Avaya 5402 Technical Tip

IP Office Technical Tip
Tip no:
Release Date:
Region:
Retrieving a Parked Call from a 5402 terminal
When retrieving a parked call from a 5402 terminal, the function key needs to be
pressed twice to retrieve the call.
shows "drop" and "answer", but there are no physical keys on the terminal to retrieve the
call.
On the 5402 phone, dial pad 1 through # are represented by buttons 4 to 15 in the user
button programming in the Manager application (Button 3 in the user programming is not
used as it is reserved.).
In the example below:
On button 4 in Manager (button 1 on terminal), Park slot 1 is programmed.
On button 5 in Manager (button 2 on terminal), Park slot 2 is programmed.
On button 6 in Manager (button 3 on terminal), Park slot 3 is programmed.
On button 7 in Manager (button 4 on terminal), Park slot 4 is programmed.
To retrieve a parked call in slot 1, press the feature button, then button 1 twice.
COMPAS ID 117201 Issue 1
127
13 March 2006
GLOBAL
After the first press of the function key, the display
Page 1 of 3
