36/49 Bosch Rexroth AG
Device Description
12.4

Display and Operating Components

Rexroth IndraControl VAC 05.1, VAC 30.2, VAC 31.1 Connection Modules
WARNING
Red-yellow EMERGENCY STOP pushbuttons have to function in all opera‐
tion modes of a machine or a system at any time.
Store hand-held terminals with a red-yellow EMERGENCY STOP pushbutton
that are not connected so that they are not visible. In case of emergency, it is
ensured that disconnected devices are not confused with functional devices.
● Unlocking an EMERGENCY STOP pushbutton must not result in uncon‐
trolled start-up of machines or system.
● The EMERGENCY STOP pushbutton does not replace other safety de‐
vices.
● The EMERGENCY STOP pushbutton on the hand-held terminal does
not replace the EMERGENCY STOP pushbutton to be mounted directly
on the machine.
● Some mechanical errors in the EMERGENCY STOP pushbutton and in
the STOP pushbutton can be detected only when actuated.
Test the functionality of the EMERGENCY STOP pushbutton after the
device has been exposed to mechanical shock (e.g. by dropping it on
the ground).
Additionally, the EMERGENCY STOP pushbutton has to be tested cycli‐
cally (every 6 months) by actuating the EMERGENCY STOP pushbut‐
ton.
● For further information about the EMERGENCY STOP pushbutton and
the STOP pushbutton, also refer to the project planning manual of the
VCH 08.1 hand-held terminal.
As the connection module VAC is operated together with a hand-held termi‐
nal (e.g. VEH 30.2, VCH 08.1,...) or a machine control panel (e.g. VAM 10.2,
VAM 11.41,...), the display and operating components of the connected
hand-held terminal or machine control panel apply, refer to the respective
documentation of the connected device.
DOK-SUPPL*-VAC*XX.X***-IT01-EN-P
Non-functioning EMERGENCY STOP push‐
buttons can have fatal consequences!
