Summary of Contents for Baumatic BR23.8A
- Page 1 BR23.8A Combi fridge/freezer...
- Page 2 USER MANUAL FOR YOUR BAUMATIC BR23.8A Combi fridge/freezer NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.
-
Page 3: Table Of Contents
Important safety information Specifications of your combi fridge freezer Description of your appliance Description of the product features Using your Baumatic combi fridge freezer Before switching on During first use Turning on the appliance and setting the thermostat Control panel... -
Page 4: Environmental Note
Environmental note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. -
Page 5: Important Safety Information
Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Technical Department. - Page 6 Do not place electrical devices inside of the appliance, such as mixers and electric ice cream makers. Service You should not attempt to repair the appliance yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Baumatic Service Department.
-
Page 7: Specifications Of Your Combi Fridge Freezer
Specifications of your combi fridge freezer Congratulations on purchasing a Baumatic double door fridge freezer o Automatic defrost (fridge section only) o Adjustable thermostat o Fast freeze switch o Temperature rise warning light o Egg rack o Butter compartment o Bottle rack... -
Page 8: Description Of Your Appliance
Description of the appliance 1. Control Panel 2. Refrigerator shelf 3. Crisper cover 4. Crisper 5. Bottle shelf 6. Middle shelves 7. Butter shelf 8. Butter shelf cover 9. Egg shelf 10. Refrigerator lamp and cover 11. Freezer flap 12. Freezer compartment drawer 13. -
Page 9: Description Of The Product Features
1) Shelves o The shelves may be placed in any of the guide slots within the interior of the appliance. They are protected from sliding out. o To remove a shelf: Take off all of the items that are stored on the shelf that you want to remove. -
Page 10: Using Your Baumatic Combi Fridge Freezer
Using your Baumatic combi fridge freezer Before switching on o Make sure that it has been installed by a suitably qualified person, as per the information contained in Baumatic’s installation instructions. o After delivery, wait for eight hours before connecting the appliance to your mains supply. -
Page 11: Turning On The Appliance And Setting The Thermostat
You switch on your appliance by connecting it to your mains supply and setting the thermostat. The thermostat is located on the control panel, which can be found between the fridge and freezer sections. o The thermostat automatically regulates the temperature inside the refrigerator, depending on what number you have turned the thermostat control knob to. -
Page 12: Control Panel
o Super freeze light- will light up when the super freeze button has been turned on. o Power light- will light up as soon as the appliance is connected to your mains supply. o Temperature rise warning light- will light up when the appliance detects a rise in temperature that could affect the contents of your fridge freezer. -
Page 13: The Freezer Compartment
and acid in butter, can cause damage to the plastic parts contained inside of the refrigerator. o Do not open the refrigerator door too often or leave the door open for long periods of time, as this will increase the temperature inside of the appliance. -
Page 14: Freezing Fresh Food
o To freeze the maximum quantity of fresh food specified above, you should you should follow the “Freezing with Super Freeze” section on page 15, 24 hours prior to attempting freezing. o For smaller quantities of fresh food, you should you should follow the “Freezing with Super Freeze”... -
Page 15: Making Ice Cubes
o If you are freezing liquid, then do not fill the o Do not place bottles (glass or tin) Making ice cubes o Fill the ice cube tray with water and place it in the freezer compartment. o After the water is completely frozen and turned to ice, you can twist the ice cube tray (as shown in the drawing below) to dispense the ice. -
Page 16: Cleaning And Maintenance
Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO CLEAN IT. o Do not clean the appliance by pouring water onto it or spraying water over it. o The refrigerator and freezer compartment should be cleaned periodically, using a solution of bicarbonate of soda and lukewarm water. -
Page 17: Defrosting The Freezer Compartment
cleaned periodically with the defrost drain plug. This will prevent water from collecting in the bottom of the refrigerator, instead of flowing down the defrost drainage channel and drain hole. o You can also pour a small amount of water down the drain hole to clean inside of it. - Page 18 o Your appliance is fitted with a defrost drainage tube. Therefore you should pull out the bottom drawer (A) and place it on the floor in front of the appliance. o The defrost drainage tube (B) is located on the back wall of the freezer.
-
Page 19: Replacing The Light Bulb
WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO REPLACE THE LIGHT BULB. o There is an interior light in the top of the refrigerator section. o Press the hooks on the sides of the light cover and slide the cover off. -
Page 20: Installation
Installation IMPORTANT: Before installation and usage, read all the instructions and make sure tha voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found on the front left edge of the inside of the refrigerator. -
Page 21: Positioning
o It is advisable that your appliance is only installed in a location where the ambient temperature of the room, corresponds with the climate classification that is stated on the rating plate of your appliance. Your appliance may not function correctly if the ambient temperature falls outside of the following ranges. -
Page 22: Aperture And Appliance Dimensions
Aperture and appliance dimensions 2) Figure 2 shows the aperture size that you will need to be able to install your appliance. o The appliance must be stood on a level floor. You can use the leveling feet to take into account any minor unevenness in the floor. -
Page 23: Installing Your Fridge Freezer
If you need the appliance door to open from the other side, then please reverse the door before commencing the installation process. (See Reversing the door section). 5) Cut the sealing strip so that is the same height as the height of the aperture. - Page 24 6) Align the front feet of the a with the front edge of the kitchen unit x the front feet into position using the Ø4 x 17 fixing screws (e). ) Screw the top fixing bar to the underneath of the kitchen unit using the Ø4 x 17 fixing screws (e).
- Page 25 9a) Fit the door guides (d) to the appliance doors but do not secure them at this stage. Perform the following steps on one appliance door at a time. o Open the furniture door and the appliance door to their fullest positions.
- Page 26 with the furniture door. o From the edge of the furniture door, using a pencil you should mark a distance, which is the thickness of the cabinet wall + 10 mm. This is where the edge of the door slide (c) should be placed, in line with the door guide (d).
-
Page 27: Reversing The Door Of Your Appliance
Caution! After unscrewing any of the fixing hinges, hold the door to prevent it from fall and causing damage. Any parts that you remove from the appliance whilst reversing the door, should be retained for later use. Remove t he upper hinge cover from both sides of the appliance. WHILST SUPPORTING THE UPPER DOOR. - Page 28 o Tilt the appliance backward at a maximum angle of 35°. Unscrew the leg support screws (C) - left and right, and remove the leg support cover (D). Then place it on the opposite side. Unscrew, remove and then replace the position of the end switch (E) and decorative peg (F) (for models with forced door closing system).
-
Page 29: Troubleshooting
PORTANT: If your fridge freezer appears not to be operating properly, before contacting the Baumatic Service Department, please refer to the checklist below. My fridge freezer does not appear to be working/there is no power to my appliance. Check that the plug is fully inserted into the power socket. -
Page 30: Baumatic Ltd. Conditions Of Guarantee
Baumatic appliance. * In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fitte defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date. -
Page 31: Contact Details
Headquarters Baumatic Ltd. Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0 , United K Sales Telephone +44 118 933 6900 Sales Fax +44 118 931 0035 Service Telephone +44 118 933 6911 Service Fax +44 118 986 9124 Spares Telephone...
