Yaesu FTDX101MP Operation Refence Manual

Hide thumbs Also See for FTDX101MP:

Advertisement

Table of Contents

101MP
101D
CAT Operation Reference Manual
YAESU MUSEN CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Yaesu FTDX101MP

Summary of Contents for Yaesu FTDX101MP

  • Page 1 101MP 101D CAT Operation Reference Manual YAESU MUSEN CO., LTD.
  • Page 2 Visit the Yaesu website http://www.yaesu.com/ to download the Virtual COM port driver and Installation Manual. YAESU MUSEN does not produce CAT System operating software due to the wide variety of personal computers and operating systems in use today. However, the information provided in this chapter explains the serial data structure and opcodes used by the CAT system.
  • Page 3 Operation ( Computer Aided Transceiver ) When performing software port configuration, select the COM port numbers that were confirmed using the procedure above, use the two confirmed COM port numbers for each software function. The frequency and communication mode and PTT control can be set from the software, and CW keying, digital communication, etc. can be performed simultaneously. When performing software port configuration, select the COM port numbers that were confirmed using the procedure above. ・ If a “!” or “X” is displayed for the port on the Device Manager, uninstall and reinstall the virtual COM driver. ・ If a transceiver with a different serial number is connected and turned on, different COM port numbers will be assigned to it, making it possible to perform individual COM port configurations for separate transceivers.
  • Page 4 When using an RS-232C cable, the “PS” command (POWER SWITCH) is not available. Therefore, the transceiver cannot be turned ON with the CAT command. The FTDX101MP/FTDX101D transceiver has a built-in level converter, allowing direct connection from the rear- panel RS-232C jack to the serial port of your computer without the need of any external boxes.
  • Page 5 Unnecessary characters between parameters IS00+10000; Too many digits (Five frequency digits given) Note: If a particular parameter is not applicable to the FTDX101MP/FTDX101D, the parameter digits should be filled using any character except the ASCII control codes (00 to 1Fh) and the terminator (;). Terminator To signal the end of a command, it is necessary to use a semicolon (;). The digit where this special character must...
  • Page 6 Operation ( Computer Aided Transceiver ) Command Function Set Read Ans. Command Function Set Read Ans. MAIN BAND TO SUB NARROW Band NOISE BLANKER ANTENNA TUNER NOISE BLANKER LEVEL CONTROL NOISE REDUCTION AF GAIN OPPOSITE BAND AUTO INFORMATION INFORMATION MAIN BAND TO OFFSET (Repeater Shift) MEMORY CHANNEL PRE-AMP (IPO)
  • Page 7 Operation ( Computer Aided Transceiver ) MAIN BAND TO SUB BAND Read Answer ANTENNA TUNER CONTROL P1 0: Fixed P3 0: Tuner “OFF” P1 P2 P3 P2 0: Fixed 1: Tuner “ON” 2: Tuning Start / Tuning Stop Read Answer P1 P2 P3 AF GAIN P1 0: MAIN BAND...

  • Page 8: Band Select

    Operation ( Computer Aided Transceiver ) SUB BAND TO MAIN BAND Read Answer AUTO NOTCH P1 0: MAIN BAND P1 P2 1: SUB BAND P2 0: Auto Notch “OFF” Read 1: Auto Notch “ON” Answer P1 P2 BAND DOWN P1 0: MAIN BAND 1: SUB BAND Read Answer...

  • Page 9: Channel Up/Down

    Operation ( Computer Aided Transceiver ) BUSY P1 0: MAIN BAND RX BUSY “OFF” 1: MAIN BAND RX BUSY “ON” P2 0: SUB BAND RX BUSY “OFF” Read 1: SUB BAND RX BUSY “ON” Answer P1 P2 CHANNEL UP/DOWN P1 0: Memory Channel “UP” 1: Memory Channel “DOWN”...
  • Page 10 Operation ( Computer Aided Transceiver ) MIC DOWN Read Answer DATE AND TIME P1 0: Date P1 P2 P2 P2 P2 1: Time (UTC) P2 P1=0 yyyymmdd (Year/Month/Date) Read P1=1 hhmmss (Hour/Minute/Second, 24 hour time system) Answer P1 P2 P2 P2 P2 ENCODER DOWN P1 0: MAIN ENCODER 5: MAIN CONT ENCODER...
  • Page 11 Operation ( Computer Aided Transceiver ) Table 2 (MENU Chart) Function Digits AGC FAST DELAY 20 ~ 4000 msec (P4= 0020 ~ 4000, 20 msec/step) AGC MID DELAY 20 ~ 4000 msec (P4= 0020 ~ 4000, 20 msec/step) AGC SLOW DELAY 20 ~ 4000 msec (P4= 0020 ~ 4000, 20 msec/step) LCUT FREQ 00: OFF...
  • Page 12 Operation ( Computer Aided Transceiver ) Table 2 (MENU Chart) Function Digits RX USOS 0: DISABLE 1: ENABLE TX USOS 0: DISABLE 1: ENABLE RX NEW LINE CODE 0: CR or LF or CR+LF 1: CR,LF,CR+LF (RADIO SETTING) (ENC/DEC RTTY) TX AUTO CR+LF 0: DISABLE 1: ENABLE TX DIDDLE 0: OFF 1: BLANK 2: LTRS...
  • Page 13 01 ~ 10 HF MAX POWER 5 ~ 100 (P4 = 005 ~ 100) FTDX101D / 5 ~ 200 (P4 = 005 ~ 200) FTDX101MP 50M MAX POWER 5 ~ 100 (P4 = 005 ~ 100) FTDX101D / 5 ~ 200 (P4 = 005 ~ 200) FTDX101MP...

  • Page 14: Agc Function

    Operation ( Computer Aided Transceiver ) FREQUENCY MAIN BAND P1 000030000 - 075000000 (Hz) P1 P1 P1 P1 P1 P1 P1 P1 Read P1 P1 P1 P1 P1 P1 P1 P1 Answer FREQUENCY SUB BAND P1 000030000 - 075000000 (Hz) P1 P1 P1 P1 P1 P1 P1 P1 Read P1 P1 P1 P1 P1 P1 P1 P1...
  • Page 15 Operation ( Computer Aided Transceiver ) IDENTIFICATION P1 0681: FTDX101D 0682: FTDX101MP Read Answer P1 P1 P1 P1 INFORMATION P 0 0 0 1 - 0 9 9 ( M e m o r y C h a n n e l ) , P 1 L - P 9 U ( P M S ) , 5 x x ( 5 M H z B A N D ) ,...

  • Page 16: Memory Channel

    Operation ( Computer Aided Transceiver ) CW KEYING P1 1: Keyer Memory “1” Playback 6: Message Keyer “1” Playback 2: Keyer Memory “2” Playback 7: Message Keyer “2” Playback 3: Keyer Memory “3” Playback 8: Message Keyer “3” Playback Read 4: Keyer Memory “4”...

  • Page 17: Monitor Level

    Operation ( Computer Aided Transceiver ) MONITOR LEVEL P1 0: MONI “ON/OFF” 1: MONI Level P1 P2 P2 P2 P2 P1=0 000: MONI “OFF” Read 001: MONI “ON” P1=1 Answer 000 - 100 P1 P2 P2 P2 MEMORY CHANNEL READ P 0 0 0 1 - 0 9 9 ( M e m o r y C h a n n e l ) , P 1 L - P 9 U ( P M S ) , 5 x x ( 5 M H z B A N D ) , EMG (EMERGENCY CH) P2 VFO-A Frequency (Hz)

  • Page 18: Noise Reduction

    Operation ( Computer Aided Transceiver ) MEMORY CHANNEL WRITE P1 001-099 (Memory Channel), P1L -P9U (PMS) P2 Frequency (Hz) W P1 P1 P1 P2 P2 P2 P2 P2 P3 Clarifier Direction +: Plus Shift, --: Minus Shift Clarifier Offset: 0000 - 9990 (Hz) P2 P2 P2 P2 P3 P3 P3 P3 P3 P4 P4 0: RX CLAR “OFF”...

  • Page 19: Power Control

    4: DVS (CH “4” Playback Start) 5: DVS (CH “5” Playback Start) Answer P1 P2 POWER CONTROL P1 005 - 100 (FTDX101D) P1 P1 P1 005 - 200 (FTDX101MP) Read Answer P1 P1 P1 SPEECH PROCESSOR LEVEL P1 000 -100 P1 P1 P1...
  • Page 20 Operation ( Computer Aided Transceiver ) POWER SWITCH P1 0: POWER “OFF” 1: POWER “ON” This command requires dummy data be initially sent. Then after one second and before two seconds the command is sent. (For example, Send “PS1;” command, wait 1 second, Read and then Send “PS1;”...

  • Page 21: Radio Information

    Operation ( Computer Aided Transceiver ) RF GAIN P1 0: MAIN Band P1 P2 P2 P2 1: SUB Band P2 000 - 255 Read Answer P1 P2 P2 P2 RADIO INFORMATION P1 0: Hi-SWR 3: REC 4: PLAY Read P2 0: OFF 1: ON Answer P1 P2...

  • Page 22: Squelch Level

    Operation ( Computer Aided Transceiver ) CW BREAK-IN DELAY TIME 00: 30 01: 50 02: 100 03: 150 04: 200 05: 250 33: 3000 (msec) （06 to 33: 100 msec steps） 06: 300 07: 400 - 32: 2900 P1 P1 Read Answer P1 P1...

  • Page 23: Spectrum Scope

    Operation ( Computer Aided Transceiver ) SPECTRUM SCOPE P1 0: MAIN Band 1: SUB Band P1 P2 P3 P4 P5 P6 P7 P2 0: SPEED 1: PEAK 2: MARKER 3: COLOR 4: LEVEL 5:SPAN 6:MODE 7: AF-FFT/OSCILLOSCOPE 8: HOLD Read P2=0 (SPEED): P1 P2 P3 0: SLOW1 1: SLOW2 2: FAST1 3: FAST2 4: FAST3...
  • Page 24 Operation ( Computer Aided Transceiver ) PLL UNLOCK STATUS P1 0: PLL “Lock” 1: PLL “Unlock” Read Answer MIC UP Read Answer VOX DELAY TIME / DATA VOX DELAY TIME P1 00: 30 msec 01: 50 msec 02: 100 msec 03: 150 msec 04: 200 msec P1 P1 P1 P1 05: 250 msec 06: 300 msec - 33: 3000 msec (06 - 33: 10 msec multiples) VD command has different parameters to be changed according to the setting of Menu...
  • Page 25 Operation ( Computer Aided Transceiver ) TX CLAR P1 0: TX CLAR “OFF” 1: TX CLAR “ON” Read Answer ZERO IN (CW AUTO ZERO IN Function) P1 0: MAIN Band 1: SUB Band Read Answer...
  • Page 26 Copyright 2021 YAESU MUSEN CO., LTD. All rights reserved. No portion of this manual may be reproduced without the permission of YAESU MUSEN CO., LTD. YAESU MUSEN CO., LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan YAESU USA 6125 Phyllis Drive, Cypress, CA 90630, U.S.A.

This manual is also suitable for:

Ftdx101d
