Subject : Explode Views & Replacement Part List (Update)
Please file and use this supplement manual together with the service manual for
Model No. SA-HT740GCP-S, Order No. MD0605182C3
Model No. SA-HT740P/PC-S, Order No. MD0512491C1
Model No. SA-HT740PX-S, Order No. MD0605181A3
Model No. SA-HT743P/PC, Order No. MD0603063A1
Model No. SA-HT744PC, Order No. MD0604127A1
Model No. SA-HT940P/PC, Order No. MD0603057C1
