CDI6371
Integrated dishwasher
Use and maintenance

Advertisement

Table of Contents
loading

Related Manuals for CDA CDI6371

Summary of Contents for CDA CDI6371

  • Page 1 CDI6371 Integrated dishwasher Use and maintenance...

  • Page 2: Table Of Contents

    Contents Important information and notes Recommendations and before first use Control panel Selecting a programme and feature information Starting a programme Changing and cancelling programme Buzzer sound control Save Power mode Detergent information Salt information Softener adjustment Direct wash feature Rinse aid 20 Dishwasher basket information 20 Loading information...
  • Page 3 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
  • Page 4 Availability of this manual in an alternative format: A soft copy of this manual is available for download from www.cda.eu. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
  • Page 5 • Do not open the dishwasher door when a programme is running. If it is necessary to do so, then open it only slightly to allow the dishwasher to pause the programme and prevent any water spilling out. Remember that the water in the dishwasher can be very hot when the programme is running.
  • Page 6 Recommendations • To reduce energy and water consumption, remove all dirt residues from the dishes prior to loading the dishwasher. • Loading the dishwasher to the capacity indicated by the manufacturer will save energy and water. • Place hollow items (bowls, glasses and pans) face down in the basket. •...

  • Page 7: Control Panel

    Control Panel 60 - 70 C Upper basket Lower basket Extra Silent Extra Drying Extra Fast Fig. 1 Programme display (1) The programme display shows the selected programme and the remaining time to run. If there is a fault on the dishwasher, the fault code will show on the display.
  • Page 8 Press the button until the LED (9) corresponding to the basket contaning the dishes to be washed illuminates. Dishes in other areas will not be washed. For more info see page 17. Delay timer indicator (5) The dishwasher is equipped with a variable timer of up to 19 hours duration at hourly intervals.

  • Page 9: Starting A Programme

    temperature and pressure will increase to ensure an improved washing quality in a shorter duration. This option can only be selected at the beginning of a programme. Salt and rinse aid warning lights (8) When the dishwasher salt or rinse aid begins to run out, the warning light will illuminate to advise that it needs refilling Starting a programme •...
  • Page 10 Changing a programme It is possible to change the programme if necessary once the programme has started. • First open the door slightly to reduce the risk of water spillage. • Press the Programme Selection button until the required programme is shown on the display. •...

  • Page 11: Buzzer Sound Control

    Buzzer sound control To change the buzzer sound level, follow the below steps: 1. Open the door and press Delay (5) and Options (6) buttons simultaneously for 3 seconds. 2. When sound setting is recognized, buzzer gives a long sound and machine will display last set level, from “S0”...
  • Page 12 The solubility of dishwasher tablets can vary depending on the temperature and duration of the programme. As a result, it is recommended that powder detergents should be used in the shorter programmes to allow better performance. CDA recommend the use of separate detergent, rinse aid and...
  • Page 13 dishwasher salt rather than combination tablets as separates achieve better wash performance. If you do use combination detergents, add salt and rinse aid to the dishwasher and then adjust the water hardness setting and rinse aid setting to the minimum. When you then use separate detergents again, you should fill the salt and rinse aid compartments, adjust the water hardness setting to the maximum and run an empty wash, then adjust the water hardness setting and the rinse aid setting to the...
  • Page 14 Salt To ensure the best efficiency, the dishwasher needs soft water. Hard water means that lime residues remain on the dishes and the interior of the dishwasher, affecting performance. The softener system is designed to remove the ions that make the water hard to provide the best quality wash performance.

  • Page 15: Softener Adjustment

    CDA recommends the use of separate detergent, rinse aid and dishwasher salt rather than combination tablets as separates achieve better wash performance. fig 2 If you do use combination detergents, add salt and rinse aid to the dishwasher and then adjust the water hardness setting and rinse aid setting to the minimum.
  • Page 16 If the hardness of the water you use is above 63dE or if you are using well water; you are recommended to contact your local water board to confirm the water hardness level and to use filter and water refinement devices. Please note: The level of water hardness is preset to level 3.

  • Page 17: Direct Wash Feature

    Direct wash This feature uses nozzles to help to wash bottles, glasses etc. directly. Alternatively, the nozzles can be unclipped and placed horizontally and used as an aid in washing the lower basket. When changing the direction of the nozzles, pay attention to their positions on the basket.

  • Page 18: Rinse Aid

    Rinse aid Rinse aid helps to ensure better quality wash results and increased drying performance. To fill the rinse aid compartment, open the rinse aid compartment lid. Fill the compartment with rinse aid to the MAX level and then close the lid. Be careful not to overfill the rinse aid compartment and ensure that you wipe up any spillages.
  • Page 19 Level Brightener Dose Indicator Rinse-aid not dispensed r1 is shown the on display. 1 dose is dispensed r2 is shown the on display. 2 doses are dispensed r3 is shown the on display. 3 doses are dispensed r4 is shown the on display. 4 doses are dispensed r5 is shown the on display.
  • Page 20 Dishwasher Baskets The middle basket has two different heights available, to allow for larger products in either the middle or lower basket. To raise or lower the middle basket: 1. Hold the basket on both sides and pull it up or push it down, ensuring both sides of the upper basket are in the same position (Fig.
  • Page 21 Adjustable cup racks (Glass guard) The dishwasher is equipped with adjustable, soft rimmed, cup racks on the middle basket to allow long stemmed glasses to rest securely during washing, or stacking of smaller cups. The cup racks can also be folded up when not required to allow more space for larger items.

  • Page 22: Standard Loading And Test Data

    Standard Loading and Test Data Capacity • Middle and lower baskets: 15 place settings. • The middle basket should be adjusted to the lowest position. Detergent / Rinse aid • 5 + 25 cm , in accordance with EN50242-DIN 44990 IEC 436 (international norms) / Rinse aid dosage adjustment: 5.

  • Page 23: Programme Listing

    Programme Listing Smart Steam Super Dual Programme Hygiene Quick Mini 14 60°C - Wash 50’ Name 50°C 70°C 30’ 40°C 70°C 70°C 65°C Wash Level of Medium Heavy Heavy Heavy Medium Heavy Light Light soil Amount of detergent: A = 25cm³ B = 15cm³...

  • Page 24: Care And Maintenance

    Care and Maintenance Before beginning any care or maintenance, you should always disconnect the appliance from the electricity supply, and also turn off the water supply. Door seals fig. 14 Wipe the dishwasher door seals regularly with a damp cloth to remove any residues.
  • Page 25 Please note: Never run a programme without the filters in place. Incorrect fitting of the filters may reduce wash performance and potentially damage your appliance. Spray arms You should clean the spray arms at least once a month. 1. Remove the lower basket 2.

  • Page 26: Error Codes

    Make sure the water inlet tap is open and water is flowing Seperate the inlet hose from the tap and clean the filter Water inlet system failure fo the hose Contact CDA customer care if the error continues Pressure system failure Contact CDA customer care Continuous water input...

  • Page 27: Troubleshooting

    Poor appliance earth (check mains electrical supply). Door tension not correctly adjusted for the decor The door is not opening or closing properly door. Light failure - Contact CDA Customer Care for The internal light is not working replacement Knocking or tapping noise during cycle...

  • Page 28: Electrical Information

    Electrical Information Warning! This appliance must be earthed. Green and yellow to earth Brown to live 13A Fuse Cord Clamp Blue to Neutral The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug, follow the steps below: 1.
  • Page 29 As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:- • The wire which is coloured GREEN and YELLOW must be connected to the terminal which is marked with the letter (E) or by the Earth symbol or coloured GREEN and YELLOW.

  • Page 30: Installation

    Installation • Do not install this appliance if it is damaged in any way. Installing a damaged appliance may invalidate the warranty and could cause further damage to the surrounding area. • Do not hold the appliance by the door or control panel to move it as this may cause damage.
  • Page 31 There is a template supplied in the bag of fixings with detailed dia- grams on fitting the appliance. Figures 18 and 19 on page 32 show the recommended installations of our dishwashers. The set-ups in these figures should be mimicked wherever possible to help to ensure the best performance of the appliance.
  • Page 32 • Use the additional fitting template and kit supplied with the appli- ance to fit the appliance into the cabinetry, secure it and fit and secure the decor door. • Adjust the dishwasher door hinge tension as necessary to ensure the appliance door opens and closes properly and safely with the decor door attached.
  • Page 33 Fitting the integrated appliance door Where non-standard integrated appliance doors are supplied, additional fitting instructions are Fitting template required to ensure compatibility with this product. The machine is supplied with Fig. 21 a fitting template and these instructions should be followed as normal.

  • Page 34: Warranty And Service

    Warranty and service The manufacturer shall not be held liable for any damage caused by improper use of the product. • Repairs carried out by unqualified persons may seriously endanger the appliance user • Pursuant to Commission Regulation (EU) 2019/2023, The minimum availability period for spare parts necessary to repair the appliance is 7 or 10 years depending on the type and purpose of the spare part...
  • Page 35 Notes...
  • Page 36 The CDA Group Harby Road Langar Nottinghamshire NG13 9HY Sales Department Phone: 01949 862010 Email: sales@cda.eu CDA Customer Care Phone: 01949 862012 Email: customer.care@cda.eu ©2020 CDA Group Ltd...
