AMX MVP-8400 Dimension Manual

9.83 [250MM]
7.49 [190MM]
7.00 [178MM]
NOTICE: This drawing is the UNLESS OTHERWISE SPECIFIED:
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
UNDER .250 = +/- .005
shall be confidential except
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
This drawing may not be copied, ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV ECN DESCRIPTION
A 5545 RELEASE TO PRODUCTION
REL APPR REL DATE REV APPR
DAS 10/21/03
DRAWN
DB 10/31/03
ENGR SERV
PICTORIAL,
RR 10/31/03
ENGINEER
MVP-TDS,
KZ 10/31/03
PROD ENGR
MVP TABLE TOP DOCKING STATION
BS 10/31/03
MATL SUP
AK 10/31/03
SIZE DWG. NO.
QUALITY
95-5965-10
SCALE: 1:2
B
THIRD ANGLE
PROJECTION
95-5965-10
DATE APPROVED
10/31/03
AMX CORPORATION
3000 RESEARCH DRIVE
RICHARDSON, TX 75082
REV.
A
SHEET 1 OF 1
