Electro-Voice | ELX200-18SP 18" powered subwoofer
www.trungchinhaudio.vn
ELX200-18SP 18" pow-
ered subwoofer
▪ EV QuickSmart Mobile application: quickly and
wirelessly configure, control and monitor up to six
ELX200 loudspeakers simultaneously, and receive
immediate notification during critical performance
conditions. Bluetooth® is available in select countries.
▪ QuickSmartDSP features best-in-class processing. Easy
setup via three presets, sub/top system-match, five user-
programmable presets, visual monitoring of limiter
status, input level control and meters, and master
volume control to optimize gain structure, all via LCD.
▪ High-efficiency 1200 W Class-D power amplifier
delivers up to 132 dB peak SPL utilizing ultra-
efficient, high-sensitivity transducer designed and
engineered by EV.
▪ Ideal for portable and installed applications.
Professional-grade hardware: integrated M20
threaded pole mount plate and two-handle design for
easy lifting.
ELX200-18SP features high-efficiency Class-D power
amplifiers (up to 1200 W) with integrated QuickSmartDSP,
and delivers up to 132 dB SPL utilizing transducers
designed and engineered by EV (18-inch EVS-18L woofer).
Powered subwoofer models allow easy setup via three
presets (Music, Live, Club), sub/top system-match
crossovers, three-band EQ, five user-programmable
presets (Store and Recall settings), visual monitoring of
limiter status, input level control and meters, and master
volume control to ensure optimal gain structure. ELX200
powered models are ideal for portable and installed
applications, with lightweight and compact 15-mm wood
enclosures, integrated M20 threaded pole pole-mount
plate, and two-handle design for easy lifting. The new
QuickSmart Mobile wireless control and monitoring
application, using Bluetooth® Low Energy (BTLE)
technology, allows intuitive system control, configuration
and monitoring of up to six powered ELX200 loudspeakers
simultaneously. Receive alerts
when your system is being overdriven, and control
your system while in front of your speakers, not
behind. Bluetooth® is available in select countries.
Technical specifications
Frequency response (-3 dB):
Frequency range (-10 dB): 40 Hz – 145 Hz
Maximum SPL:
Power rating: 1200 W
LF transducer: EVS-18L 457 mm (18 in)
Low-Pass frequency: Adjustable: 80 Hz, 100 Hz,
Connectors: (2) XLR/TRS combo jacks and
Enclosure: 15 mm plywood with EVCoat
47 Hz – 105 Hz
1
1
132 dB
2
120 Hz, 150 Hz
(2) XLR link outputs
