LG FJ5 Simple Manual

SIMPLE MANUAL
High Power
Speaker System
Please read this manual carefully before operating your set and retain it for future reference.
To view the instructions of advanced features, visit http://www.lg.com and then download
Owner' s Manual. Some of the content in this manual may differ from your unit.
MODEL
FJ5
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
MFL70040816
FJ5-FK.DCHLLLK_ENG_SPA_SIM_MFL70040816.indd 1-4
Top Panel
g MASTER VOLUME/MULTI JOG
- Adjust speaker volume.
a
- Adjust microphone volume.
- Selects lighting mode.
- Selects VOCAL EFFECTS mode.
i
h F (Function)
Selects the function and input source.
U (Skip/Search)
b h
- Skips forward.
- Searches for a section within a file.
- Selects the radio stations.
T (Play/Pause)
- Starts or pauses playback.
- Selects Stereo/Mono (Horizon mode only).
Y (Skip/Search)
- Skips backward.
- Searches for a section within a file.
- Selects the radio stations.
c d e f g
WIRELESS LINK
- Selects MASTER or SLAVE on WIRELESS PARTY LINK mode.
- Enable or disable WIRELESS PARTY LINK mode.
a USB Port
i Display window
You can play sound files by connecting the USB device.
b 1 (Standby)
Turns the power on or off
KEY CHANGER
Changes the key to suit your vocal range.
VOICE CANCELLER
You can reduce the vocal tones during music playback from
various input sources.
ECHO/DEMO
- Selects ECHO mode.
- In power off status, if you press ECHO/DEMO, shows DEMO
mode.
c LIGHTING
Selects the lighting effects.
d MIC (Microphone) VOL. (Volume)
Select to adjust microphone volume.
(Adjust microphone volume by rotating
MASTER VOLUME/MULTI JOG.)
e VOCAL EFFECTS
Selects VOCAL EFFECTS mode.
f BASS BLAST
Press to select BASS effect directly.
Controller App
www.lg.com
Download the Music Flow Bluetooth App to your For more information, download the online owner' s
device. (Android only) manual. http://www.lg.com
Front panel / Rear panel
a
b
a MIC (Microphone) jack
b Remote sensor
How to place the unit
Vertical
LG Sound Sync (Wireless)
On the horizon mode, you can hear the stereo sound and on
the vertical mode, the sound transforms into a mono signal.
Specifications
Power Requirements
c
Power Consumption
L f
d
FM
R Dimensions (W x H x D)
AC IN
ANTENNA AUX IN
e
Bus Power Supply (USB)
Amplifier
(Total RMS output power)
Design and specifications are subject to change without notice.
c Handle
d AC IN socket
e ANTENNA (FM)
f AUX IN (L/R)
Connect an auxiliary device.
Horizon
Right
Left
Additional Information
Replacement of battery
Refer to the main label on the unit.
Refer to the main label on the unit.
Approx. 615 mm x 272 mm x
318 mm
5 V 0 1 A
220 W RMS
2018-06-14 11:54:32
