Summary of Contents for Aluratek ADMPF107
- Page 1 7” Digital Photo Frame model ADMPF107 Instructional Manual mnl M10040...
-
Page 2: Table Of Contents
Table of Contents Overview ... Features ... Package Contents ... Product Highlights ... Remote Control Close-up ... Application ... Getting Started ... Operations ... Viewing Photos ... Shortcut to Start a Slideshow ... Picture Display ... Adjust Speed of Slideshow ... Adjust Order of Pictures in Slideshow ... -
Page 3: Overview
Overview More than just a digital photo frame, Aluratek raises the bar with its new Digital Lifestyle Device (DLD). View hi-resolution pictures, music files, movies and home videos easily by inserting your camera or camcorder’s digital media card or an USB thumb drive directly onto Aluratek’s (DLD). -
Page 4: Features
Features • Easy operation as most file formats are automatically recognized • High quality wooden frame • High quality built-in speakers • Memory included • 7” TFT true color LCD • Supports most memory card formats such as CF / MD / MS / SD / MMC / XD •... -
Page 5: Package Contents
Features cont. USB Host / Device Functions Any MP3 or USB mass storage device can be inserted into the USB port on the digital picture and it will be shown as “USB” on the memory card selection menu. You can access all files on the device just like any other memory cards. -
Page 6: Product Highlights
Digital Photo Frame Highlights 7” viewing area Quality wood frame Built-in speakers Menu selection buttons Headphone jack Power adapter port USB port connection CF / MD / MS / SD / MMC / XD Card reader slots Remote control Frame stand (rotates 90° for vertical orientation) -
Page 7: Remote Control Close-Up
Remote Control Close-Up POWER MUTE ROTATE RETURN ENTER VOL - VOL + 1. Power On/Off 2. Mute - Disables sound to music and video. 3. BGM - Push to start photo slideshow 4. Rotate - Rotate pictures 90 degrees 5. Up, Down, Left, Right Arrows - Use arrow keys to navigate your way throught various menus 6. -
Page 8: Application
Application Connect any mp3 device, digital camera or digital camcorder through the unit’s USB ports Insert any of the following memory cards: Compact Flash (CF) Type I, II, Ultra, and Extreme; - OR - Secure Digital (SD); MMC; RS-MMC; Memory Stick (MS);... -
Page 9: Getting Started
Getting Started Step 1: Remove the protective film covering the LCD. Step 2: Remove the plastic insulator from the battery on the remote control. Step 3: Plug in the power adapter and then press the power button on the remote control or the power button on the photo frame to turn the photo frame on. - Page 10 Getting Started cont. Please insert your memory card (SD, MMC, CF, MS, MD or XD) at this time. You may also insert a USB thumb/flash drive into the on board USB 2.0 port which will appear as “USB” on the OSD. Optional Step 4: With the built-in memory feature, you may also transfer pictures, movies and/or music files directly from your computer to your digital photo frame by attaching the included USB cable to your com-...
- Page 11 Getting Started cont. STEP 5: After you insert your memory card or USB drive, select the category of media files (Photo, Music, Combo, Movie, and Text) you want to display/play as it appears on the OSD by pressing “Enter” on the included remote control.
-
Page 12: Operations
Operations Viewing Photos Select “Photo” (pic 1) on the OSD by pressing “Enter” on the remote control and then select the media (pic. 2) that you want to view the photo from. You may then toggle up or down to select your desired picture then press “Enter”... -
Page 13: Shortcut To Start A Slideshow
Operations cont. Shortcut to Start a Slideshow: Press the “BGM” button on the remote to start a slideshow with pictures / music stored in the onboard memory. Picture Display Once an image is chosen, press “Enter” again on the remote control for more options. Zoom out Stop Next... -
Page 14: Adjust Speed Of Slideshow
Operations cont. Adjust Speed of Slideshow 1. Exit completely to the main menu by pressing “OSD” on the remote control repeatedly. The main menu will display the 8 categories options on the OSD (pic 1). 2. Scroll to “Setup” and press the “Enter” button on the remote control. key to select “Picture Set”... -
Page 15: Adjust Order Of Pictures In Slideshow
Operations cont. Adjust Order of Pictures in Slideshow 1. Exit completely to the main menu by pressing “OSD” on the remote control repeatedly. The main menu will display the 8 categories options on the OSD (pic 1). 2. Scroll to “Setup” and press the “Enter” button on the remote control. key to select “Picture Set”... -
Page 16: Listen To Music
Operations cont. Listen to Music 1. Select “Music” (pic. 1) from the main menu by using the remote control’s press “Enter” and then select the desired media type. 2. A list of the MP3 files stored on your media will appear on the OSD. Use the remote control to select the desired song then press “Enter”. -
Page 17: Song Display
Operations cont. Song Display Once an song is chosen, press “Enter” again on the remote control for more options Prev Pause Specifi cations Time Play Mode Play Stop Next Song Track Info... -
Page 18: Turn On/Off Background Music During Slideshow
Operations cont. Turn On/Off Background Music During Slideshow Press “BGM” on the remote to turn on/off background music during slideshow. Adjust Music Play Options 1. During music playback, press the key on the remote control to the play mode selection below. 2. -
Page 19: View Videos
Operations cont. View Videos 1. Select “Movie” (pic. 1) from the file menu option by using the remote control’s then press “Enter” and select the desired media type and press “Enter”. 2. You will see a list of Video files that are stored on your media. Use the on the remote control to select which file you would like to view, then press “Enter”. -
Page 20: Copy File Between Memory Card And Internal Memory
Operations cont. Copy File Between Memory Card and Internal Memory 1. Select “Edit” from the main menu by using the remote control’s press “Enter” and then select the desired media type. 2. Press the button on each file (MP3 or pictures) that you want to copy. Each selected file should have at the beginning of the file name. -
Page 21: Technical Support
Technical Support If you need further assistance, please contact Aluratek support department prior to returning this device. E-mail: support@aluratek.com Web: www.aluratek.com/support Local (Irvine, CA): 949-419-6504 Toll free: 1-866-580-1978... -
Page 22: Radio And Tv Interference Statement
Radio and TV Interference Statement WARNING!!! This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications. -
Page 23: Warranty
Warranty Aluratek warrants this product against defect in material or workmanship for 120 Days from the date of purchase. This warranty becomes invalid if the factory-supplied serial number or “warranty void” sticker has been removed or altered on the product. - Page 24 Aluratek, Inc. 12A Mauchly Irvine, CA 92618 sales@aluratek.com 949.419.6504 • office 949.419.6477 • fax...
