QL1 SERIES
4-WAY
CONVERTIBLE
RANGE HOOD
Deluxe features in our smaller shell - offers the
most hood for the money.
FEATURES
•
2-speed fan control
•
Polymeric blade and light lens (accepts two 60W bulbs)
•
Washable aluminum filter
•
converts to non-ducted by removing cover plate from
control panel and installing the non-ducted filter BPQTF
(purchase separately)
•
3¼" x 10" damper/duct connector included
•
7" round duct adapter plate included
•
Mitered sides and hemmed bottom for safety,
cleanability and good looks
•
contemporary styling in White and Biscuit
•
available in 30" width only
SPECIFICATIONS
VOLTS
AMPS
CFM
HIGH
120
1.9
190
120
1.9
190
120
1.9
230
120
1.9
--
HVI-2100 ceRtIfIeD RatINgs comply with new testing
technologies and procedures prescribed by the Home
Ventilating Institute, for off-the-shelf products, as they are
available to consumers. Product performance is rated at 0.1 in.
static pressure, based on tests conducted in a state-of-the-art
test laboratory. sones are a measure of humanly-perceived
loudness, based on laboratory measurements.
Broan-Nutone LLc Hartford, Wisconsin www.broan.com 800-558-1711
REFERENCE
QTY.
SONES
NORMAL
HIGH NORMAL
100
6.0
2.0
130
6.0
2.0
150
6.0
2.0
--
--
--
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Range hood shall be Broan QL1 Series.
Unit shall be convertible between ducted (using a washable
aluminum filter) and non-ducted (using non-ducted filter
BPQTF).
Motor to be permanently lubricated.
Unit shall have a 2-speed fan control with separate 2-level
light switch.
sides shall be mitered and bottom edge hemmed with no
sharp edges.
air delivery shall be no less and sound levels no greater than
shown. All air and sound ratings shall be certified by HVI.
Unit shall be U.L. listed.
DUCT
3¼" X 10" (H)
3¼" X 10" (V)
7" Round (V)
Non-Ducted
Project
Location
Architect
Engineer
Contractor
Submitted by
Date
90B
99044082B
