Summary of Contents for Baumatic BR16.5
- Page 1 BR16.5 Larder fridge...
- Page 2 USER MANUAL FOR YOUR BAUMATIC BR16.5 Larder fridge NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference. for you or any person not familiar with the operation of the appliance.
-
Page 3: Table Of Contents
Specifications of your larder fridge Dimensions Description of the appliance Description of the product features 10-11 Using your Baumatic larder fridge Before switching on During first use Turning on the appliance and setting the thermostat Arranging and storing food in your refrigerator... -
Page 4: Environmental Note
Environmental note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. -
Page 5: Important Safety Information
Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department. - Page 6 Service You should not attempt to repair the appliance yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Baumatic Customer Care Department.
-
Page 7: Specifications Of Your Larder Fridge
Specifications of your larder fridge o Gross capacity: 137 litres o Net capacity: 136 litres o Automatic defrost o Adjustable thermostat o Egg rack o 3 safety glass shelves o 2 salad crispers o Reversible door Dimensions of appliance Height: 875 mm Width: 540 mm... -
Page 8: Description Of The Appliance
Description of the appliance Refrigerator shelf Crisper cover Crisper Thermostat control Egg shelf Bottle shelf Butter shelf Butter shelf cover... -
Page 9: Description Of The Product Features
Description of the product features 1) Shelves o The shelves may be placed in any of the guide slots within the interior of the appliance. They are protected from sliding out. o To remove a shelf: Take off all of the items that are stored on the shelf that you want to remove. -
Page 10: Using Your Baumatic Larder Fridge
IMPORTANT: IT IS IMPORTANT THAT NONE OF THE SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE. Using your Baumatic larder fridge Before switching on o Make sure that it has been installed by a suitably qualified... -
Page 11: Turning On The Appliance And Setting The Thermostat
Turning on the appliance and setting the thermostat You switch on your appliance by connecting it to your mains supply and setting the thermostat. The thermostat is located on the upper right hand side of the inside of the cabinet, next to the interior light. o The thermostat automatically regulates the temperature inside the refrigerator, depending on what number you have turned the thermostat control knob to. -
Page 12: Arranging And Storing Food In Your Refrigerator
Arranging and storing food in your refrigerator o Warm food or evaporating liquids should not be stored in your refrigerator, as this will increase the humidity inside of the appliance. o All foods should be wrapped or covered, this is particularly important if the food has a strong flavour. -
Page 13: Saving Energy When Using Your Refrigerator
o Milk bottles should have a cap on them and be stored on the bottle shelf that sits in the door. o Garlic, potatoes, onions and bananas should only be stored in a refrigerator IF they are stored in airtight containers. -
Page 14: Cleaning And Maintenance
Disposing: If you're going to throw out your old fridge, see if there's a chlorofluorocarbons (CFCs) recycler your area. government department which looks after the environment in your area may be able to help you. Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS... -
Page 15: Defrosting The Refrigerator Compartment
Defrosting the refrigerator compartment o Defrosting occurs automatically in the refrigerator section during operation. The defrost water is collected by the evaporating tray and evaporates automatically. o The evaporating tray and defrost water drain hole should be cleaned periodically with the defrost drain plug. This will prevent water from collecting in the bottom of the refrigerator, instead of flowing down the defrost drainage channel and drain hole. -
Page 16: Installation
o Change the present light bulb with a new one. The replacement bulb should not have a greater rating than 15 W. o Replace the light cover and after waiting five minutes, reconnect your plug to your mains supply. Installation IMPORTANT: Before installation... -
Page 17: Positioning
The green and yellow wire must be connected to the terminal marked “E” (earth), or by the earth symbol, or coloured green and yellow. o When the connection is completed, no stray strands or cut wire should be present. The cord clamp must be secured over the outer sheath. -
Page 18: Aperture And Appliance Dimensions
1) Your appliance requires ventilation. The minimum amount of ventilation that it requires is shown in figure 1. Aperture and appliance dimensions 2) Figure 2 shows the aperture size that you will need to be able to install your appliance. o The appliance must be stood on a level floor. -
Page 19: Supplied Installation Components
Supplied installation components Top fixing bar Sealing strip Door slider Door guide Fixing screws (Ø4 x 17) Fixing screws (Ø4.2 x 9.5) Installing your refrigerator If you need the appliance door to open from the other side, then please reverse the door before commencing the installation process. - Page 20 5) Cut the sealing strip so that is the same height as the height of the aperture. o Stick the sealing strip onto the side of the aperture that the appliance door will open from. o Carefully lift the appliance and place it into the aperture of the kitchen unit...
- Page 21 7) Screw the top fixing bar to the underneath of the kitchen unit using the Ø4 x 17 fixing screws (e). 8a) Fit the door guides (d) to the appliance door but do not secure them at this stage. o Open the furniture door and the appliance door to their fullest positions.
-
Page 22: Reversing The Door Of Your Appliance
o Using a pencil, mark where the edge of the appliance door meets with the furniture door. o From the edge of the furniture door, using a pencil you should mark a distance, which is the thickness of the cabinet wall + 10 mm. -
Page 23: Troubleshooting
Troubleshooting IMPORTANT: If your refrigerator appears not to be operating properly, before contacting the Baumatic Customer Care Department, please refer to the checklist below. My fridge does not appear to be working/there is no power to my appliance. - Page 24 o The thermostat setting is too low, you should turn the thermostat up higher. o Ensure that the door is closing properly and that the door has not been opened for a prolonged period in error. o Ensure that there is adequate ventilation for your appliance. My fridge is noisy o The refrigerant gas that circulates the pipe work of the appliance may make a slight noise, even if the compressor is not running.
- Page 25 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...
-
Page 26: Baumatic Consumables
BC005 Stainless Steel Cleaner and Protector (250ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.uk... -
Page 27: Technical Data
Technical Data Manufacturer BAUMATIC LTD Model Number BR16.5 Product Category 1 - Refrigeration Energy Efficiency Class (1) Annual Energy Consumption (2) 124 kWh Storage Volume of Fridge 136 litres Compartment Storage Volume of Freezer Compartment Star Rating Frost Free Compartments... -
Page 28: Contact Details
United Kingdom Baumatic Ltd., Baumatic Buildings, Czech Republic 6 Bennet Road, Baumatic CR spol s.r.o. Reading, Berkshire Lípovà 665 RG2 0QX 460 01 Liberec 4 United Kingdom Czech Republic +420 483 577 200 Sales Telephone (0118) 933 6900 Sales Fax www.baumatic.cz...
