Please read these instructions carefully and follow safety precautions before using this product.
Please keep product purchase documents like invoice copy with this operating instructions manual for warranty
claim purpose.
Thank you for purchasing the Panasonic product
CONTENTS
Introduction
Caring for the environment ...................................
Safety instructions ................................................
Installation
Installation...............................................................
- Choosing the right location ..............................
- Door Handle Install Instructions........................
Parts and their functions .......................................
Operation
- Introduction of Function....................................
Refrigerator compartment.....................................
Do and Don'ts.........................................................
When moving or transporting the refrigerator.....
Appendix
Cleaning and maintenance ...................................
- Cleaning ..........................................................
- Changing the Internal Light.............................. 14
- When Shutting off the refrigerator ...................
Troubleshooting ....................................................
Specifications ........................................................
This appliance is intended to be used in household and similar
applications such as
- farm houses and by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Operating Instructions
Refrigerator-Freezer
NR-BC52MSSA
Model No.
NR-BC52SWSA
- How to make ice ..........................................
(Household use)
2
2
5
5
6
7
8
10
10
11
12
13
13
14
15
16
Advertisement
Related Manuals for Panasonic NR-BC52MSSA
Summary of Contents for Panasonic NR-BC52MSSA
-
Page 1: Table Of Contents
Operating Instructions Refrigerator-Freezer (Household use) NR-BC52MSSA Model No. NR-BC52SWSA Thank you for purchasing the Panasonic product CONTENTS Introduction Caring for the environment ........Safety instructions ..........Installation Installation............... - Choosing the right location ......- Door Handle Install Instructions......Parts and their functions ........ - Page 2 Introduction Caring for the environment Disposing of the packaging Please recycle where possible (e.g. cardboard, plastic bags, adhesive tape and polystyrene) and make sure you dispose of all other packing materials safely. Keep the packaging out of the reach of babies and young children, to avoid injury or suffocation. Before disposing of your old appliance Please follow either the disposal instructions from the manufacturer of the old appliance, or local disposal regulations for the appliance.
- Page 3 Introduction Do not install the refrigerator in a damp place, or where it may come into contact with water. ● ● Flammable substances such as benzene, thinners, alcohol, ether and Liquid Petroleum Gas (LPG) can cause explosions. Do not store pharmaceuticals or other temperature-sensitive products in the refrigerator. ●...
- Page 4 Introduction The refrigerant (R134a) used in the refrigerator and the gases in the insulation material ● Before you dispose of the appliance, make sure none of the pipes on the back are damaged. ● Do not damage the refrigerant circuit. Unplug the refrigerator before cleaning and servicing.
-
Page 5: Choosing The Right Location
Installation Choosing the right location ● Where the refrigerator will not be exposed to direct sunlight ● Where the refrigerator will be at a distance from heating appliances, cooking appliances and other sources of heat ● A location which is well-ventilated and dry ●... -
Page 6: Door Handle Install Instructions
Installation Door Handle Installation Instruction Note: Figures in the user manual are only for reference. The actual product may differ slightly. The refrigerator must be disconnected from the source of electrical supply before attempting the CAUTION installation of accessory. ● 1. Take out the two crisscross-screw; and install them into the door holes; turn the screws till to the bottom; ●... - Page 7 Operation Parts and their functions Interior and foods stored 1. Temperature Control Dial 2. Temperature Control Panel 3. Adjustable Glass Shelves 4. Vegetable Case Cover 5. Vegetable Case 6. Freezer Door Rack 7. Utility Box 8. Refrigerator Door Rack 9. Levelling Feet 10.
-
Page 8: Introduction Of Function
Operation Introduction of Function ① ② ③ ④ ⑤ ⑥ 1. Key A. SET position set key 2. Display screen ① Shift 1 ② Shift 2 ③ Shift 3 ④ Shift 4 ⑤ Shift 5 ⑥ Standby indicator 3. Display ◆... - Page 9 Operation 6. Fault indicator Display Malfunc on The LED1 and LED2 glow Refrigerator temperature sensor circuit The LED1 and LED3 glow Freezer defrost sensor The LED1 and LED4 glow Ambient temperature sensor 7. Temperature control operation 1. Initial setting of fresh compartment control panel is shift 3, for frozen compartment air shutter, the initial setting is Mid position.
-
Page 10: How To Make Ice
Operation Refrigerator & Freezer compartment Put the food which are short-term storage or to eat at any time in the refrigerator comparment. Although regulating temperature b will enable average temperature of the majority preservation of food. Therefore, refrigerator compartment only use as a short-term food storage. Shelf adjustment According to the needs of food storage you can adjust the... - Page 11 Operation Do and Don'ts ● The refrigerator use alternating current supply which is 220-230V / 60Hz. If the voltage, fluctuations is large( Over the scope of 198-264V ), it may cause some failures, such as the refrigerator does not start, The main control board and compressor bum and the compressor works with abnormal voice.
- Page 12 Appendix When moving or transporting the refrigerator Before moving or transporting the refrigerator Remove all the food and ice inside the refrigerator, and disconnect the power plug. Raise the adjustable legs, and pull the refrigerator toward the front. Drain off the water from the drain outlet at the bottom of the rear panel.
-
Page 13: Cleaning
Appendix Appendix Cleaning and maintenance Conduct periodic cleaning and maintenance to ensure that the refrigerator will be kept clean and that it will continue to operate for a long time to come. Before cleaning or conducting maintenance, be absolutely sure to disconnect the power plug from the power outlet. -
Page 14: Changing The Internal Light
Appendix Cleaning and maintenance Changing the Internal Light Setting the refrigerator control to off does not remove power to the light circuit. CAUTION:Light bulb may be hot. CAUTION Illuminating lamp parameter: MAX 40W 1) Unplug the refrigerator. 2) The bulb is located at the top of the compartment near the opening. 3) Replace with an appliance bulb of the same or lower wattage. - Page 15 Appendix Troubleshooting The following simple symtom can be handle by customer. Check that the plug and its socket are in good condition. ● Check if there is any problem on main fuse and electrical system of The refrigerator does ● the house.
- Page 16 • All shelves are the same position when you purchased. 5. Occasionally clean the ventilation openings at the bottom of the refrigerator with a vacuum cleaner, etc. (Take care not to damage the refrigerant pipe inside the cover) Specifications MODEL NR-BC52MSSA NR-BC52SWSA COLOR Stainless Steel White...
- Page 24 (SET) (SET)
- Page 28 • • • •...
- Page 32 ● ● " " NR-BC52SWSA NR-BC52MSSA × × 230-220 230-220 R134a R134a ISO 15502...
