Emerson Fisher 92C Installation Manual

Installation Guide
D100255X014
English – December 2012
Introduction
This installation guide provides instructions for installation,
startup and adjustment. To receive a copy of the
instruction manual, contact your local Sales Office or view
a copy at www.fisher.com. For further information refer to:
Type 92C Instruction Manual, D100255X012.
PED Categories
This product may be used as a safety accessory with
pressure equipment in the following Pressure Equipment
Directive categories. It may also be used outside of the
Pressure Equipment Directive using sound engineering
practice (SEP) per table below. For information on the
current PED revision see Bulletin: D103053X012.
PRODUCT SIZE
DN 15, 20 and 25 / NPS 1/2, 3/4 and 1
Specifications
Body Sizes and End Connection Style
See Table 1
Maximum Allowable Inlet and Pilot
Supply Pressures
(1)
Grey Cast Iron: 17.2 bar / 250 psig
Steel and Stainless Steel: 20.7 bar / 300 psig
Regulator Pressure Drops
Minimum: 1.0 bar / 15 psig
Maximum Operating: 10.3 bar / 300 psig for
outlet pressure settings equal to or below 3.4 bar /
50 psig; 13.8 bar / 200 psig for outlet pressure
settings above 3.4 bar / 50 psig
Maximum Emergency:
Grey Cast Iron Construction: 17.2 bar / 250 psig
Steel and Stainless Steel Construction: 20.7 bar /
300 psig
Outlet Pressure Range
See Table 2
Maximum Outlet Pressures
Maximum Operating Outlet Pressure: 10.3 bar /
150 psig
Maximum Emergency Outlet (Casing) Pressure:
Grey Cast Iron Construction: 17.2 bar / 250 psig
Steel and Stainless Steel Construction: 20.7 bar /
300 psig
Loading Pressure For Pressure-Loaded Regulator
Maximum allowable loading pressure is 17.2 bar /
250 psig for grey cast iron construction and 20.7 bar /
300 psig for steel or stainless steel construction; the
maximum allowable diaphragm differential pressure
of 10.3 bar / 150 psig for grey cast iron, steel and
stainless steel constructions must not be exceeded.
1. The pressure/temperature limits in this installation guide or any applicable standard limitation should not be exceeded.
CATEGORIES FLUID TYPE
SEP
(1)
(1)
Proof Test Pressure
All Pressure Retaining Components have been
proof tested per Directive.
Maximum Temperature Capablities
Grey Cast Iron: 208°C / 406°F
Steel and Stainless Steel: 260°C / 500°F
Optional High-Temperature Steel or Stainless
Steel Body: 343°C / 650°F
Installation
Only qualified personnel should install
or service a regulator. Regulators
should be installed, operated and
maintained in accordance with
1
international and applicable codes
and regulations and Emerson Process
Management Regulator Technologies,
Inc. instructions.
If the regulator vents fluid or a leak
develops in the system, it indicates that
service is required. Failure to take the
regulator out of service immediately may
create a hazardous condition.
Personal injury, equipment damage or
leakage due to escaping fluid or bursting
of pressure-containing parts may result
if this regulator is overpressured or
is installed where service conditions
could exceed the limits given in the
Specifications section, or where
conditions exceed any ratings of the
adjacent piping or piping connections.
To avoid such injury or damage, provide
pressure-relieving or pressure-limiting
devices (as required by the appropriate
code, regulation or standard) to prevent
service conditions from exceeding limits.
Additionally, physical damage to the
regulator could result in personal injury
and property damage due to escaping
fluid. To avoid such injury and damage,
(1)
install the regulator in a safe location.
Type 92C
(1)
WARNING
!
