CAUTION:
Weight on this product should not exceed 300 lbs.
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springfield, MO 65803
www.staminaproducts.com
Product May Vary Slightly
From Pictured.
Customer Care
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following numbers :
Model#: 55-2125
S/N: _____________
STAMINA PRODUCTS
MADE IN TAIWAN
© 2020 Stamina Products, Inc.
2020, 08

Advertisement

Table of Contents
loading

Related Manuals for Stamina CARDIO CLIMBER

Summary of Contents for Stamina CARDIO CLIMBER

  • Page 1 Weight on this product should not exceed 300 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN TAIWAN 2040 N Alliance Ave, Springfield, MO 65803 Customer Care © 2020 Stamina Products, Inc. 1 (800) 375-7520 2020, 08 www.staminaproducts.com...

  • Page 2: Table Of Contents

    17. The STAMINA® Cardio Climber should not be used by persons weighing over 300 pounds. 18. The STAMINA® Cardio Climber should be used by only one person at a time. 19. The STAMINA® Cardio Climber is for consumer use only. It is not for use in public or semipublic facilities.
  • Page 3 1 (800) 375-7520 customer.care@staminaproducts.com Hi! From all of us here at Stamina Products, thank you for your purchase. We know that you have big fitness goals in mind and we are here to help you along. Call us, email us, or send us a message on Facebook. Be sure to contact us if you have any questions on your new product.

  • Page 4: Before You Begin

    STAMINA® Cardio Climber. to make you feel better, look better, and enjoy life to its Providing you with a quality product is Stamina's top fullest. priority. However, sometimes there could be a missing It's a proven fact that a regular exercise program can or incorrectly sized part.

  • Page 5: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the STAMINA® Cardio . Please take a moment to familiarize yourself with all of the warning, caution, and notice Climber labels.

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the fasteners used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 3 Place the END COVER(54) onto the Bracket in the BASE FRAME(60). Insert the RAIL ASSEMBLY(53) into the gap between the END COVER(54) and the Bracket, then secure with BUTTON HEAD BOLTS(M8x1.25x16mm)(98). Do not securely tighten the Bolts(98) until Step 4. STEP 4 Attach the FRONT SUPPORT(55) to the BASE FRAME(60) with BUTTON HEAD BOLTS (M8×1.25×16mm)(98).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 5 NOTE: The CABLE(18) can be attached to the PEDAL SUPPORTS(37, 38) in two positions. Refer to detail views A and B below. The upper position offers the stride distance of 16 inches (406mm). The Lower position offers the stride distance of 20 inches (508mm). Try the lower position first. Insert the SPACER(32) into the hole in the end of the CABLE(18), then attach the CABLE(18) to the RIGHT PEDAL SUPPORT(38) with PLASTIC WASHERS(66), SOCKET HEAD BOLT(M8x1.25x25mm) (81), and NYLOCK NUT(M8)(71).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7: Push the PEDALS(35, 36) to the same height, so the SLIDING TUBES(30) come out as shown in the following illustration. Insert the HANDLEBARS(25, 26) in the SLIDING TUBES(30) and lock in the desired position with the ADJUSTMENT KNOBS(28). NOTE: Make sure to always adjust both HANDLEBARS(25, 26) to the same height.

  • Page 11: Set Up Instructions

    SET UP INSTRUCTIONS Place the STAMINA® Cardio Climber in the area where it will be used. It is recommended that the STAMINA® Cardio Climber be placed on an equipment mat. The STAMINA® Cardio Climber is approximately 43 inches long x 31.5 inches wide x 92.5 inches tall (max.). An area 4 feet wide x 6 feet long is required for safe operation of the STAMINA®...

  • Page 12: Operational Instructions

    OPERATIONAL INSTRUCTIONS LOAD ADJUSTMENT To increase the load, turn the TENSION KNOB(47) clockwise. To decrease the load, turn the TENSION KNOB(47) counterclockwise. There are eight levels for the load adjustment. HANDLEBAR HEIGHT ADJUSTMENT There are five adjustment holes in the HANDLEBARS (25, 26) to adjust the height for the HANDLEBARS(25, 26).
  • Page 13 OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON : Move the pedals or press the button. POWER OFF : Automatically shuts off after four minutes of inactivity. FUNCTION BUTTON: Press to select display functions, including SCAN, SPEED, DISTANCE, TIMER, COUNT, and CALORIES. Press and hold for three seconds to reset all functions to zero.

  • Page 14: Storage

    6. Worn or damaged components must be replaced immediately or the STAMINA® Cardio Climber removed from service until repair is made. 7. Only Stamina Products supplied components should be used to maintain/repair the STAMINA® Cardio Climber. 8. Keep your STAMINA® Cardio Climber clean by wiping it off with an absorbent cloth after use.

  • Page 15: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 16: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place.

  • Page 17: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance Ave, Springfield, Missouri, USA, MO 65803, or email us at customer.care@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 18: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 19: Parts List

    PARTS LIST PART# PART NAME Pulley Spacer (ø10 x ø14 x 15mm) Bearing (6800) Small Pulley Magnetic Flywheel Tension Bracket Eye Bolt (M6 x 1.0 x 67mm) Resistance Bracket Bearing Adapter Cable Mounting Plate Long Pulley Spacer (ø10 x ø14 x 45mm) Tension Spring Eye Bolt (M6 x 1.0 x 57mm) Magnetic Brake Plate...
  • Page 20 PARTS LIST PART# PART NAME Tension Knob Cover Base Frame Round Plug (ø76mm) Stand Moving Wheel Sensor Wire Lock Washer (M8) Plastic Washer (ø8 × ø25 × 3mm thick) Washer (ø8 × ø16 × 2mm thick) Washer (ø8 × ø23 × 2mm thick) Washer (ø10 x ø16 x 1mm thick) Nylock Nut (M6 ×...

  • Page 21: Notes

    NOTES...

  • Page 22: Fax/Mail Ordering Form

    2040 N Alliance Ave, Springfield, MO 65803 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
