KEYLESS ENTRY ALARM UPGRADE MODULE
Congratulations on your purchase of the PRO 9232 automotive Keyless Entry Upgrade
Alarm System. The PRO 9232 is a state - of - the - art auto security system that is
designed to automatically arm and disarm when it receives a command from your
existing Factory Keyless Entry Transmitter. Taking a few moments to read this manual
will help to ensure that your vehicle is protected at all times.
ARMING THE SYSTEM : ( ACTIVE )
1. Turn the ignition key off, exit the vehicle, and close all doors.
2. Press and release the Lock button on the keychain transmitter.
3. The siren and or horn will beep one time, the parking lamps will flash one time, and
the red dash mounted L.E.D. will begin to slowly flash, indicating that the system
is ARMED.
NOTE: If the unit beeps three times when arming, then one of the entry points
( hood, trunk, or doors ) has been left opened. Closing the hood, trunk,
or door will correct the problem, and the system will emit a single chirp
to confirm that the problem has been corrected. Additionally, if illuminated
entry is a feature of the Factory Keyless Entry system, the alarm may chirp
3 times every time the system is armed, and chirp one additional time
when the interior light turns off to confirm that all trigger zones are fully
operational.
4. Any time the door lock switch in the vehicle is used to lock the doors while the
ignition key is turned off, the system will immediately arm. To lock the doors after
entering the vehicle, make sure the ignition key is switched on first. Turning the
ignition key on first will stop the system from arming.
ARMING THE SYSTEM : ( PASSIVE )
1. Turn the ignition key off, exit the vehicle, and close all doors.
2. The dash mounted L.E.D. will begin to flash rapidly, indicating that the system is
automatically ( passively ) arming. As an added convenience, the 30 second
automatic passive arming will not begin until all doors are closed, allowing passengers
to exit the vehicle at their convenience.
Model PRO 9232
OWNER'S MANUAL
Advertisement
Related Manuals for Audiovox Pursuit PRO 9232
Summary of Contents for Audiovox Pursuit PRO 9232
- Page 1 KEYLESS ENTRY ALARM UPGRADE MODULE Congratulations on your purchase of the PRO 9232 automotive Keyless Entry Upgrade Alarm System. The PRO 9232 is a state - of - the - art auto security system that is designed to automatically arm and disarm when it receives a command from your existing Factory Keyless Entry Transmitter.
-
Page 2: Protection While The System Is Armed
3. In 30 seconds, you will hear a single short chip from the siren, and the vehicle’s parking lamps will flash one time, indicating that the system has ARMED. At this time, the red dash mounted L.E.D. will begin to flash slowly, providing a visual indication that the system is fully armed. -
Page 3: Using The Valet Switch
rapid flashing of the red dash mounted L.E.D. Opening one of the vehicle’s doors will suspend the passive arming process until all doors have been closed, or until the ignition key has been turned on. INTRUSION WARNING SIGNALS : The system will inform you if an intrusion attempt has occurred while you were away from the vehicle. -
Page 4: Manual Override Operation
2. Turn the ignition switch to the “On” position. 3. Press and hold the valet/override pushbutton switch for 5 seconds. The L.E.D. turns on, indicating valet mode has been successfully entered. TO EXIT VALET: With the ignition switch in the on position, press and release the valet/override pushbutton switch one time. - Page 5 different code than was pre-assigned from the factory. To Change the pre-assigned override code follow the steps outlined below. It is advised you read both sections under the headings “Programming Your Custom Override Code” and, “Custom Code Programming Example”, To completely understand the procedure before beginning: Programming Your Custom Override Code: Unlike override switches easily found, and defeated, the PRO-9232 allows the...
- Page 6 4. Within 10 seconds turn the ignition switch off, on, off, on, off, on. (The siren or horn will beep and the lights will flash one time.) 5. Within 10 seconds, begin to press and release the push button switch to set the tenths digit.
- Page 7 ELIMINATING THE ARM / DISARM CHIRPS : The normal arming and disarming confirmation chirps can easily be turned off using the valet pushbutton switch. To do this; 1. Turn the ignition key on, and then off. 2. Within 10 seconds of turning the ignition key off, press and release the valet switch 3 times.
- Page 8 3 FLASH Your System Has These Features Activated: Starter Disable When Armed Passive Arming Instant Trigger Remote Car Starter Remote Window Open © 1998 Audiovox Corp. 150 Marcus Blvd. PASSIVE ARMING DISARMED VALET MODE INTRUSION ZONE 3 INTRUSION ZONE 2...
