Big Kid®/Big Kid®
LX
Booster Seat
Owner's Manual
Keep instructions for future use.
Child Requirements*
18 to 49.8 kg
(40 to 110 lbs.)
102 to 145 cm
(40 to 57 in.)
At least 4 years old
* See page
Para instrucciones en Español,
llamar al: 1-800-233-5921
WARNING!
To reduce the risk of serious injury
or death, read this owner's manual prior
to installing and using this booster seat.
© 2019 Evenflo Company, Inc.
for complete requirements.
4
25701560
11/19
Advertisement
Table of Contents
Related Manuals for Evenflo Big Kid
Summary of Contents for Evenflo Big Kid
- Page 1 * See page for complete requirements. Para instrucciones en Español, llamar al: 1-800-233-5921 WARNING! To reduce the risk of serious injury or death, read this owner’s manual prior to installing and using this booster seat. © 2019 Evenflo Company, Inc. 25701560 11/19...
-
Page 2: Important Notice
More children are killed every year as passengers in car crashes than by any other type of injury. To reduce the risk of SERIOUS INJURY or DEATH, read this owner’s manual and your vehicle owner’s manual before installing and using this booster seat. Using a booster seat makes a big difference. -
Page 3: Table Of Contents
INTERACTIVE PDF Table of Contents (TOC) Important Notice ............2 Booster Seat Child Requirements ........4 Warnings ..............5 Safe Practices ..............8 Recall Information for U.S. Customers ......8 Public Notice for Canadian Customers ......9 Airplane Usage .............. 9 Booster Seat Features .......... -
Page 4: Booster Seat Child Requirements
Booster Seat Child Requirements Warning: Failure to follow these Child Requirements could result in serious injury or death. This booster seat is designed for use by children in booster mode only. To use this booster seat properly, children MUST meet the size and age requirements below. Please review any applicable local, state or provincial laws related to child passenger safety before installing and using this booster seat. -
Page 5: Warnings
WARNING! DEATH or SERIOUS INJURY can occur. Airbag Warning • DO NOT use this booster seat in the front seat of a vehicle equipped with an air bag. Air bags may cause serious injury or death to children 12 and under. If your vehicle has an air bag, refer to your vehicle owner’s manual for booster seat installation. - Page 6 • Some booster seats do not fit in all vehicles. If the booster seat cannot be properly installed, DO NOT use the booster seat. Consult your vehicle owner’s manual, try a different seating location, or call Evenflo for further assistance. Booster Seat Position Warnings •...
- Page 7 • DO NOT attach additional padding, toys, or other devices not made by Evenflo to the booster seat. Items not tested with the booster seat could injure the child. • In hot, sunny weather cover the seat with a light colored blanket when you leave the vehicle.
-
Page 8: Safe Practices
Please fill this card out using blue or black ink • For recall information, call the U.S. Government’s Vehicle and mail it NOW, (or register online at: www.evenflo.com/registercarseat) Safety Hotline at 1-888-327-4236 (TTY:1-800-424-9153), while you are thinking about it. or go to: http://www.NHTSA.gov The card is already addressed and we've paid the postage. -
Page 9: Public Notice For Canadian Customers
The information you provide must be complete. Or register online at www.evenflo.com/registercarseatcanada. Evenflo Company, Inc. ATTENTION : Cette carte pourait être importante à la sécurité de votre enfant. -
Page 10: Booster Seat Features
Booster Seat Features Front Back... - Page 11 Booster Seat Features (cont.) Description 1. Shoulder Belt Guide 2. Seat Pad 3. Armrest 4. Elastic Cup Holder 5. Adjustment Handle 6. Instruction Storage Area 7. Shoulder Belt Clip...
- Page 12 Booster seat Features (cont.) Elastic Cup Holder WARNING • DO NOT use the cup holder to store cans, bottles, or hard containers. Only for use with soft cups. • DO NOT place any cups that contain hot liquids in the cup holder.
- Page 13 This page is intentionally blank.
-
Page 14: Attaching The Seat Pad
Attaching the Seat Pad 1. Position seat facing up. Wrap the seat pad around the front of the seat. Make sure the seat pad is straight and positioned correctly on the seat. 2. Connect elastic loops to hooks on the underside of the seat. - Page 15 Attaching the Seat Pad (cont.) 3. Wrap the seat pad around the back of the seat. Make sure the seat pad is straight and positioned correctly on the seat. Connect elastic loops to hooks on the underside of the seat.
-
Page 16: Assembling Backrest
Assembling Backrest 1. Assemble the backrest. Insert three posts on the headrest into the backrest, as shown. Make certain the headrest clicks securely into the backrest. Note: This is a one-time assembly and may require additional force to connect properly. CLICK! 2. -
Page 17: Attaching The Backrest Pad
Attaching the Backrest Pad Wrap the backrest pad around the back. Make sure the pad is straight and positioned evenly on the seat. 1. Pull the backrest pad down over the top of backrest. Attach the headrest pad to the hooks. - Page 18 Attaching the Backrest Pad (cont.) 2. Connect elastic loops to hooks on the top of the headrest on both sides. 3. Connect elastic loops to hooks on the middle of the backrest on both sides. 4. Pull the pad around the bottom corner and connect elastic loops to hooks.
-
Page 19: Assembling Your Booster Seat
Assembling Your Booster Seat 1. Install the backrest. Slide the backrest assembly into the base. Make certain the backrest locks into place. 2. Check your work. Inspect the booster seat to make sure that the headrest is securely attached to the backrest, the seat pad is hooked into place, and that the backrest assembly is securely locked into the base. -
Page 20: When To Put Your Child In A Booster Seat
When to Put Your Child in a Booster Seat Booster seats raise the child up and help to position the vehicle lap and shoulder belt correctly. When the child is properly restrained in a booster seat, their risk of injury in all types of crashes is reduced, as the lap and shoulder belt provides excellent restraint of both the upper and lower torsos. -
Page 21: Using Your Booster Seat With The Backrest
Using Your Booster Seat with the Backrest Child Requirements • Weight: 18 – 49.8 kg (40 – 110 lbs.) • Height: 102 – 145 cm (40 – 57 in.) AND the tops of child’s ears are below the top of the booster seat headrest. - Page 22 How can you tell if your child is ready to transition to a booster seat? You should consider using a booster seat if the following conditions apply: • The child is mature enough to sit in the booster seat and not put the belts under their arm or behind their back.
-
Page 23: Installation Checklist
Installation Checklist 1. Place the booster seat on the vehicle seat. 2. Set the child in the booster seat. Make sure the child’s back and bottom are flat against the back and bottom surfaces of the booster seat. 3. Adjust the back of the booster, if necessary. Adjust the backrest so the shoulder belt guides are level with the top of the child’s shoulders. -
Page 24: Without The Backrest
Using Your Booster Seat without the Backrest Child Requirements • Weight: 18 – 49.8 kg (40 – 110 lbs.) • Height: 102 – 145 cm (40 – 57 in.) tall AND the tops of child’s ears are below top of the vehicle headrest. •... -
Page 25: Installation Checklist
Installation Checklist 1. Remove the backrest from the booster seat. (See Removing the Backrest, p. 26.) 2. Place the booster seat on the vehicle seat. 3. Set the child in the booster seat. Make sure the child’s back is flat against the vehicle seat,and the child’s bottom is flat against the booster seat. -
Page 26: Removing The Backrest
Removing the Backrest 1. Lay the booster seat on its side. 2. Squeeze the lever on the bottom of the base and remove the backrest from the base. Important Store the backrest properly when not in use. -
Page 27: Adjusting The Backrest
Adjusting the Backrest To adjust the backrest, pull and hold the adjustment handle then slide the backrest up or down. The backrest is positioned properly when the bottom of the shoulder belt guides are even with the top of child’s shoulders. Shoulder Belt Shoulder Belt Guide... -
Page 28: Using The Shoulder Belt Clip
Using the Shoulder Belt Clip 1. Thread the looped end of the shoulder belt clip belt through the anchor point on bottom of the booster. 2. Thread the shoulder belt clip through the loop at the end of the belt and pull until tight. 3. -
Page 29: Care And Cleaning
Care and Cleaning • Plastic parts may be wiped clean with mild soap and water and dried with a soft cloth. Do not use abrasive cleaners or solvents. • Take care not to damage any labels. • The seat pad can be machine washed separately in cold water, delicate cycle, tumble dry 10 –... -
Page 30: Replacement Parts
Seat Pad Proper Disposal of this Booster seat When this booster seat reaches the expiration date found on the date of manufacture label, Evenflo encourages you to dispose of it properly. Most components of this booster seat are recyclable. 1. Remove all fabric and padding. -
Page 31: Storing Your Instructions
Storing Your Instructions After thoroughly reading and following these instructions, STORE THE INSTRUCTIONS IN THE SLOTS PROVIDED ON THE BOTTOM OF THE BOOSTER SEAT. For future reference, record the model number of your booster seat AND the date of manufacture below. Model Number: Date of Manufacture:... -
Page 32: Limited Warranty
Evenflo’s sole obligation under this express limited warranty shall be, at Evenflo’s option, to repair or replace any Product that is determined to be defective by Evenflo and determined to be covered by this warranty.
