Telex IP-223 Technical Manual

Remote adapter panel
Hide thumbs Also See for IP-223:
Table of Contents

Advertisement

Quick Links

Download this manual
IP-223
Remote Adapter Panel
Technical Manual
up to and including version 4.200
803641 Rev L
07/2009

Advertisement

Table of Contents
loading

Related Manuals for Telex IP-223

Summary of Contents for Telex IP-223

  • Page 1 IP-223 Remote Adapter Panel Technical Manual up to and including version 4.200 803641 Rev L 07/2009...
  • Page 2 All Bosch manufactured signaling products are guaranteed against malfunction due to defects in materials and workmanship for three (3) Web ..................www.telex.com years, beginning at the original date of purchase.If such a malfunction occurs, the product be repaired or replaced (at our option) without LAIMS charge during the three (3) year period, if delivered to the Bosch factory.

  • Page 3: Table Of Contents

    IP R ..........23 ADIO ONTROL Accessing IP-223 Web Browser Configuration Network Requirements ..........24 Windows ..............42 IP O ..........24 PERATION VERVIEW IP-223 Web Setup Windows Standards ....43 ........24 THERNET AS HYSICAL AYER ................. 43 INKS ..............24 ANDWIDTH Welcome Window ..........45 ..............24 ULTICAST ..........
  • Page 4 ....48 COR E ACKET ELAY BEFORE LAYBACK IELD NABLED HECK OCAL AND QOS: P .........48 ...............66 RECEDENCE IELD ODES QOS: D, T, ........49 COR A IELD CTIVE HECK OCAL AND IP A .....49 ...............66 OCAL OMPUTER DDRESS IELDS ODES ............50 UBMIT UTTON LWAYS...

  • Page 5: Ox - Local And Tone

    PTT N ............84 OTCH ILTER HECK OCAL ELAY LOSURE ..........74 AGC E ......... 85 ONSOLE ODES NABLED HECK R1600 M ........74 ....85 ODEM HECK LIVE IGITS NABLED HECK ..... 85 HANNEL OCKOUT HECK OCAL AND OUND EYING NABLED HECK ..............74 .......
  • Page 6 ERIAL ARAMS ..........126 IALING IGITS IELD Save to EEPROM Window ......... 106 ..........126 NTERDIGIT IELD ........106 ARAMETERS UTTON ............127 IELD IP-223 B ..........107 ESET UTTON ..........127 ATCH IMEOUT IELD Account Setup Window ........108 ............127 LOBAL IELD ..........109 NABLE HECK ............127...
  • Page 7 CTCSS TONE FREQUENCY TABLE 149 CTCSS Tone Frequency Table ......149 DIGITAL OUTPUT TABLE 151 Digital Output Table ...........151 TONE FREQUENCY TABLE 153 Tone Frequency Table ........153 IP-223 SETTINGS - QUICK REFERENCE 155 I/O Connectors ...........155 Adjustments ............155 Jumper Settings ...........156 PCB 750743 PCB 750630 F ....156...
  • Page 9 FIGURE 1. Local and Tone Mode Connections ....................14 FIGURE 2. Console Mode Connection .......................14 FIGURE 3. IP-223 Front Panel ..........................17 FIGURE 4. IP-223 Case Top Test Points ......................17 FIGURE 5. IP-223 Back Panel ...........................20 FIGURE 6. DB25 Connector Pinout Configuration ...................22 FIGURE 7.
  • Page 10 FIGURE 77. PTT Frequency Drop Down Menu ....................139 FIGURE 78. Select Installation Folder ......................144 FIGURE 79. Confirm Installation ........................144 FIGURE 80. Telex Website Firmware Downloads................... 145 FIGURE 81. Firmware Update Tool ........................ 146 FIGURE 82. Firmware Update Tool— Success Messages ................148...
  • Page 11 List Tables Table 84. IP-223 Specifications ...........................16 Table 85. Jumper Position ...........................21 Table 86. DB9 Pinout ............................21 Table 87. DB25 Connector Pinout Connections ....................22 Table 88. PCB 750743 or PCB 750630 Revision C and Higher Jumper Positions ..........29 Table 89. PCB 750743 or PCB 750630 Revision C and Higher Jumper Positions ..........30 Table 90.

  • Page 13: Overview

    LAN (Local Area Network) connection. Features NOTE: The features listed below for the IP-223 do not comprise the full feature set. For more information on all the features available, contact Radio Dispatch Sales listed on www.telex.com • Ethernet TX and LINK LEDs •...

  • Page 14: Operating Modes

    Ethernet traffic to another IP-223 that can be in tone or local mode. Console Mode Connection FIGURE 2. Phone Mode - Using a PIB (Phone Interface Box) or TDI (Telephone Dispatch Interface), a line on the IP-223 is used to connect to an analog phone line.

  • Page 15: Ip-223 Accessories

    Radio Mode - Using the NI-223, allows interface with a Falcon Class PTT (Push-To-Talk) mobile phone system. TETRA Radio Mode - Used to interface to a TETRA digital trunked system using the IP-223 and the Sepura SRM2000 mobile radio. The IP-223 interfaces the radio through the PEI (Peripheral Equipment Interface) allowing dispatch access to TETRA radio assets.

  • Page 16: Ip-223 Specifications

    Overview IP-223 Specifications The specifications for the IP-223 are listed in Table 1. The specifications are subject to change without notice. CAUTION: This device is not PoE (Power Over Ethernet) compatible. IP-223 Specifications TABLE 1. Operating Temperature Range 0 to 70°C for full specifications...

  • Page 17: Front Panel

    Test and Adjustment Points Test and adjustment points for Radio 1 and Radio 2 are provided on the front panel. Newer versions of the IP-223 provide access to additional test and adjustment points on the case top, as shown in Figure 4.

  • Page 18: Handset Jack

    The IC button, when pressed, sends audio from the handset microphone back through the IP Network on the selected TX multicast and port. It also sends audio to the transmit lines of the IP-223 without keying up the radio. This means no PTT relay in local mode and no EIA (Electronic Industries Association) tones in tone mode.

  • Page 19: Line Button

    1, and an asterisk (*) on the bottom line of the display indicates a connection to line 2. TX LED The TX LED provides a visual indication the IP-223 is generating IP packets. When the LED is illuminated, packets are being transmitted to the network. LNK LED The LNK LED provides a visual indication of the Ethernet connection.

  • Page 20: Back Panel

    Overview Back Panel 10/100 Serial Power Radio 1 and radio 2 Ethernet connector connection connectors (DB25) connector (DB9) IP-223 Back Panel FIGURE 5. 10/100 Ethernet Connector The 10/100 Ethernet connector provides the LAN or WAN connection for the IP-223.

  • Page 21: Serial Connector

    Power Connection The IP-223 requires +12 to +16VDC, ~700mA of clean power. A 3-pin screw terminal receptacle is provided on the right rear of the unit. Pin 1 is the positive terminal, pin 2 is the ground terminal, and pin 3 is the earth ground terminal.
  • Page 22 Overview DB25 Connector Pinout Configuration FIGURE 6. DB25 Connector Pinout Connections TABLE 4. Pin # Signal Cable color PTT Relay N.C. Brown PTT Relay Common MON Relay N.O. Orange R1 Relay N.C. Pink R1 Relay Common Yellow R2 Relay N.O. Green Ground Lt.

  • Page 23: Communications System Design

    Designing an IP-223 system requires an understanding of the radio network and how the various radios and communication equipment are connected. Design an IP-223 system by creating a roadmap of the radio, console, and any other communication equipment locations. This roadmap must include the following: •...

  • Page 24: Network Requirements

    Multicast In general, Telex systems require Multicast to function. The network must be able to support the multicast traffic generated by the system. It is common for networks to enable Multicast after an IGMP (Internet Group Management Protocol) join message is sent out, and then prune off branches after a period of time.

  • Page 25: Internet Group Management

    Implementation of a Multicast protocol requires a few things for seamless use on a network. First, clients must all support the protocol. This is accepted as given since all Telex products utilize Multicast for audio communications. Second, consider if the...
  • Page 26 Communications System Design...

  • Page 27: Installation And Level Settings

    CHAPTER 3 Installation and Level Settings Local Radio Connections NOTE: Connections to radios differ from connections for remote operation; therefore connections are discussed separately. Jumper Positions An example of the jumper positions are shown in Figure 7. In the figure, jumper 14 (J14) is shown in position A, jumper 3 (J3) is shown in position B, and jumper 23 (J23) has been placed on the center pin indicating the jumper is in the NULL position.
  • Page 28 Carefully lift up the case top and place it into position on the chassis bottom. Secure the case top into position using the six (6) screws. Connect power to the IP-223 unit. The IP-223 is ready to configure for Local mode.

  • Page 29: Tx Audio Connection

    Local Radio Connections TX Audio Connection Different jumper settings are required for different revisions of the PCB installed in the IP-223 unit. Set the jumper position for the line according to the connection type. • If the radio transmit audio output is balanced, connect to pins 13 and 25 of the DB25 connector.

  • Page 30: Cor I/O

    8 Ohms (for a speaker input) 600 Ohm 10k Ohm NULL NULL NOTE: When the speaker output is used, the radio volume control affects the audio levels of the IP-223. RX Impedance Jumper Positions - 4-Wire TABLE 8. Jumper Position Line 1 Line 2...

  • Page 31: Monitor Connection

    R1 and R2 Relays The IP-223 provides two (2) relay closures for controlling the frequency of the radio, or switching a remote ancillary device. The F1 and F2 contacts can be connected through the DB25 connector. Usually the common of each relay contact switch is grounded and the normally open contact connects to the radio frequency control terminals.

  • Page 32: Tone And Console Operation

    Installation and Level Settings Tone and Console Operation Tone and Console operation require jumpers set to specific locations. For more information, see “Jumper Locations” on page 131. 2-/4-Wire Jumper Settings 2- and 4-Wire Jumper Settings TABLE 9. 2-Wire / 4-Wire Selection: Line 1 Line 2 2-Wire A position...

  • Page 33: Supervisory I/O

    Once the IP-223 unit is connected to the system, the level potentiometers can be set. Access to test and adjustment points on newer versions of the IP-223 are provided through labeled openings on the case top and on the front panel of the unit. On older versions of the IP-223, access to some of the test and adjustment points is provided through labeled openings on the front panel;...

  • Page 34: Radio Rx

    PCB 750743 or PCB 750630 revision C and higher The Line TX Monitor Level adjustment is used when the IP-223 is connected to consoles set in 4-wire mode. This allows for local TX audio to be sent back on the network and played at other consoles so both sides of the radio traffic can be heard. The alignment for TX monitor is similar to 4-wire RX alignment.

  • Page 35: Frequency Decoding

    Frequency Decoding The IP-223 is factory tuned to the frequencies shown in Table 11. The detection frequencies cannot be changed as they are coded into the software. However, any actual function or output can be made to work with any existing programmed frequency.
  • Page 36 Installation and Level Settings...

  • Page 37: Setup Information

    IP Address, Subnet, and Mask. For the IP-223 to interface successfully with the LAN or WAN, the IP Addresses of the IP-223 and your PC must be on the same subnet. IP Addresses consist of four (4) numbers separated by periods. For example, 10.2.99.101. For more information on IP Addresses and subnets, consult your network administrator.

  • Page 38: Using Hyperterminal

    J35 must be in the A position. To assign the IP Address and Network Mask using HyperTerminal, do the following: Using a DB-9 serial cable, connect the IP-223 to your PC. From the Start menu, select Programs. The Programs flyout menu appears.
  • Page 39 Setting the IP Address Information From the Flow Control drop down menu, select None NOTE: These parameters may be different than the defaults depending on the selected Serial Port Parameters, see “Serial Port Parameters Drop Down Menu” on page 87. Drop down menu Default Setting Bits per second field:...
  • Page 40 Setup Information Press enter. The serial port access window shown in Figure 12 appears. HyperTerminal Factory Setup Options – Serial Port Access Window FIGURE 12. NOTE: The serial number is fixed and should match the case label. The MAC (Media Access Control) address is generated based on the serial number.
  • Page 41 When “Do you wish to reset the unit now” appears, type Y if changes were made on the window, otherwise enter an If changes were made on the window, press enter to reset the IP-223, otherwise proceed to the next step.

  • Page 42: Accessing Ip-223 Web Browser Configuration Windows

    From the User Name drop down menu, type admin or the Username. In the Password field, enter the appropriate Username password. NOTE: If this is the first time the IP-223 has been started and a password has not been assigned to the unit, no entry is required.

  • Page 43: Ip-223 Web Setup Windows Standards

    Links Across the top of each setup window are links used to access the various IP-223 configuration pages. On the left side of the links header, the name assigned to the unit, the MAC address, and the version number of the firmware are displayed.
  • Page 44 Click the desired link. The window for the selected link appears. To permanently save changes, do the following: Click Submit. The changes are sent to the IP-223 in temporary storage. Click Save to EEPROM. The Save to EEPROM window opens. Click Save Parameters.

  • Page 45: Welcome Window

    Welcome Window The Welcome window, shown in Figure 15, provides a basic description of the IP-223 operating modes and a field to enter a descriptive name for the unit. This name displays at the top of each IP-223 web setup window.

  • Page 46: Firmware Version Field

    The Checksum field is calculated from the firmware programmed in the unit. This field is not editable. Submit Button The Submit button is used to temporarily save changes to the IP-223. NOTE: Click Submit to save changes in temporary memory only.

  • Page 47: Basic Ethernet Setup Window

    IP-223 IP Address, Subnet Mask, Gateway Address, as well as setting the network time protocol and packet delay. Serial Number Field The Serial Number field displays the serial number of your IP-223. The serial number label is located on the back of the adapter box and should match the number in this field. MAC Address The MAC Address field displays the MAC Address of the IP-223.

  • Page 48: Use Dhcp Server Check Box

    Unit IP Address Field The Unit IP Address field is used to enter a unique base IP Address for the IP-223. The web browser configuration uses the IP Address to identify the IP-223 for such operations as set up, software upgrades, and communications in some operating modes.

  • Page 49: Qos: D, T, Andr Bits Field

    The entries are used for the Ethernet crossmute function. The IP-223 examines the source of the audio and flags it if the source from one (1) of the IP-223 units listed in these fields.

  • Page 50: Submit Button

    In the QOS: Precendence Bits field, enter the number of bits, if required. In the QOS: D, T, and R Bits field, enter the number of bits, if required. In the Local Computer IP Address fields, enter the IP Addresses of the IP-223 units located in the same room. Click Submit.

  • Page 51: General Gain Setup Window

    The General Gain Setup window, shown in Figure 17, is used to adjust gain levels, as required. Except for handset sidetone gain, the gains are set to 0dB, by default, and can be adjusted up or down. The IP-223 is based largely on software controlled resistors with a resolution of 1.5dB per step.

  • Page 52: Handset Mic Gain Dropd

    Setup Information Handset Gain Setup Handset Mic Gain Drop Down Menu The Handset Mic Gain drop down menu is used to set the level, in dB, of gain for the handset mic. Available selections are: 12.0, 10.5, 9.0, 7.5, 6.0, 4.5, 3.0, 1.5, 0, -1.5, -3.0, -4.5, -10.5, -16.5, -22.5, -28.5, and -34.5. Handset Gain Setup Drop Down Menu FIGURE 18.

  • Page 53: Receive Gain Drop Downm

    General Gain Setup Window Line Gain Setup Receive Gain Drop Down Menu The Receive Gain drop down menu is used to set the gain level, in dB, for receive audio on either line 1 or line 2. Available selections are 12.0, 10.5, 9.0, 7.5, 6.0, 4.5, 3.0, 1.5, 0, -1.5, -3.0, -4.5, -10.5, -16.5, -22.5, -28.5, and -34.5. Receive Gain Drop Down Menu FIGURE 20.

  • Page 54: Ctcss/Recorder Out Gain

    Setup Information CTCSS/Recorder Out Gain Drop Down Menu The CTCSS/Recorder Out Gain drop down menu is used to set the CTCSS/recorder gain, in dB, for either line 1 or line 2. Available selections are 12.0, 10.5, 9.0, 7.5, 6.0, 4.5, 3.0, 1.5, 0, -1.5, -3.0, -4.5, -10.5, -16.5, -22.5, -28.5, and -34.5. CTCSS/Recorder Out Gain Drop Down Menu FIGURE 22.

  • Page 55: Tdi Receive Gain Drop Down

    The TDI Receive Gain drop down menus are used to set the TDI receive gain, in dB, for a TDI connected to Line 1 or Line 2. This gain affects receive audio just before entering the IP-223 receive audio path.

  • Page 56: Submit Button

    Click Save Parameters. The entries are saved to permanent memory. Submit Button The Submit button, located at the bottom of each configuration window, is used to upload changes to the IP-223. NOTE: Clicking Submit saves changes in temporary memory only.

  • Page 57: Multicast Address Setup Window

    The Enable via Ethernet check box, if selected, indicates Ethernet connectivity is active. Otherwise, audio received from the analog connections of the IP-223 are not echoed to the Ethernet, and Ethernet traffic is not mixed into the audio of the IP-223.

  • Page 58: Line Type Drop Down Menu

    Uses an NI-223 to interface with a Falcon Class PTT mobile phone system. TETRA Radio Mode - Interfaces to a TETRA digital trunk system using the IP-223 and the Sepura SRM2000 mobile radio. The IP-223 interfaces the radio through the PEI, allowing dispatch access to TETRA radio assets.

  • Page 59: Rx Mcast Address Field

    Multicast Address Setup Window RX Mcast Address Field The RX Mcast Address field is used to enter the broadcast address for all audio traffic received on a specific line. All consoles must have the same Multicast Address. The entry in the first Multicast Address field applies to the port number entered in the RX Port field.

  • Page 60: Ttl Field

    In the Channel Hops field, enter the number of channel hops (routers) the multicast audio packets can go through before being stopped. Click Submit. The entries currently displayed on the window are sent to the IP-223 for storage. Click Save to EEPROM. The Save Setup Parameters window appears.

  • Page 61: Vocoder Type Drop Down

    The Vocoder Type drop down menu, shown in Figure 27, indicates the bit rate at which audio is converted into digital format. This feature is used to configure communication between the IP-223 and C-Soft. Available selections are: ADPCM (Adaptive Differential Pulse Code Modulation) 16K and ADPCM 32K.

  • Page 62: Ttl Field

    This field is automatically populated and is not editable. Outgoing Port Field The Outgoing Port field identifies the port used to communicate with TSM. The IP-223 sends data through this port to TSM. This field is automatically populated and is not editable.

  • Page 63: Enable Check Box

    The Vocoder Type drop down menu, shown in Figure 28, indicates the bit rate at which audio is converted into digital format. This feature is used to configure communication between the IP-223 and C-Soft. Available selections for this field are ADPCM 16K and ADPCM 32K.

  • Page 64: Submit Button

    Setup Information Submit Button The Submit button, located at the bottom of each configuration window, is used to upload changes to the IP-223. NOTE: Clicking Submit saves changes in temporary memory only. To permanently save changes, do the following: Click Submit.

  • Page 65: Per Line Setup Window

    Per Line Setup Window Per Line Setup Window The Per Line Setup window, shown in Figure 29, is used to view and set the parameters for the line type selected on the Multicast Setup window. The details on the window apply to the line number displayed at the top of the window. The selected line type enables the appropriate fields necessary to set up the line.

  • Page 66: Line Select 1 Button

    The Save to EEPROM window opens. Click Save Parameters. Changes are now permanently saved to the IP-223 console. Line Type Field The Line Type field displays the line type assigned to the line in the “Multicast Address Setup Window” on page 57.

  • Page 67: Always O N Radio Button - L

    The RX Delay field identifies the amount of time, in ms, RX audio is recorded and stored. RX audio is constantly recorded by the IP-223 and when a COR or LAM triggered detect occurs, the IP-223 goes back the specified time of delay to start generating Ethernet packets.

  • Page 68: Ptt Delay Field - Localm

    Setup Information PTT Delay Field - Local Mode The PTT Delay field identifies the delay, in ms, before closing the PTT relay. When TX Ethernet packets arrive, the PTT relay closure is delayed for the specified time. This delay provides the ability to allow for digital output channel changes before keying the radio.

  • Page 69: Relay Drop Down Menu - L

    Per Line Setup Window—Local, Tone, and Console Mode Relay Drop Down Menu - Local, Tone, and Console Modes The Relay drop down menu, shown in Figure 31, identifies the relay(s), if any, closed immediately upon receipt of the function tone. Available selections are no selection, R01, R02, or BOTH.

  • Page 70: Digital Output Field - L

    When PTT is pressed, F1 is the default frequency and the F4 CTCSS tone is sent. System Field - Local Mode The System field is used to control radios serially connected to the IP-223. Once configured, the IP-223 directs audio to the system entered in the field.

  • Page 71: Chan Field - Local Mode

    Per Line Setup Window—Local, Tone, and Console Mode Chan Field - Local Mode The Chan field is used to control radios serially connected to the IP-223. Once configured, the IP-223 directs audio to the frequency entered in the field. When the function tone is changed by the console operator, this setting, along with the System field setting, directs the radio to the system and frequency configured in the field.
  • Page 72 Setup Information Per Line Setup—Local, Tone, and Console Mode, View 2 Per Line Setup—Local, Tone, and Console Modes, View 2 FIGURE 32.

  • Page 73: Lam Level Field - Local , T Modes

    Monitor Relay The Monitor Relay field provides the IP-223 the ability to decode a valid Ethernet packet and provide a relay-contact output to turn off the sub-audible-tone-decoder circuit in the radio receiver. This allows the console operator to monitor the line for other users before transmission (required by FCC regulations on stations equipped with CTCSS).

  • Page 74: H I -Pass Rx Check Box - L Console Modes

    Setup Information Hi-Pass RX Check Box - Local, Tone, and Console Modes The Hi-Pass RX check box, if selected, indicates RX audio below 300Hz is blocked. Pre-Emphasize TX Check Box - Local Mode The Pre-Emphasize TX check box, if selected, indicates TX audio includes a standard 6dB octave pre-emphasis. TX Monitor Check Box - Tone Mode The TX Monitor check box, if selected, indicates audio from parallel consoles in 4-wire mode are sent to the Ethernet as a transmit packet.

  • Page 75: Ptt + R1 Radio Button - L Console Modes

    Per Line Setup Window—Local, Tone, and Console Mode PTT + R1 Radio Button - Local, Tone, and Console Modes The PTT + R1 radio button, if selected, indicates both the PTT relay and the R1 relay close at the same time. PTT + R2 Radio Button - Local, Tone, and Console Modes The PTT + R2 radio button, if selected, indicates the PTT relay and the R2 relay close at the same time.

  • Page 76: Serial Port Params Drop D Tone , And Console Modes

    1200,E,7,1 9600,E,7,1 2400,N,8,1 19200,N,8,1 2400,N,8,2 19200.N.8.1 2400,E,7,1 19200,E,7,1 Serial Port Params Drop Down Menu - Normal Mode FIGURE 34. REFERENCE: For more information see the Radio Dispatch and Signaling Equipment downloads available on the Telex website (www.telex.com) for this setting.

  • Page 77: Fleet Sync Decode Check B Modes

    The Signaling Setup section is used to set up encode, decode, tone type, digits pause and duration. IMPORTANT: The FleetSync and MDC-1200 features in this section are optional IP-223 accessories. The “Additional Feature Setup Window” on page 122, must be also configured.

  • Page 78: Fleet Sync Encode Check B Modes

    MDC Encode Check Box - Local and Tone Modes The MDC Encode check box is used to enable OTA encode. All outbound MDC-1200 messages are generated by the IP-223 instead of the radio. Motorola encode features supported by the IP-223 include PTT ID, call alert, select call, radio check, remote monitor and radio disable/enable.

  • Page 79: Tone Type Drop Down Menu

    FIGURE 37. EXAMPLE: If you have a suffix 123 and the ANI 9876 is received, the IP-223 sends 9876123 to the consoles. This is useful if two (2) different lines have duplicate ANI IDs. Digit Duration Field - Local and Tone Modes The Digit Duration field identifies the length of time, in ms, the digit tone is decoded when it is active for the signaling type selected in the Tone Type drop down menu.

  • Page 80: Ani Decoder # Field

    Setup Information Group Digit Field - Local and Tone Modes The Group Digit field identifies the group digit. The group digit is a wild card that can represent any digit. Placing a group digit within a filter allows any digit appearing at that location in the tone string to pass through the filter. The range for this field is 0–9 or A–F.

  • Page 81: Ani Call Format Field - L Console Modes

    Per Line Setup Window—Phone Mode, View 1 ANI Call Format Field - Local, Tone, and Console Modes The ANI Call Format field identifies the call string format for the ANI Decoder #. This field can contain up to 16 digits. These include digits 0–9, A–D (A–F for other formats), *, # and the following characters: I (Caller ID) - Placed into the ID field of the ANI packet or the ANI field of the caller portion of the telegram.

  • Page 82: Auto Answer Field

    The RX Delay field identifies the amount of time, in ms, RX audio is recorded and stored. RX audio is constantly recorded by the IP-223 and when a COR or LAM triggered detect occurs, the IP-223 goes back the specified time of delay to start generating Ethernet packets.

  • Page 83: Mic Click Call Enabled Check Box

    The Mic Click Call Enabled check box indicates a remote radio user can click the radio PTT the stated number of times within a specified period of time to dial a programmed number. Upon receipt of this sequence, the IP-223 takes the PIB or TDI offhook and automatically dials the number in the Click Dial String field.

  • Page 84: Relay Closure

    Monitor Relay The Monitor Relay field provides the IP-223 the ability to decode a valid Ethernet packet and provide a relay-contact output to turn off the sub-audible-tone-decoder circuit in the radio receiver. This allows the console operator to monitor the line for other users before transmission (required by FCC regulations on stations equipped with CTCSS).

  • Page 85: R Xagc Enabled Check Box

    If selected, the inbound caller can key-up and key-down the radio connected to the opposite line of the IP-223. The star key (*) keys up the radio, the pound key (#) keys down the radio.

  • Page 86: C550 Operation Enabled Check Box

    Setup Information RP251/550 Setup The RP251/550 Setup section is used to configure legacy PSTN radio control systems. C550 Operation Enabled Check Box The C550 Operation Enabled check box indicates operation of the C-550 console is enabled. If selected, operation of the C- 550 console is enabled.

  • Page 87: Serial Port Parametersd

    MDC Encode Check Box The MDC Encode check box is used to enable OTA encode. All outbound MDC-1200 messages are generated by the IP-223 instead of the radio. Motorola encode features supported by the IP-223 include PTT ID, call alert, select call, radio check,...

  • Page 88: Tone Type Drop Down Menu

    Setup Information Tone Type Drop Down Menu The Tone Type drop down menu, shown in Figure 36, identifies the signaling type used when receiving a call. Available selections for this field are: None KENWOOD 5TONE CCIR1 MODAT CCIR2 NATEL DTMF PCCIR DZVEI PDZVEI...

  • Page 89: Ani Suffix Drop Downm

    ANI Type Drop Down Menu FIGURE 44. EXAMPLE: If you have a suffix 123 and the ANI 9876 is received, the IP-223 sends 9876123 to the consoles. This is useful if two (2) different lines have duplicate ANI IDs. Digit Duration Field The Digit Duration field identifies the length of time, in ms, the digit tone is decoded when it is active for the signaling type selected in the Tone Type drop down menu.

  • Page 90: Group Digit Field

    Setup Information Group Digit Field The Group Digit field identifies the group digit. The group digit is a wild card that can represent any digit. Placing a group digit within a filter allows any digit appearing at that location in the tone string to pass through the filter. The range for this field is 0–9 or A–F.

  • Page 91: Ani Call Format Field

    Per Line Setup Window—Phone Mode, View 1 ANI Call Format Field The ANI Call Format field identifies the call string format for the ANI Decoder #. This field can contain up to 16 digits. These include digits 0–9, A–D (A–F for other formats), *, # and the following characters: I (Caller ID) - Placed into the ID field of the ANI packet or the ANI field of the caller portion of the telegram.

  • Page 92: Per Line Setup-Iden Mode

    The RX Delay field identifies the amount of time, in ms, RX audio is recorded and stored. RX audio is constantly recorded by the IP-223 and when a LAM or COR, triggered detect occurs, the IP-223 goes back the specified time of delay to start generating Ethernet packets.

  • Page 93: Squelch Tail Delay Field

    Per Line Setup—iDEN Mode Squelch Tail Delay Field The Squelch Tail Delay field identifies the amount of time, in ms, the RX audio is muted after PTT occurs. This provides the ability to overcome squelch tail ping-pong in crosspatch modes by muting the radio RX input after PTT occurs. The range for this field is 0 to 5000ms.

  • Page 94: Relay Drop Down Menu

    Setup Information Relay Drop Down Menu The Relay drop down menu, shown in Figure 48, identifies the relay(s), if any, closed immediately upon receipt of the function tone. Available selections for this field are no selection, R01, R02, or BOTH. Relay Drop Down Menu—Per Line Setup FIGURE 48.

  • Page 95: Call Type Drop Down Menu

    Per Line Setup—iDEN Mode Call Type Drop Down Menu The Call Type drop down menu, shown in Figure 49, identifies the iDEN radio call type. Available selections for this field are Direct Connect, Group Call, Call Alert, and Emergency Group Call. Call Type Drop Down Menu—iDEN Mode FIGURE 49.

  • Page 96: Lam Level Field

    Setup Information Per Line Setup—iDEN, View 2 Per Line Setup—iDEN Mode, View 2 FIGURE 50. LAM Setup LAM Level Field The LAM Level field identifies the threshold, in dB, at which the radio/line unmutes and sends RX packets to the Ethernet. The range for this field is -50 to +10dB.

  • Page 97: Supervisor Check Box

    Monitor Relay The Monitor Relay field provides the IP-223 the ability to decode a valid Ethernet packet and provide a relay-contact output to turn off the sub-audible-tone-decoder circuit in the radio receiver. This allows the console operator to monitor the line for other users before transmission (required by FCC regulations on stations equipped with CTCSS).

  • Page 98: 2-Wire Check Box

    When selected, the PTT relay, the R1 relay, and the R2 relay close at the same time. PTT Timeout Field The PTT Timeout field is used to configure the length of time, in seconds, the IP-223 allows the radio to key up. This function is used to prevent an extensive occupation of the interfaced radio.

  • Page 99: Serial Port Params Dropd

    Per Line Setup—Tetra Mode Serial Port Mode Serial Port Mode Drop Down Menu The Serial Port Mode drop down menu is used to identify the specific radio interface for the serial port configuration. Selecting an item with a Scan List suffix enables a frequency scan list update function. The Freq Scan List function synchronizes the console scan list with the radio's can list.

  • Page 100: Tx Delay Field

    The RX Delay field identifies the amount of time, in ms, RX audio is recorded and stored. RX audio is constantly recorded by the IP-223 and when a LAM or COR triggered detect occurs, the IP-223 goes back the specified time of delay to start generating Ethernet packets.

  • Page 101: Tone Enable Check Box

    Per Line Setup—Tetra Mode Tone Enable Check Box The Tone Enable check box, if selected, indicates the function tone is active. The frequency for the tone is set on the Tone Frequency and Durations window described on page 138. The standard function tones and their frequencies are the default entries.

  • Page 102: Type Drop Down Menu

    Each unit asks permission to transmit before each transaction. Trunked UDSL (User Defined Scan List) - A scan of specific groups predefined in the radio and in the IP-223. A UDSL is a collection of pre-defined talk group (or function tone) settings.

  • Page 103: Lam Level Field

    Per Line Setup—Tetra Mode Per Line Setup—Tetra Mode, View 2 Per Line Setup—Tetra Mode, View 2 FIGURE 55. LAM Setup LAM Level Field The LAM Level field identifies the threshold, in dB, at which the radio/line unmutes and sends RX packets to the Ethernet. The range for this field is -50 to +10dB.

  • Page 104: Supervisor Check Box

    Monitor Relay The Monitor Relay field provides the IP-223 the ability to decode a valid Ethernet packet and provide a relay contact output to turn off the sub-audible-tone-decoder circuit in the radio receiver. This allows the console operator to monitor the line for other users before transmission.

  • Page 105: 2-Wire Check Box

    Per Line Setup—Tetra Mode 2-Wire Check Box The 2-Wire check box is selectable only in local and console modes. For more information, see “2-Wire Check Box - Tone Mode” on page 74. F1 Last Call Check Box The F1 Last Call check box is selectable only in iDEN mode. For more information, see “F1 Last Call Check Box - Local, Tone, and Console Modes”...

  • Page 106: Serial Port Params Dropd

    Save to EEPROM Window The Save to EEPROM window, shown in Figure 56, is used to save the current configuration to the IP-223 or to reset the parameters on the configuration webpage to the last configuration saved to the IP-223.

  • Page 107: Reset Ip-223 Button

    Save to EEPROM Window Reset IP-223 Button The Reset IP-223 button is used to perform a full reset of the IP-223. This is the software equivalent of a power down reset. To save changes to permanent memory, do the following: Click Save to EEPROM.

  • Page 108: Account Setup Window

    System Accounts By default, the IP-223 comes with two (2) system accounts created: admin and user. Upon first use, there are no passwords set for either account. You can change the passwords for both of the accounts, if desired. These are the only system accounts allowed.

  • Page 109: Enable Check Box

    The success message, shown in Figure 59, appears. Account Setup Success Message FIGURE 59. Click Submit. The changes are sent to the IP-223 console. Click Save to EEPROM. The Save to EEPROM window opens. Click Save Parameters. Changes are now permanently save to the IP-223.

  • Page 110: Confirm Password Field

    Click Submit to save the change to the console. Submit Button The Submit button, located at the bottom of each configuration window, is used to upload changes to the IP-223. Clicking Submit saves changes in temporary memory only. To permanently save changes, do the following: Click Submit.

  • Page 111: Delete Button

    Click Save. Click EEPROM. Click Save Parameters. Changes are now permanently saved to the IP-223 console. Delete Button The Delete button is used to delete the selected user account(s). User accounts are marked for deletion by selecting the Delete check box.

  • Page 112: Reset System Parameters Button

    Setup Information System Parameters Reset System Parameters Button The Reset System Parameters button resets all parameters, except multicast and port numbers, in the IP-223 to the factory defaults. To reset the system parameters, do the following: Select the Reset System Parameters radio button.

  • Page 113: Reset Button

    Factory default settings are restored to the browser configuration windows. Click Reset IP-223, to undo and restore system parameters to the last saved configuration. System settings on both the console and the browser configuration windows are set to the previously saved version.

  • Page 114: Edit User Accounts Window

    Setup Information Edit User Accounts Window The Edit User Account window, shown in Figure 60, is used to edit the user system account. You can only change the password or set no password from this window. By default, the System User Account has access to only the default admin pages Tone Freqs and General Gain Setup, ID Directory, and Save to EEPROM.
  • Page 115 Click Save to EEPROM. The Save to EEPROM window appears. Click Save Parameters to save the changes to the IP-223. To change the system account password from an actual password to no password, do the following: Leave the New Password and Confirm password fields blank.

  • Page 116: Cancel Button

    The Cancel button discards the user account settings you have made and reopens the Account Setup window. To permanently save the new password, do the following: Click Submit. Click Save to EEPROM. The Save to EEPROM window opens. Click Save Parameters. Changes are now permanently save to the IP-223.

  • Page 117: Add New User Window

    Add New User Window Add New User Window The Add New User window, shown in Figure 63, is used to create a new user account. From this window, you can assign permissions to certain users. Add New User—Account Setup FIGURE 63. Choose a Username Username Field The Username field identifies the username of the account you are creating.

  • Page 118: Save T Oeeprom Checkb

    Setup Information Save To EEPROM Check Box The Save to EEPROM check box indicates permission is granted to use the Save to EEPROM window. By default, permission to change configurations in this window is granted on every created account. For more information, see “Save to EEPROM Window”...

  • Page 119: Submit Button

    Add New User Window Submit Button The Submit button is used to upload changes to the IP-223. NOTE: Clicking Submit saves changes in temporary memory only. To permanently save changes, do the following: Click Submit. The changes are sent to the IP-223 in temporary storage.

  • Page 120: Edit Created Accounts Window

    Setup Information Edit Created Accounts Window The Edit Created Account window, shown in Figure 65, is used to edit permissions granted to a user account. NOTE: The Edit button is not active until an account has been created. Edit Created Account FIGURE 65.

  • Page 121: New Password Field

    Click Save to EEPROM. The Save to EEPROM window opens. Click Save Parameters. Changes are now permanently saved to the IP-223 console. Save Button The Save button is used to save the changes to temporary memory. To permanently save changes, do the following: Click Save.

  • Page 122: Additional Feature Setup Window

    The Additional Feature Setup window appears. In the enter Access Key field, enter the 16-digit Access Key code. The window displays a list of additional features enabled on your IP-223. See example in Figure 67. Click Submit. The entries currently displayed on the window are sent to the IP-223 for storage.
  • Page 123 Additional Feature Setup Window Additional Feature List Example FIGURE 67.

  • Page 124: Clone Console Window

    The Retrieve Configuration Data from Remote IP-223 window appears. In the Enter IP Address field, enter the IP Address of the remote IP-223 the configuration data is to be copied from. Enter the username and password of the remote IP-223.

  • Page 125: Crosspatch Setup Window

    Crosspatch Setup Window Crosspatch Setup Window The Crosspatch Setup window, shown in Figure 69, provides the necessary parameters to configure crosspatch. This window can contain up to 100 entries. Crosspatch Setup FIGURE 69.

  • Page 126: Enable Line-Line Check Box

    Enet Patch Timeout Field The Enet Patch Timeout field is used to switch a full-duplex IP-223 line to a half-duplex line when an Ethernet crosspatch is active. When the Enet Patch Timeout expires, the IP-223 line switches back to full-duplex regardless the Ethernet crosspatch state.

  • Page 127: Beep Dly Field

    Crosspatch Setup Window Beep Dly Field The Beep Dly (Delay) field identifies the amount of time, in ms, between the digit string detection and status beeps echoed back to the hand-held radio. The range for this field is 0 to 5000ms. Patch Timeout Field The Patch Timeout field identifies the amount of time, in seconds, allowed for inactivity on an active patch.

  • Page 128: Jump To Entry Drop Down Menu

    Setup Information RCP Tables Jump To Entry Drop Down Menu The Jump To Entry drop down menu allows you to select function tones (in groups of 10) to view and modify. From the Jump To drop down menu, select the entries you want to view. Click GO.

  • Page 129: Mode Drop Down Menu

    IP to a different line. PHONEP - A remote user with a portable radio can key a DTMF string, causing the IP-223 to take the PIB or TDI offhook. Once the PIB or TDI is offhook, the user can manually dial a phone number.

  • Page 130: Or #2 Drop Down Menu

    #1 or #2 Drop Down Menu (XPATCH option only) The #1 or #2 drop down menu identifies which DB25 connector port on the remote IP-223 is used in this crosspatch entry. Available selections for this field are: Radio1 or Radio 2.

  • Page 131: Command Buttons

    From the #1 or #2 drop down menu, select the applicable DB25 connector port used on the remote IP-223. In the IP Address field, enter the IP Address of the remote IP-223 with the radio used in this crosspatch entry.
  • Page 132 If all of the remote crosspatch entries are complete on the window and more crosspatches need to be defined, click Submit. The entries currently displayed on the window are sent to the IP-223 for storage. If all of the remote crosspatch entries are complete on the window and no more crosspatches need to be defined, click Submit.

  • Page 133: Crp Pin Table Window

    CRP PIN Table Window CRP PIN Table Window The Remote CrossPatch Pin Setup window, shown in Figure 73, allows up 300 PIN numbers to be set for operation of the IP- 223’s crosspatch feature. Remote Crosspatch Pin FIGURE 73. When PIN numbers are entered correctly, a Go-Ahead Beep sequence to indicate success or failure is played back on the console indicating RCP setup is ready.

  • Page 134: Jump To Entry Drop Down Menu

    The Go button is used to navigate to the page in the Jump to Entry Drop Down Menu. Submit Button The Submit button is used to upload changes to the IP-223. To permanently save changes, do the following: Click Submit.

  • Page 135: Pin Enable Check Box

    The PIN field is used to enter a PIN number for the displayed crosspatch entry number. This field can contain up to 4 digits. Submit Button The Submit button, located at the bottom of each configuration window, is used to upload changes to the IP-223. To permanently save changes, do the following: Click Submit.

  • Page 136: Next 30 Entries Button

    If all of the PIN entries are complete on the window and more PINs need to be defined, click Submit. The entries currently displayed on the window are sent to the IP-223 for storage. If all required Crosspatch PIN entries are complete on the window and no more PINs need to be defined, click Submit and proceed to step 9.

  • Page 137: Pass Change Window

    The password is required to be entered in the Password field on the Connect to [IP Address] window to access the web setup windows for the IP-223. Account Password Change FIGURE 75.

  • Page 138: Tone Frequency & Durations Window

    Tone Frequency & Durations Window The Tone Frequency and Durations window, shown in Figure 76, identifies frequencies and function tones. The IP-223 is capable of generating the standard tone packages required to control a radio with a tone termination panel.

  • Page 139: Ptt Frequency Drop Down Menu

    Tone Frequency & Durations Window Guard Hold PTT Frequency Drop Down Menu The PTT Frequency drop down menu, shown in Figure 77, identifies the PTT frequency, in Hz, the console uses. Available selections for this field are 2100, 2175, 2300, 2325, 2400, 2600, 2800, 2850 and 2970Hz. PTT Frequency Drop Down Menu FIGURE 77.

  • Page 140: Function Tone Duration Field

    Setup Information Function Tone Function Tone Duration Field The Function Tone Duration field identifies the duration, in ms, of the function tone. When dual function tones are set, both tones are set to this duration. The range for this field is 0 to 999ms. In most cases, this value is set to 40ms.
  • Page 141 Enter the desired frequency (in Hz) for the second function tone. An entry of 0 indicates no second function tone is sent. Click Submit. The entries currently displayed on the window are sent to the IP-223 for storage. Click Save to EEPROM. The Save Setup Parameters window appears.
  • Page 142 Setup Information...

  • Page 143: Update Firmware

    CHAPTER 5 Update Firmware Update Firmware Telex VoIP Hardware firmware can be updated using TSM (Telex System Manager). A copy of TSM is available on the CD included in the shipment with the VoIP hardware. NOTE: • VoIP hardware includes the following Telex devices: IP-223, IP-2002, IP-1616, C-6200 and NEO-10.
  • Page 144 To specify an installation path for TSM, click Browse. To accept the default folder location, leave the path entered in the Folder field By default, TSM is installed at C:\Program Files\Telex Communications\Telex System Manager\. To allow any user to access TSM, select Everyone.

  • Page 145: Download Telex Firmware

    Download Telex Firmware When new firmware becomes available it is posted to our website. It can be downloaded at www.telex.com/Downloads/. Check the website periodically for updated firmware. Telex Website Firmware Downloads. FIGURE 80. To download updated firmware, do the following: Set the search criteria to Radio Dispatch &...

  • Page 146: Update Firmware Tool Window

    Update Firmware Tool Window The Update Firmware Tool window, shown in Figure 81, is used to upload the newest version of firmware to the device selected in the Destination field. Firmware Update Tool FIGURE 81. File Field The File field is used to select a firmware file to upload to the VoIP hardware. Firmware File Info Group Box Device Type Field The Device Type field displays the type of device supported by the currently selected file in the File field.

  • Page 147: Upload Voip Hardware Firmware

    Once TSM is installed and your new .tfb file is downloaded, you are ready to upload the VoIP hardware’s firmware. To upload the VoIP hardware’s firmware, do the following: Click the TSM shortcut on your desktop. From your taskbar, click Start|Programs|Telex Communications|Telex System Manager. The Telex System Manager window opens. Click Tools|Firmware Update The Firmware Update Tool opens.
  • Page 148 NOTE: If an error occurs, the Progress column is reset and an error message appears in the Status column. NOTE: Once the firmware is uploaded, the device resets. Firmware Update Tool— Success Messages FIGURE 82. Click Close. The dialog window closes. Click Close.

  • Page 149: Ctcss Tone Frequency Table

    APPENDIX A CTCSS Tone Frequency Table CTCSS Tone Frequency Table CTCSS Tone Frequencies TABLE 15. Tone Freq. Tone Freq. Tone Freq. Tone Freq. Number (Hz) Number (Hz) Number (Hz) Number (Hz) 33.0 71.9 123.0 183.5 35.4 74.4 127.3 186.2 36.6 77.0 131.8 189.9...

  • Page 151: Digital Output Table

    APPENDIX B Digital Output Table Digital Output Values TABLE 16. Digital Output Table Digital Output Values TABLE 16.
  • Page 152 Digital Output Values Digital Output Values TABLE 16. TABLE 16.

  • Page 153: Tone Frequency Table

    APPENDIX C Tone Frequency Table Tone Frequency Table Supported Radio Dispatch Tone Frequencies TABLE 17. European Tone Frequencies in Hz Motorola TONE 0 2400 2400 2400 2200 2200 1981 1981 1981 1981 979.8 1633 637.5 TONE 1 1060 1060 1060 1124 1124 1124...

  • Page 155: Ip-223 Settings - Quick Reference

    APPENDIX D IP-223 Settings - Quick Reference I/O Connectors Connector Description Power IN Serial port Radio/Line 1 Radio/Line 2 Display Header Handset Jack Ethernet port Adjustments Test Test Signal Line 1 Line 2 point point RX Pre-amp R175 TP13 R110...

  • Page 156: Jumper Settings

    Jumper Settings PCB 750743 or PCB 750630 revision F Line 1 Jumper Setting Line 2 A = RS232 serial data, B = TTL PCB 750743 or PCB 750630 revision C, D, E, and F Line 1 Jumper Setting Line 2 J33, J34 2 or 4 Wire, A = 2-wire, B = 4-wire J5, J6...

  • Page 157: Jumper Locations

    Jumper Locations Jumper Locations FIGURE 83.
  • Page 159 NOTES...
