- Page 1 Motorola MCS-2000 Radios to 223 Series Adapter Panels AN-DISPATCH-020 Rev B 21 MAY 2009...
-
Page 2: Table Of Contents
Table of Contents 1.0 General ..................... 3 2.0 Interconnect Cable Assembly ..............3 3.0 223 Series Adapter Panels ..............4 3.1 TRA-223 Setup .....................4 3.1.1 TRA-223 Dip Switch Settings ..............4 3.2 DSP-223 Setup ......................4 3.2.1 DSP-223 Jumper Settings ................4 3.3 IP-223 Setup ......................5 3.3.1 IP-223 Jumper Settings ................5 AN-DISPATCH-020... -
Page 3: General
A cable assembly is required to connect to the 25-pin accessory connector of the MCS to the various 223 Series adapter panels. Use the following chart to make this interconnect cable assembly. Interconnect Cable Assembly Pin Out TABLE 1. TRA-223 DSP-223 IP-223 Series MCS-2000 Signal DB-25 Pin DB-25 Pin DB-25 Pin DB-25 Pin... -
Page 4: 223 Series Adapter Panels
3.0 223 Series Adapter Panels 3.1 TRA-223 Setup 3.1.1 TRA-223 Dip Switch Settings Set the TRA-223 dip switches as shown in Table 2. For more information, see the TRA-223 Technical Manual REFERENCE: (P/N 803570). TABLE 2. Front Panel Dip Switch - TRA-223 Switch Setting Signal... -
Page 5: Ip-223 Setup
3.3 IP-223 Setup Set the IP-223 jumpers as shown in Table 3. 3.3.1 IP-223 Jumper Settings TABLE 3. IP-223 Jumper Settings Line 1 Jumper Setting Line 2 J33, J34 B = 4-wire J5, J6 J16, J21 A = Single Ended J19, J20 Hanging on Center Pin = 10 Ohm J3, J9, J11... - Page 6 Contact technical support with suggestions or comments concerning this application note. Technical Support: Email: TelexDispatchtechsupport@us.bosch.com Fax: 1-402-467-3279 Phone: 1-800-898-6723 Bosch Security Systems, Inc. 8601 East Cornhusker Highway Lincoln Nebraska 68507 Phone: (800) 752-7560 Fax: (402) 467-3279 Email: Telexdispatch@us.bosch.com Web: www.telex.com...
