- Page 1 The Power of Clarity Owner’s Manual and Setup Procedures Radia Series...R-75i & R-8i / R-50i / R-40i / R-LCRi / R-32i / R-20i...
-
Page 2: Table Of Contents
The Radia Series, BG’s top of the line In-Wall loudspeakers, are ideal for either critical music listening or high performance home theater applications. The line is comprised of models R-75i & R- 8i, R-50i, R-40i, R-LCRi, R-32i, and R-20i. -
Page 3: Important Owner Information
DO NOT spray any cleaning solutions directly on the grill as it can clog its perforations. Liquid – DO NOT place BG loudspeakers near an open source of liquid that may spill on the loudspeaker surfaces. -
Page 4: General Information
Therefore a good 100-150 watt per channel amplifier or receiver is needed to deliver adequate power for a typical room size. Your authorized BG Dealer can recommend an amplifier best suited to your needs. All Radia in-wall speakers are single post connections... -
Page 5: Technical Description
Series line-source loudspeakers also operate as one-way loudspeakers above their bass crossover point achieving the ideal of coherent, consistent amplitude (loudness) and phase response. For additional technical information, please request a complimentary copy of Keith Yates’ white paper on planar ribbon technology. BG Corp 2005... - Page 6 In custom designs, Radia Series systems install in vertical details in cabinetry, in as little as 7” of width for the ultimate performance and elegance. Radia loudspeakers virtually disappear while still providing state-of-the-art performance – performance absolutely unavailable from conventional loudspeaker systems. BG Corp 2005...
-
Page 7: Installation
4. When installing the R-75i planar ribbon with its companion R-8i woofer, they must be mounted within two feet of one another, in the adjacent stud bay, for proper performance. BG Corp 2005 Installation... - Page 8 8. Insert the speaker in the cavity. 9. Using the supplied 1/8” Allen-Key bit in a medium clutched screw gun, engage the dog-toggles and tighten. 10. Test the speaker. 11. Re-install the rubber covers, grills and end caps. BG Corp 2005...
- Page 9 LCRi can be rotated for use either vertically or horizontally. Electronic Connections: Today’s electronic processors and a/v receivers have built in crossover points described as small and large speakers. With all Radia speakers, this option should be turned on for maximum performance. BG Corp 2005...
-
Page 10: Installed Height
Installed Height BG Corp 2005... -
Page 11: Warranty Information
PURCHASE DATE: _____________________ AUTHORIZED DEALER: _________________ As part of our policy of continual product improvement, BG reserves the right to change or discontinue any specifications or parts associated with any of its products without advanced notice. Thank you again for choosing BG loudspeakers! - Page 12 The Power of Clarity www.bgcorp.com BG Corp 2005...
