SERVICE MANUAL
Ver. 1.0 2009.07
• BDV-E800W is composed of following models.
As service manuals are issued for each component model, please
refer to them.
COMPONENT MODEL NAME
BD/DVD receiver
Front speaker
Center speaker
Surround speaker
Subwoofer
Surround amplifi er
Wireless transceiver (AEP model)
Wireless transceiver (Except AEP model)
DIGITAL MEDIA PORT adapter (Australian model)
Note: As for EZW-RT10A and TDM-iP20, the part number has been described to
this service manual.
General (BDV-E800W)
Power requirements
Power consumption
Output voltage/current
(DIGITAL MEDIA PORT)
LAN (100)
EXT
Dimensions (approx.)
Mass (approx.)
Wireless transceiver (EZW-RT10/EZWRT10A*)
Communication system
Frequency band
Modulation method
Power requirements
Dimensions (approx.)
Mass (approx.)
* European models only.
General (TDM-iP20: Australian model)
Power requirements:
Dimensions:
Mass:
Cable length:
Supplied items:
Design and specifi cations are subject to change without notice.
9-889-590-01
2009G05-1
©
2009.07
Taiwan model: 120 V AC , 50/60Hz
Other models: 220 V - 240 V AC, 50/60Hz
On: 120 W
Standby: 0.3 W
(at the Power Saving mode)
DC 5 V/700 mA
100BASE-TX Terminal
External memory slot
(For connecting the external memory)
DC output: 5 V 500 mA Max
430 mm × 93 mm × 400 mm (w/h/d) incl.
projecting parts
430 mm × 93 mm × 430 mm (w/h/d)
(incl. Wireless transceiver)
5.4 kg
S-AIR Specifi cation version 1.0
2.4000 GHz - 2.4835 GHz
DSSS
DC 3.3 V, 350 mA
50 mm × 13 mm × 60 mm (w/h/d)
24 g
DC IN: 5 V, 0.6 A
(via DIGITAL MEDIA PORT)
Approx. φ 80 × 22(h) mm
Approx. 132 g (including cable)
Approx. 1 m
TDM-iP20 (1)/Operating Instructions (1)
Sony Corporation
Audio&Video Business Group
Published by Sony Techno Create Corporation
BDV-E800W
BDV-E800W
HCD-E800W
SS-TSB91
SS-CTB91
SS-TSB91
SS-WSB91
TA-SA100WR
EZW-RT10A
EZW-RT10
TDM-iP20
SPECIFICATIONS
Unpacking
• Front speakers (2)
• Surround speakers (2)
• Center speaker (1)
• Subwoofer (1)
• FM wire antenna (aerial) (1)
• Speaker cords (2, green/purple)
• Video cord (1)
• Remote commander (remote) (1)
• R6 (size AA) batteries (2)
• Calibration mic (1)
• Foot pads (1 set)
• Bases (4)
• Screws (with washer) (12)
• Surround amplifer (1)
• Speaker cord cover (1)
• Speaker cord holder (1)
• Wireless transceivers (2)
• Operating Instructions
• Speaker Instruction Guide
• Quick Setup Guide
• Software Licence Information
• Wireless Product Safety Information (For European models)
• DIGITAL MEDIA PORT adapter (TDM-iP20) (1)
(For Australian model)
• Operating Instructions for DIGITAL MEDIA PORT adapter (TDM-iP20)
(For Australian model)
• HDMI cable (1) (For Singapore, Indoneseian, Malaysia, Hong Kong, and
Philippines models)
BD/DVD HOME THEATRE SYSTEM
AEP Model
Australian Model
Chinese Model
Saudi Arabia Model
Singapore Model
Taiwan Model
SYS SET
