシブル基板 検出スイッチ 接着紙  （アース板MIC）  (490) DSC-HX350...
  • Page 29 Short-circuit the terminals of flash capacitor with the short jig for about to seconds, and discharge the capacitor. Short Jig R:1 k /1 W (Part code: 1-215-869-11) ST-1013 Board C901 ST-1013 Board C901 Disassembly Places [1]: #12 x 2 Back View [2]: #12 x 2 Back View DSC-HX350...
  • Page 30 [4]: #310 x 2 Back View #310 Notes on Assembling the ST/BT Section Notes on Assembling the Control Switch Block (RL63980) Install the Control Switch Block (RL63980) with the lever positioned at the center. Lever Control Switch Block (RL63980) 4-10 DSC-HX350...

  • Page 31: Front Section

    4-2-5. Front Section • Refer to “Front Section” on exploded view for Ref. No. #310 #294 #292 4-11 DSC-HX350...
  • Page 32 Notes on Assembling the Front Section Notes on Assembling the PR-1006 Board MF Slide Lever MF Ring Assy Lever Pins PR-1006 Board PR-1006 Board MF Ground Plate Groove Groove Pins Insert the MF Ground Plate to these portions 4-12 DSC-HX350...

  • Page 33: Rear Section

    (Claws) (Note 1) #140 (Size: 28.4 mm X 8.7 mm) (Claws) #310 #140 LCD901 (Note 1) (Size: 29.4 mm X 11.9 mm) Note 1 Use this to cut or splice so that it becomes the designated size. 指定のサイズになるように形状を加工して使用してください。 4-13 DSC-HX350...
  • Page 34 Before installing the P Cabinet (C) Assy, be sure to install the side panel screw first. P Cabinet (C) Assy Notes on Assembling the Hinge Covers Set up the hinge part. Hinge Pass the FP-2131 Flexible Board to the hinge part and the Hinge Cover (R). Hinge Hinge Cover (R) FP-2131 Flexible Board 4-14 DSC-HX350...
  • Page 35 Fix the FP-2131 Flexible Board as shown in the figure. Hinge Cover (R) Adhesive part FP-2131 Flexible Board Pins Fix the Hinge Cover (R). Hinge Cover (R) Install the Hinge Cover (M). Hinge Cover (M) 4-15 DSC-HX350...
  • Page 36 Install the Hinge Cover (C). Hinge Cover (C) Tighten the screw. 4-16 DSC-HX350...

  • Page 37: Lens Block Section

    “Lens Block Section” on exploded view for Ref. No. (including CMOS imager) #258 (Size: 9 mm X 70 mm) (Note 1) #172 #115 #172 Note 1 Use this to cut or splice so that it becomes the designated size. 指定のサイズになるように形状を加工して使用してください。 4-17 DSC-HX350...

  • Page 38: Lens Block

    Installation Match the boss of the Filter Screw Frame Assy with the concave of the 1st Frame Assy, install the Filter Screw Frame Assy, and then tighten three screws. Filter Screw Frame Assy Boss 1st Frame Assy Concave 4-18 DSC-HX350...
  • Page 39 Peel off the release paper of the Ornamental Plate and stick the Ornamental Plate matching the boss of the Ornamental Plate with the screw A position. Ornamental Plate Screw A position Boss 4-19 DSC-HX350...

  • Page 40: 2Nd Assy Replacing Method

    Solders Polyester Tape Peel off the Shutter Flexible Board. Shutter Flexible Board Main Flexible Board Adhesive Tape Disconnect the 5th Assy Flexible Board from the connector on the Main Flexible Board. 5th Assy Flexible Board Main Flexible Board 4-20 DSC-HX350...
  • Page 41 Remove the six screws to detach the Rear Mirror Assy. Rear Mirror Assy 10. Turn the Naruto Gear counterclockwise to extend the lens. 11. Draw the F Flexible Board and the Vibration Absorption Flexible Board inside the Fixed Stationary Tube Assy. 4-21 DSC-HX350...
  • Page 42 12. Turn the Naruto Gear clockwise to return the lens to the previous position. Vibration Absorption F Flexible Board Flexible Board Naruto Gear Fixed Stationary Tube Assy 13. Remove the Naruto Gear. Naruto Gear 14. Remove the Fixed Stationary Tube Assy. Fixed Stationary Tube Assy 4-22 DSC-HX350...
  • Page 43 16. Remove the four screws to detach the Bearing Assy and the Straight Tube Thrust Spring. Bearing Assy Straight Tube Thrust Spring 17. Remove the 4th Assy. 4th Assy 18. Fully turn the Shafts Retainer Assy in the direction of arrow. 4-23 DSC-HX350...
  • Page 44 When removing the 3rd Assy, hold the bottom of the 2nd Assy to prevent it from falling. 3rd Assy 2nd Assy Shafts Retainer Assy 20. Remove the Cam Tube Assy. Cam Tube Assy 21. Remove the five screws to detach the Shafts Retainer Assy and the 2nd Assy. 2nd Assy, Shafts Retainer Assy 4-24 DSC-HX350...
  • Page 45 Attach the 2nd Assy to the Shafts Retainer Assy. 2nd Assy Shafts Retainer Assy Match the groove with the hole and attach the Straight Tube to the Cam Tube Assy. Cam Tube Assy Straight Tube Groove Match the groove with the hole Hole 4-25 DSC-HX350...
  • Page 46 3rd Assy Boss Hole Shaft Groove 2nd Assy Shafts Retainer Assy Match the boss with the groove and attach the 4th Assy while inserting the shafts into the holes. 4th Assy Hole Boss Groove Hole Shafts Shafts Retainer Assy 4-26 DSC-HX350...
  • Page 47 Pass the Flexible Boards through the notches of the Straight Tube. Notch Notch Match the marks and turn the Cam Tube to be attached to the 1st Assy in the direction of arrow. Cam Tube Marks 1st Assy 4-27 DSC-HX350...
  • Page 48 Tube Assy 11. Attach the Naruto Gear. Naruto Gear 12. Turn the Naruto Gear counterclockwise to extend the lens. 13. Pull the F Flexible Board and the Vibration Absorption Flexible Board out of the Fixed Stationary Tube Assy. 4-28 DSC-HX350...
  • Page 49 15. Install the Rear Mirror Assy and tighten six screws. Rear Mirror Assy 16. Stick the Main Flexible Board to the Fixed Stationary Tube Assy. 17. Connect the Vibration Absorption Flexible Board to the connector on the Main Flexible Board. 4-29 DSC-HX350...
  • Page 50 20. Connect the 5th Assy Flexible Board to the connector on the Main Flexible Board. 5th Assy Flexible Board Main Flexible Board 21. Stick the Shutter Flexible Board. Shutter Flexible Board Main Flexible Board Adhesive Tape 22. Solder the Main Flexible Board and the Shutter Flexible Board. 4-30 DSC-HX350...
  • Page 51 23. Stick the Polyester Tape. Solders Shutter Flexible Board Main Flexible Board Polyester Tape 24. Perform the Flange Back Adjustment after the assembling. 4-31 DSC-HX350...

  • Page 52: Final Inspection

    Inspection When Cam Tube Block Assy or Straight Tube Lubricated Assy is Replaced Focus check Preparation • Camera installed re-assemble lens. • Chart (Printed PDF file at the same magnification) (Refer to <Reference>) • Tripod • Mirror (ex. CD) • Memory card • PC 4-32 DSC-HX350...
  • Page 53 Check the settings of printer to print in proper size. • Check of chart size. Make charts together and check if the size of charts is the following size. * The chart consists of 2 pcs. 533 mm (±2 mm) 4-33 DSC-HX350...

  • Page 55: Repair Parts List

    • Color Indication of Appearance Parts • SEMICONDUCTORS Example: In each case, u: μ, for example: (SILVER) : Cabinet’s Color uA... : μA... , uPA... : μPA... , uPB... : μPB... , (Silver) : Parts Color uPC... : μPC... , uPD... : μPD... DSC-HX350...

  • Page 56: Exploded View

    VF ASSY (970) 4-279-877-01 RETAINER, MODULE 4-487-180-02 SHEET METAL (980), SHOE 4-464-330-01 SHEET (S) (490) 4-537-558-01 SHEET (RADIATION ) (LENS FPC) 4-279-878-01 CUSHION (EYE SENSOR) LCD902 1-811-013-11 LCD MODULE (FL0906) 2-635-562-31 SCREW(M1.7) 3-080-204-21 SCREW, TAPPING, P2 #140 2-635-562-01 SCREW(M1.7) DSC-HX350...

  • Page 57: Main Board Section

    SY-1034 BOARD, COMPLETE (SERV- ICE) 4-463-553-01 GASKET (4X4X1) 4-458-110-01 PLATE (USB) (490), FIXED A-1926-868-A UM-1002 FLEXIBLE BOARD, COMPLETE 4-274-987-01 TAPE (AS 1/2) (C) BT4500 1-756-710-14 LITHIUM RECHARGEABLE BATTERY SP901 1-858-343-71 LOUDSPEAKER (1.0CM) 3-080-204-21 SCREW, TAPPING, P2 #257 3-208-537-41 0+Z M1.4X2 NEW TORASUTA DSC-HX350...

  • Page 58: Lens Section

    Lens Section ST/BT Section #291 Lens Block Section Ref. No. or Q'ty Part No. SP Description 4-539-270-01 SHEET EST (LENS FPC 2) 4-461-557-01 SHEET (OF) 4-465-381-01 SHEET (LENS) (490) #291 3-078-890-41 SCREW, TAPPING DSC-HX350...

  • Page 59: St/Bt Section

    HARNESS (SK-1001) (Pink) 1-969-003-11 HARNESS (SK-1002) (White) 4-458-102-01 CUSHION (490), MICROPHONE 4-458-101-01 PLATE (MIC) (490), GROUND 4-465-719-02 SHEET (GROUND PLATE MIC) (490) A-2032-312-A GP-1017 FLEXIBLE BOARD, COMPLETE X-2586-759-1 BTH ASSY (490) 4-279-792-01 SHEET (LCD) 4-278-659-01 INTERCEPTION SHEET ST (770) DSC-HX350...

  • Page 60: Front Section

    RING (BASE) (490), LENS X-2593-488-1 CABINET (FRONT) ASSY (61890) 3-283-643-21 SCREW, TRIPOD 4-458-080-01 * COVER (MULTI) (490), JACK 4-458-081-01 * SHAFT (490), JACK COVER #292 3-316-938-41 SCREW (B1.4X6), TAPPING #294 3-939-590-46 SCREW (IB LOCK) #310 4-300-115-31 TAPPING (1.7) (CH) DSC-HX350...

  • Page 61: Rear Section

    COVER (R) (490), HINGE 4-279-852-01 COVER (C), HINGE 4-464-523-01 SHEET (RADIATION) (PD FPC 1) X-2586-762-1 CABINET (REAR) ASSY (490) 1-492-120-21 SWITCH BLOCK, CONTROL (KEY63980) LCD901 1-811-762-11 PANEL MODULE (PF2-BJD) 3-080-204-21 SCREW, TAPPING, P2 #140 2-635-562-01 SCREW(M1.7) #310 4-300-115-31 TAPPING (1.7) (CH) DSC-HX350...

  • Page 62: Lens Block Section

    CD-1003 FLEXIBLE BOARD, COMPLETE 1-856-440-11 OPTICAL UNIT (BE019) 7-600-009-74 TAPE, POLYIMIDE (NO.690) 10MMX20M X-2587-062-1 FRAME ASSY, FILTER SCREW 4-460-994-01 PLATE, ORNAMENTAL #115 3-348-998-51 SCREW (M1.4X3.5), TAPPING, PAN #172 2-178-410-01 TITE (UB TITE) 1.4 #258 4-299-468-11 SCREW, TAPPING UB1.2 (CH) DSC-HX350...

  • Page 63: Fuse

    SY-1034 BOARD (SIDE A) SY-1034 BOARD (SIDE B) 5.0V 5.0V F5650 F0102 5.0V Primary side Ref. No. or Q'ty Part No. SP Description F0100 1-576-415-31 FUSE (2A/32V) F0101 1-576-842-31 * FUSE (0.63A/32V) F0102 1-576-596-41 FUSE (1A/36V) F5650 1-576-415-31 FUSE (2A/32V) DSC-HX350...

  • Page 64: Accessories

    4-595-954-21 * Instruction Manual (TURKISH, THAI, INDONESIAN) Ref. No. or Q'ty Part No. SP Description 8-022-359-31 Rechargeable Battery Pack NP- BX1/UC (UC2) 8-022-359-50 Rechargeable Battery Pack NP- BX1/CE (EXCEPT UC2, CN1) 8-022-359-71 Rechargeable Battery Pack NP- BX1/CN (CN1) 5-10 DSC-HX350...

  • Page 65: Frame Schematic Diagrams

    26 30 SY-1034 BOARD (SIDE A) (ZOOM/FOCUS) CN6801 MULTI SP901 (SPEAKER) CN4003 CN4500 SE7701 (PITCH/YAW) LENS BLOCK BT4500 (LITHIUM BATTERY) FP-2131 FLEXIBLE BOARD CN004 LCD901 (LCD MODULE) BACKLIGHT CONTROL SWITCH BLOCK PD-1038 BOARD (KEY63980) 3.0 INCH CN8040 CN8041 COLOR DSC-HX350...

  • Page 67: Revision History

    Revision History Ver. Date History Contents S.M. Rev. issued 2017.01 Official Release ― ― DSC-HX350...
  • Page 70 DSC-HX350 (UC2) DSC-HX350 (CE3) DSC-HX350 (CEH) DSC-HX350 (RU3) DSC-HX350 (E32) DSC-HX350 (E33) DSC-HX350 (IN5) DSC-HX350 (AU2) DSC-HX350 (EA8) Printed in Japan Sony Corporation DSC-HX350 (CN1) 2017. 01 08 9-896-784-11 © 2017...
