SERVICE MANUAL
Ver. 1.0 2008.12
• The tuner and CD sections have no adjustments.
AUDIO POWER SPECIFICATIONS
(US model)
CEA2006 Standard
Power Output: 17 Watts RMS × 4 at
4 Ohms <1 % THD + N
SN Ratio: 82 dBA
(reference: 1 Watt into 4 Ohms)
CD Player section
Signal-to-noise ratio: 120 dB
Frequency response: 10 – 20,000 Hz
Wow and fl utter: Below measurable limit
Tuner section
FM
Tuning range:
US model: 87.5 – 107.9 MHz
AEP, UK, IT, EA model: 87.5 – 108.0 MHz
E, MX model:
87.5 – 108.0 MHz (at 50 kHz step)
87.5 – 107.9 MHz (at 200 kHz step)
RU model:
FM1/FM2: 87.5 – 108.0 MHz (at 50 kHz step)
FM3: 65 – 74 MHz (at 30 kHz step)
FM Tuning interval:
E, MX model: 50 kHz/200 kHz switchable
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 150 kHz
Usable sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
Signal-to-noise ratio: 70 dB (mono)
Separation: 40 dB at 1 kHz
Frequency response: 20 – 15,000 Hz
Sony Corporation
9-889-377-01
2008L04-1
Audio&Video Business Group
©
2008.12
Published by Sony Techno Create Corporation
CDX-GT730UI/GT737UI/
Photo: CDX-GT730UI: AEP, UK, Italian model
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
AM (US, E, EA, MX model)
Tuning range:
US model: 530 – 1,710 kHz
EA model: 531 – 1,602 kHz
E, MX model:
531 – 1,602 kHz (at 9 kHz step)
530 – 1,710 kHz (at 10 kHz step)
AM Tuning interval:
E, MX model: 9 kHz/10 kHz switchable
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 25 kHz
Sensitivity: 26 μV
MW/LW (AEP, UK, IT, RU model)
Tuning range:
MW: 531 – 1,602 kHz
LW: 153 – 279 kHz
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 25 kHz
Sensitivity: MW: 26 μV, LW: 45 μV
FM/AM COMPACT DISC PLAYER
FM/MW/LW COMPACT DISC PLAYER
GT780UI
AEP Model
Russian Model
CDX-GT63UIW/GT630UI/
GT637UI
MG-101Z-188//Q
DAX-25A
USB Player section
Interface: USB (Full-speed)
Maximum current: 500mA
Power amplifi er section
Outputs: Speaker outputs (sure seal connectors)
Speaker impedance: 4 – 8 ohms
Maximum power output: 52 W × 4 (at 4 ohms)
– Continued on next page –
CDX-GT730UI: US model/GT780UI
CDX-GT730UI: AEP, UK, Italian model/GT737UI
US Model
UK Model
CDX-GT730UI
E Model
CDX-GT780UI
CDX-GT737UI
