- Page 1 Vector Scope & Waveform Monitor Kit VS-100 Quick Start Guide www.datavideo-tek.com...
-
Page 2: Table Of Contents
Contents Warnings and Precautions----------------------------------------------------- 2 Warranty ---------------------------------------------------------------------------- 4 Disposal ---------------------------------------------------------------------------- 5 What’s in the box? --------------------------------------------------------------- 6 Introduction ------------------------------------------------------------------------ 6 Feature ----------------------------------------------------------------------------- 6 Connections & Controls -------------------------------------------------------- 7 MENU Function------------------------------------------------------------------- 9 Specifications -------------------------------------------------------------------- 13 Dimension ------------------------------------------------------------------------- 14 Service & Support--------------------------------------------------------------- 15... -
Page 3: Warnings And Precautions
6. This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. - Page 4 d. When the product does not operate normally under normal operating conditions. Adjust only those controls that are covered by the operating instructions in this manual; improper adjustment of other controls may result in damage to the unit and may often require extensive work by a qualified technician to restore the unit to normal operation;...
-
Page 5: Warranty
DVD Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty... -
Page 6: Disposal
It must be handed over to the applicable take back scheme for the recycling of electrical and electronic equipment. For more detailed information about the recycling of this product, please contact your local Datavideo office. -
Page 7: What's In The Box
Vectorscope to make sure of the right color presence. Use the Parade mode to check on color balance and the Histogram display to make sure blacks or whites are not clipped. Use the VS-100 to compare and match multiple cameras. -
Page 8: Connections & Controls
Connections & Controls Front Panel MENU Turn the knob to view the menu options Push the knob to select a menu option Stereo mini jack plug To monitor any 2 out of up to 8 embedded audio channels via headphones. Power Switch Switches the power On / Off. - Page 9 Rear Panel DC in socket Connect the supplied 12V PSU to this socket. The connection can be secured by screwing the outer fastening ring of the DC In plug to the socket. HDMI output interface HDMI output to monitor. Support HDMI 1.1 HD/SD - SDI BNC Connectors Input is for the Test signal and Output to connect to a monitor or be used as a loop-through signal.
-
Page 10: Menu Function
MENU Functions TOOLS Presents a set of tools that vary with each mode. TRACE MEMORY This tool is common to the Vectorscope, Parade and Waveform Monitor modes. For each mode, it allows a trace to be saved, recalled or be cleared. - Page 11 Presents a set of option that affect all modes: 576i THUMBNAIL Set 576i thumbnail to 4x3 or 16x9 aspect ratio. SDI LOOPTHROUGH Set the SDI output in constant loop-through. CAPTURE Capture field1 or field2 or frame FIRMWARE REVISION See VS-100 firmware revision...
- Page 12 WAVEFORM MOMITOR HISTOGRAM VECTOR SCOPE...
- Page 13 PARADE VIDEO DISPLAY...
-
Page 14: Specifications
Specifications Inputs HD/SD-SDI DC Power: 6-18 VDC RS232 (firmware upgrade) Output HD/SD–SDI HDMI Note: Display device must support 720p 50/59.9/60 Input Standards HD-SDI 1080i50 / 1080i59.97 / 1080i60 / 1080p24 / 1080p25 / 1080p30 / 720p25 / 720p29.97 / 720p30 / 720p50 / 720p59.97 / 720p60 SD-SDI PAL 576i50 / NTSC 480i59.9... -
Page 15: Dimension
Dimension... -
Page 16: Service & Support
It is our goal to make your products ownership a satisfying experience. Our supporting staffs are available to assist you in setting up and operating your system. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
