AUDIOVOX
CDM-4500
Dual Mode CDMA/AMPS
Handheld Portable
Cellular Telephone
In today's fast paced world, it has become a necessity to have access to real-time information. Your communications
tools must provide you with this access. With that in mind, Audiovox developed the CDM-4500.
This CDMA 800 MHz/Amps dual mode phone is our first with a built-in Web Browser. The CDM-4500 also features a
Vibrating Alert Option, Voice Recognition and Data Capabilities. In addition, the phone features a Lithium Ion battery
providing you with 190 minutes of talk time and 170 hours of stand-by, an Enhanced Phone Book with 99 Alpha/198
Numeric Memory Locations; One touch emergency dialing; 15 distinctive ring tones and Menu Driven Operation.
The CDM-4500 digital cellular telephone has several optional accessories available, including: leather carrying case,
cigarette lighter plug-in charger, desktop holder, AC adapter, Hands-free car kit and earphone microphone.
And, of course, your new CDM-4500 digital handset provides you with something only an Audiovox phone can: the
proven reliability that has made us one of the leading wireless handset providers.
Please take a few moments to read the following pages of the user's operation manual. It will help you make the most
efficient use of this valuable communications tool.
SYSTEM CONFIGURATION
System configuration and the equipment list are as shown below

Advertisement

Table of Contents
loading

Related Manuals for Audiovox CDM-4500

Summary of Contents for Audiovox CDM-4500

  • Page 1 With that in mind, Audiovox developed the CDM-4500. This CDMA 800 MHz/Amps dual mode phone is our first with a built-in Web Browser. The CDM-4500 also features a Vibrating Alert Option, Voice Recognition and Data Capabilities. In addition, the phone features a Lithium Ion battery providing you with 190 minutes of talk time and 170 hours of stand-by, an Enhanced Phone Book with 99 Alpha/198 Numeric Memory Locations;...

  • Page 2: Wrist Strap Attachment

    WRIST STRAP ATTACHMENT Attach the wrist strap to the phone through the strap hole as shown below 1 Then pull the long loop through the smaller loop as shown below 2 BATTERY INSTALLATION AND RECHARGING To Attach the Battery Pack Insert the hook at the end of the Battery Pack into the slot at the end of the phone.

  • Page 3: To Recharge Battery

    TO RECHARGE BATTERY Your CDM-4500 has a built-in charger function. To re-charge the Battery Pack, always install the Battery Pack to the phone. Attach the Battery pack to the Phone Insert the DC plug of the Ac Adapter (CNR-4000) to the Desktop Holder (DTH-4000). Plug the AC Adapter to AC outlet.

  • Page 5: Basic Operation

    Press for more than one second. All the indicators and the digit display will light momentarily, and a tone will be heard. The indicator will stay while the phone is turned on. To turn the phone off, press second.. Antenna Position The antenna can be used in its fully extended or fully retracted position only.
  • Page 6 To Correct a Number · Press to clear the last digit. Press and hold to erase all the digits entered. If the Call Fails to Go Through · Press , and to redial the number. To Terminate a Call Press .
  • Page 7 Press a digit key ( The number in your phonebook is automatically dialed. The phone number will be displayed. The “ will light. NOTE: The key is not for Quick Dialing, but for ONE TOUCH EMERGENY CALL. Emergency Call This feature permits you to place an emergency call even if your telephone is in “Phone Lock”, “Keypad Lock” or “Restrict”...
  • Page 8 “Called XX”.”XX is the number of calls (01 to 99) missed. Depressing any key will clear the display. Ringing Tone with Melody The CDM-4500 offers you 15 styles of ringer tones and melodies for alerting incoming calls. Ringer volume can also be adjusted.
  • Page 9 Press to answer the new call. Press again to switch between the two calls. Three- way Calling Your Service provider may provide Three-Way calling service. When a call is already in progress, you may call the Third party. Enter a number and press Press again to connect all three parties.

  • Page 10: Phonebook Operations

    Press and scroll to “Tone”. Press . The number in the display will be sent in Touch Tone™ signals. Your phone has an Enhanced Phonebook with 99 dual-number memory addresses. At each address, you can store up to two telephone numbers under one name, a person’s home and office number, office and mobile number, etc. Stored numbers can be easily recalled and dialed by pressing Number of Digits per Phonebook Address To program your phonebook, enter the information in the following order.
  • Page 11 Example: To store the number 9 8 7 6 5 4 3 2 1 0 in the address 07, where another number 1 2 3 4 5 6 7 8 9 0 is already stored. Press Enter Press Enter . The number already stored is displayed momentarily. Two seconds later.
  • Page 12 of a previously stored number. Enter the phone number. Press Example: To store the phone number 1 2 3 4 5 6 7 8 9 0 into a vacant memory address 04. Press Enter Press Press To Store Dual Numbers in Phonebook You can store Dual Numbers with Dual Mark “...
  • Page 13 Enter the phone number; . Set Alpha Mode; Enter the Name; for “M”, for “C”, for “K”, “N”. Press Enter and press Alpha Mode You can add an identifying name (“Alpha Tag” up to 2 lines or 20 to 24 characters) to the phone numbers at each phonebook address.
  • Page 14 Assigned Special Characters If you make a mistake, press display Press to move the cursor, which insets a blank space after the last character. Press to move the cursor back to insert new characters. To exit the Alpha Mode, press Note: You must enter the phone number first, then add the name.
  • Page 15 Press key. The following “RECALL” menu will prompt you to recall the number from memory. “ADDRESS”: Phonebook Address Mode · “SEARCH”: Phonebook Sort Scroll Mode or Phonebook Key Word Search Mode · “HISTORY”: Call History Mode · Recall Menu Tree Notes: 1.
  • Page 16 Note: The scroll feature will skip any vacant memory address(es). Phonebook Sort Scroll Mode This mode sorts and displays, in alphabetical order, telephone numbers stored with “Alpha Tags” (Names). Blank digits on tip will be disregarded for scroll. Example: To display the numbers stored in the memory alphabetically from “J”. Press Press for “J”.
  • Page 17 ever, a call can be made by simply pressing To Dial Dual Numbers After the numbers is recalled in the display, it can be easily called by pressing . To dial the primary number, just press . · To dial the secondary number, press ·...
  • Page 18 To Modify Phone Numbers Recall the number from the phonebook. Press Enter the new digit(s) and delete the old digits(s) by pressing right. To Modify Alpha Name Tag Recall the number and proceed to “MODIFY” as above. Press to clear the letter(s), and enter the new Name. To Modify Address After you modified number/name, just press be overwritten.
  • Page 19 Example: To move the number 1 2 3 4 5 6 7 8 9 0 from the address 20 to 15. Recall the number stored in the address 20. Press and scroll to “MOVE”. Press Enter as a new address. To Change Priority of Dual Numbers You can interchange the primary and the secondary numbers in a phonebook address.
  • Page 20 Example: To store the phone number 1 2 3 4 5 6 7 8 9 0 in address 30 as a secret number Press Enter Press Press and scroll to “SECRET”. Press Press to put a mark “ Press Enter and press To Recall a Secret Number Example: To recall the number 1 2 3 4 5 6 7 8 9 0 stored in the address 30.
  • Page 21 Press , then enter the memory address (01 ~ 99). Example: To link 3 numbers and store in Address 35. Enter Press Press Enter Press Press Enter Press Note: While entering a linked number, you may review all the parts of that number, even those already entered. Press , scroll to “VIEW TEL#”...
  • Page 22 again. If the registration is successful, you will hear the prompt “Entry Completed”. Your voice registration is displayed. And your phonebook status is displayed. Notes: 1. Please register names with you normal tone of voice, and in a quiet environment. 2.
  • Page 23 Press to recall the number from the phonebook. Press , scroll to “ERASE” and press Scroll to “VOICE DATA” and press You will have on the screen “VOICE DATA ERASE”. Scroll to “YES” and press This feature recalls outgoing Call History and incoming Caller ID Numbers. This is convenient for redialing recently called numbers of for returning missed calls by using the stored Caller ID.
  • Page 24 Press . The most recent call is displayed. Scroll with to review other numbers. You can place a call by simply pressing When duplicate numbers are called, only the latest call is stored in the outgoing call history memory. To Review Incoming Call History Example: To recall a received Caller ID from Memory Stack.

  • Page 25: Web Browsing

    When operating in the Digital mode, you can access various internet websites directly from your cellular phone. Please contact your Service Provider for details of the available service. Web Access Press and hold . The Web Browser will start. The cached information may be displayed. Press and hold , your phone will access the network, and desplay your service provider’s website.

  • Page 26: Alphabet Mode

    Alphabet Mode Symbol Mode Your CDS-4500 Audiovox Cellualar Telephone has been engineered to operate with the latest technology that will allow you to enjoy the benefit of Voice Mail Notification and Text Messages. Please note that operation of these features depends on the Cellular System and therefore may not bew available in all areas.
  • Page 27 In addition to the indicator, whenever your Voice Mail contains unreviewed messages, you will occasionally hear a short beep as a reminder. Voice Mail Notification Your cellular telephone notifies you when new messages are in you Voice Mail. When messages are left in your Voice Mail, the indicator at the upper right of the display flashes to alert you.
  • Page 28 Press . Scroll to “QUIT” or “ERASE” the notification you reviewed. Press To erase the Voice Mail Notification, scroll to “YES”, otherwise NO”, and press Voice Mail Dialing You can store one set of linked numbers in a specially provided memory, and access these numbers with one touch of the “Voice Mail Access”...

  • Page 29: Function Menu

    when a new message is available. Press . The first Text Message is displayed. A longer message will be automatically scrolled every 6 seconds. Press or wait for 6 seconds to review an optional information. Press or wait for 6 seconds. If a Callback Number is displayed, you can dial it by simply pressing Press and scroll “QUIT”...
  • Page 30 Each Function has its shortcut number for direct access. For example, to enter the function “RING TYPE” (F32) press To Exit from Function Menu To return from a submenu to the main menu, press · To exit from Function Menu, press ·...
  • Page 31 Function Menu Tree Lock Features Security Code and Unlock Code...
  • Page 32 Your phone is equipped with the Security Code and the Unlock Code to access various security features. You may change the preset codes for added protection. y t i Keypad Lock (F11) This mode is used for preventing inadvertent pressing of keys. (For example, when the phone is in a purse or pocket.) With this feature on, the following functions are still available.
  • Page 33 turn the phone on, you must enter the four-digit unlock code before it operates. Press You can turn this feature on/off by Press to set. To Unlock the Phone Enter the four-digit unlock code. The “Phone Lock” indicator will go out. To Change the Unlock Code (F14) Press Enter the four-digit security code and press...
  • Page 34 Backlight is on momentarily when the power is first turned on, but remains off thereafter. ALWAYS ON – Always On Mode · Backlight is always on. Note: You can keep the backlight on while you are engaged in conversation. See Backlight Control (In-Use) (F22-2). Backlight Control (In-Use) (F22-2) For ease of operation, you may select to have the backlight always on while you are engaged in a conversation.
  • Page 35 Press to exit. Last Rescan SID Indicator (F27) This menu permits you to review the Preferred Roaming List (PRL) versions that is programmed in you phone. Press Press to exit. PRL ID Review (F28) This menu item permits you to view the Preferred Roaming List (PRL) version that is programmed in your phone. 1.
  • Page 36 You can mute your conversation at any time during a call. Press Then the “Mute” indicator is displayed. The transmit audio will be muted but the receive audio will still be heard from the receiver. To return to normal conversation, press Mute is reset when the call is terminated.
  • Page 37 Voice Mail contains messages that have not been reviewed. Press You can turn this feature on/off by Press to set. Text Message Alert (F36-4) This feature audibly alerts you when a Text Message is received. Press You can turn this feature on/off by Press to set.
  • Page 38 Press You can turn this feature on/off by Press to set. Low Battery Alarm (F36-9) When activated, this feature warns by an audible alarm when the battery level is low. If the alarm is given, recharge the battery or replace it with a fully charged battery. Press You can turn this feature on/off by Press...
  • Page 39 Press to exit. Clock Indicator (F42) When the phone is in an area with digital service (Digital Mode) with this feature enabled, the date and tie are automati- cally displayed. Press You can turn this feature on/off by Press to set. A/B System Selection (F51) This feature permits you to select which cellular system (A or B) your phone uses.
  • Page 40 Some cellular users may find it beneficial to register their phones with multiple numbers, for different cities where they may frequently travel. To provide this ability, your phone has two NAMs (Number Assignment Modules) enabling up to two registrations. If you have multiple registrations, the NAM Selection feature enables you to change the NAM being used by your phone.
  • Page 41 Privacy Mode. Anti Fraud Security Features Your new Audiovox Cellular telephone has been engineered with the latest technology to help protect from the fraudulent use of your cellular telephone number. You phone is equipped with Authentication and PIN (Personal Identification Number) Dialing.
  • Page 42 To Place a Call with the Automatic PIN Feature Enter the number you are calling, or recall the number from a specific memory location. Press “SEND” key . As your call is being processed, you will the display: Press “SEND” key again.
  • Page 43 Press to set. The available Restriction modes are as follows: 11DIGITS – 11 Digits Mode · Only phone numbers of 11 digits or less are accepted. Operator assisted dialing is prohibited. 7DIGITS – 7 Digits Mode · Only phone numbers of 7 digits or less are accepted. Operator assisted dialing is prohibited. OPERATOR –...
  • Page 44 Press Enter the four-digit security code and press The current security code is displayed. Enter a new four-digit security code and press Reset Functions (F65) This is a group of several functions for Function/Memory Reset. Press Enter the four-digit security code and press Call Timer Reset (F65-1) This feature resets all the following three Cal Timers;...
  • Page 45 Data/Fax Mode (F71) Your CDM-4500 will work as a wireless modem, if connected to a PC with the optional data cable (DIC-4000). When operating in the Digital mode, the phone can be used for Async Data or Fax at the speed of up to 14.4kbps. Your CDM- 4500 also supports QNC (Quick Network Connection) for faster internet access.
  • Page 46 Web Setup Features (F72) Web Lock (F72-1) You can lock the unauthorized access to the internet. If the browser is locked by this feature, you will need to enter your 4 digit Security Code to access the Web. Press Web Backlight (F72-2) You can turn on/off the backlight setting during the web access.
  • Page 47 Quick Dialing (F01) When this feature is on, the primary number in your phonebook address 02 to 09 can be dialed with just a single press of the key. Press Scroll to “ON” or “OFF” you want and press Automatic Answering (F02) With this feature on, incoming calls will be automatically answered after a preset duration of alert tones.
  • Page 48 The following functions will return to the initial settings after Function Reset. Functions Automatic Lock (F13) Backlight Control (Standby) (F22-1) Portable Use With Car Kit Backlight Control (In-Use) (F22-2) Auto Hyphenation (F23) Text Lines Selection (F24) Contrast Control (F25) Earpiece Volume Control Alert Tone Volume Control (F31) Ring Type Selection (F32) Key Tone Volume Control (F33)
