FEATURES
Compatible with all
Multivision Quest duplex
and triplex multiplexers
Connect up to sixteen
multiplexers to one
remote panel and easily
change which multiplexer
you control
Daisy chain up to four
remote panels
Maximum distance is
300 m (1,000 ft)
Easy to install and
operate from desktop
Multivision
®
REMOTE CONTROL PANEL
Expand the control of your CCTV multiplexer
system with a Multivision Quest Remote
Control Panel. Each unit connects up to sixteen
multiplexers located up to 300 m (1,000 ft)
away, giving security operators remote control
from a central location. The Remote Control
Panel connects easily and operates like the
front panel on the multiplexer. The Remote
Control Panel comes with everything you need
for desktop use.
Up to four Remote Control Panels can be daisy
chained, each up to 300 m (1,000 ft) from the
previous panel. In addition, up to sixteen
multiplexers can also be daisy chained using
one or more Remote Control Panel(s).
www.americandynamics.net
Quest

Advertisement

loading

Summary of Contents for American Dynamics DMV14Q

  • Page 1 FEATURES • • Compatible with all Daisy chain up to four Multivision Quest duplex remote panels and triplex multiplexers • Maximum distance is • Connect up to sixteen 300 m (1,000 ft) multiplexers to one • Easy to install and remote panel and easily operate from desktop change which multiplexer...
  • Page 2 Compatibility Duplex Multiplexers DMV14Q ....Duplex, 4 channel, B/W multiplexer 120 VAC, NTSC DMV19Q ....Duplex, 9 channel, B/W multiplexer 120 VAC, NTSC DMV16Q .
