Summary of Contents for American Dynamics AD1020-1541
Page 1
FEATURES • • 880 and 950 nm versions Range up to 55 m (180 ft) • • 15, 30, and 60 watt Power supplies available versions • Pan/tilt brackets available • IP66 rating • MTBF exceeds 11 years AD1020 Series INFRARED ILLUMINATORS The AD1020 Series of infrared illuminators provide outstanding results when used with IR...
Page 2
AMERICAN DYNAMICS AD1020 SERIES INFRARED ILLUMINATORS SPECIFICATIONS Model Operating Current Wattage Number Voltage (Amps) Long Life LED 12 VDC AD1020-1541 15 watts 1.25 A (± 0.5 V) 13 VDC 30 watts 2.30 A AD1020-3050 ± 0.5 V) 13 VDC AD1020-3051 30 watts 2.30 A...
