1020 Series
30/60-Watt LED
Infrared Illuminator
About this Document
This document describes the installation and
operating procedures for the American Dynamics
model 1020 30/60-watt LED Infrared Illuminator
Series. The light produced by the 1020 Series is
invisible to the human eye which makes it ideally
suited for covert security operations. The 30-watt
model is designed for indoor operation and small
outdoor areas. The 60-watt model is most effective
in an outdoor environment where higher power is
required.
If you need assistance, call...
American Dynamics Technical Support Center:
Toll free: 800.442.2225
Fax: 914.624.7685
The software/firmware furnished with this equipment is confidential
to, and copyrighted by, AMERICAN DYNAMICS. It is not to be
copied or disclosed in any manner without the express written consent
of AMERICAN DYNAMICS. The software/firmware is furnished to
the purchaser under a license for use on a single system.
Information furnished by AMERICAN DYNAMICS is believed to be
accurate and reliable. However, no responsibility is assumed by
AMERICAN DYNAMICS for its use; nor for any infringements of
other rights of third parties which may result from its use. No license
is granted by implications or otherwise under any patent or patent
rights of AMERICAN DYNAMICS.
8000-1794-01, Rev. A (11 pages)
Copyright © 1999 by Sensormatic Electronics Corporation
Installation and
Operating Instructions
Contents
Warnings and Cautions ................................................. 2
Before You Begin ......................................................... 2
Unpacking and Inspection......................................... 2
Maintenance .............................................................. 2
Installation and Service ............................................. 2
Description.................................................................... 2
Features ..................................................................... 2
Over-voltage shut-off ............................................ 2
Temperature-related shut-off ................................ 2
Power Supply Selection ............................................ 2
Twilight Switch......................................................... 3
Power Supply Installation ............................................. 3
General Safety........................................................... 3
1040-3060PSA Power Supply Installation................ 3
Power Supply Wiring.................................................... 4
Installer Wiring ......................................................... 5
Primary Connections............................................. 5
Secondary Connections......................................... 6
Power Supply Operation ............................................... 6
120Vac/230Vac Operation........................................ 6
1040-3060PSA Power Supply Output Voltage ......... 6
Measuring the 1040-3060PSA Output Voltage......... 6
Adjusting the 1040-3060PSA Output Voltage.......... 6
Two-Wire Connections ................................................. 6
Four-Wire Connections................................................. 7
Jumper Clip Removal................................................ 7
Troubleshooting ............................................................ 8
Dimensions ................................................................... 9
Specifications.............................................................. 10
Declarations ................................................................ 11
Regulatory Compliance........................................... 11
Other Declarations .................................................. 11
