V410-H Handheld Reader
Quick Start Guide
Return to Factory Defaults / Add an Enter Key
Return to Factory Defaults
Decode the symbol below to return reader parameters
to factory defaults.
Add an Enter Key
(Carriage Return / Line Feed)
Decode the symbol below to add an Enter key after decoded data.
Step 1 – Set Up Host Interface (Cont.)
RS-232
RS-232
Decode the symbol to the right.
Step 4 – Create or Load a Setup
Assisted Setup
When you click the Assisted Setup button in the Start view, a dialog
appears asking a series of application-related questions. Based on
your answers, WebLink generates your initial setup automatically.
PC
Once the setup is created, you can fine-tune its parameters in the
Setup view.
Create a New Setup
The Start view also allows you to create a New Setup without using
Assisted Setup. When you click the Create a New Setup button,
WebLink searches for any differences from default in the reader
PC
parameters. If no differences from default are found, the Setup view
appears. If differences from default are found, an alert appears asking if
you want to restore default settings.
Load a Setup
Select Load a Setup to load an existing .rls WebLink
Step 6 – Configure the Reader (Continued)
Performance Step (DPM Optimization)
The Performance step allows you to optimize the reader for Direct
Part Mark (DPM) decoding. A DPM is a permanent mark created by
laser etch, chemical etch, or other method directly on a substrate.
DPMs are often harder to read than other symbols, and may require
a few attempts before finding optimal settings. The Decoder Effort
slider has four settings: Level 1, corresponding to Min on the slider;
Level 2; Level 3; and Level 4, corresponding to Max on the slider.
As Decoder Effort is moved toward Max, the decoder spends an
increasing amount of time trying to decode the symbol.
In Level 4, you can also enable the Enhance option, which improves
readability by allowing additional processing for poorly-formed marks.
The Illumination options are Direct, Indirect, and Cycle.
Clicking the Question Mark icon brings up a dialog with more detail
about each level of decoder effort.
Reader Features
1
1 LED Indicator
2 Reader Window
3 Reader Trigger
Add a Tab Key
Add a Tab Key
Decode the symbol below to add a Tab key after decoded data.
USB Caps Lock Override Options
USB - OVERRIDE CAPS LOCK KEY (ENABLE)
*USB - DO NOT OVERRIDE CAPS LOCK KEY (DISABLE)
Step 2 – Install WebLink
Install
The WebLink installer is found on Omron's Download Center at
PC
www.automation.omron.com/weblinkpc
Minimum PC Requirements
• Intel ® Core™2 Duo Processor (Core™i3 recommended)
• Microsoft Windows 7 32-bit (Windows 7 64-bit or Windows 10 recommended)
• Internet Explorer 11 or higher, Edge, Firefox, or Opera (Chrome recommended)
• 1 GB/128 MB Video RAM (2 GB RAM/128 MB Video RAM recommended)
• 100 MB hard drive space (500 MB recommended)
• 16-bit color display (32-bit recommended)
• 3.0 Windows Experience Index (4.0 recommended)
Connect
To start WebLink , double-click the icon placed on your desktop
PC
during installation.
WebLink
PC
You can also start WebLink
typing http://localhost:8090 or http://127.0.0.1:8090 in the address bar.
The WebLink session will begin
PC
after you enter the IP address.
Step 5 – Explore the Setup View
The Setup view allows you to configure the reader, view the current
captured image, and view decoded symbol data.
The following read cycle steps are shown at the left side of the screen:
• Cycle
• Performance
• Decode
• Format Output
setup file.
PC
Step 6 – Configure the Reader (Continued)
Decode Step
The Decode step allows you to select which symbologies to enable and
disable. Clicking the 1D and 2D checkboxes will enable or disable all the
symbologies in that group. The Gear icon brings up a Symbology
Settings dialog, allowing you to modify specific parameters.
Format Output Step
Format Output allows you to configure preambles and postambles to add
to symbol data output. The Simplified version of this control allows you to
Append Return or Append Tab after each string of data output. The
Advanced version allows you to choose from a wide variety of keyboard
characters that can be output as a preamble or postamble. You can also
add a second postamble if required.
2
3
and Connect
PC
by opening a browser of your choice and
PC
Accessories
V410-H Stand
Step 1 – Set Up Host Interface
USB
Note: Cables may vary depending on configuration.
USB
Decode one of the symbols below.
The interface cable automatically detects the host interface type
and uses the default setting. If the default (*) does not meet your
requirements, decode the other host symbol below.
*USB HID KEYBOARD
EMULATION
Step 3 – Explore the Start View
The Start view shows all the readers available to the system. The
Reader Model, Serial Number, and Firmware Version of each
reader are displayed. This view also allows you to choose Assisted
Setup, Create a New Setup, or Load a Setup. The Gear icon in the
upper right brings up the Settings Menu.
Step 6 – Configure the Reader
Cycle Step
The Cycle step allows you to choose between Manual and Presentation
trigger modes. In Manual mode, a decode is attempted when you pull
the trigger. In Presentation mode, the read cycle begins when a
symbol is detected moving into the reader's field of view.
Note: The reader is automatically set to Presentation mode when
placed in the V410-H Stand.
Step 7 – Run the Application
The Run view allows you to keep track of your application during
runtime. The current captured image is shown along with a row of image
control tools. A history of decoded symbol data is shown in the right
pane along with any preambles or postambles that have been defined.
The Output Data display in the right pane shows a list of previous
read cycle results. Each result is selectable and erasable.
Image control tools are available at the upper right of the image view.
Resize Zoom Zoom Save
Image In Out Full-Size
to Fit Image
Area
SNAPI WITH
IMAGING INTERFACE
