R-500

A r c h i t e c t u r a l L o u d s p e a k e r

radia

T H E R A D I A S E R I E S

The new Radia R-500

by BG represents the finest technology ever available in an

architectural loudspeaker. In the heart of the new Radia Series lineup, the R-500 brings

vivid clarity and lifelike performance to medium to large home theater or music systems.

The frame's narrow 7" width and elegant contour are an ideal architectural complement

to large flat TV or even large screen projection systems. Yet the R-500 delivers astounding

sonic performance that belies its modest dimensions.

Like its two larger siblings, the R-500 features BG's outstanding wideband planar ribbon

driver, the Neo10, along with BG's proprietary Neo3 tweeter. The Neo10 is a10" x 5" Planar

Ribbon Midrange Driver based on the company's proprietary technology. Significantly

larger in size than other BG ribbons, the Neo10 sets new standards for sensitivity, output,

power handling and accuracy. In fact, the driver's size allows it to move substantial

amounts of air while keeping diaphragm excursion at relatively low levels. Controlled

excursion translates into lower distortion and higher sensitivity while providing amazing

clarity and linear response.

The R-500's drivers are configured in a symmetric controlled directivity array. The driver

configuration and crossover frequencies are chosen so that the vertical directivity of the R-

500 is controlled to 20 degrees and is constant through most of the operational frequency

band. This provides effective reduction of floor and ceiling reflections and delivers

consistent intelligible and spectrally balanced sound in virtually any room and

to a wide area of seats. The R-500 offers an additional advantage by allowing more

freedom in vertical placement and can always be installed alongside of the screen, even if

the latter is located other than an optimum height.

For the bass section, R-500 employs new high-performance 5.25" woofers which feature a

powerful Neodymium magnet system and acoustically transparent chassis. The woofers

are optimized for power handling and sensitivity to keep up with the dynamic output of

the Neo10 and Neo3 drivers.

T h e

P o w e r

o f

C l a r i t y
