User Manual
Quick Installation Guide
Model # AWLH4030
Section 1
Install Utility Software
Note: Be sure to power off your computer before inserting the PCI adapter.
Step 1
Insert the PCI adapter into an available PCI slot and turn on your
computer.
Step 2
Windows will detect the adapter and request for a driver. Click Cancel to
quit the wizard. Insert the Driver & Utility CD into your CD drive and wait for the
autorun page to appear on screen.
Step 3
Click on Install Utility at the autorun page.
Note: If the autorun page doesn't appear automatically, go to Start, Run, and
type D:\autorun.exe (where D is the letter of your CD drive) and click OK.
Ver. 1A
Package Content:
•
PCI Wireless Adapter
•
Driver & Utility CD
•
Quick Installation Guide
Step 4
Click Next at the welcome screen.
Step 5
Click Next to accept the default destination folder to install the software or
click Browse to manually select a different destination folder.
Step 6
Click Next at the Select Program Folder screen.
Step 7
Click Continue Anyway at the Windows Logo Screen (if prompted).
Step 8
Verify "Yes, I want to restart my computer now" is selected and click
Finish to restart your computer.
Advertisement
Related Manuals for Airlink101 AWLH4030
Summary of Contents for Airlink101 AWLH4030
-
Page 1: Quick Installation Guide
Quick Installation Guide Model # AWLH4030 Section 1 Install Utility Software Note: Be sure to power off your computer before inserting the PCI adapter. Step 1 Insert the PCI adapter into an available PCI slot and turn on your computer. -
Page 2: Install Driver
Section 2 Install Driver Note: After restarting the computer, Windows will launch the Found New Hardware Wizard. The Found New Hardware Wizard will look different depending on your operating system. Follow the on-screen instructions to complete the installation. For Windows 98SE and ME users, you may be prompted to insert the Windows 98SE or ME CD during the driver installation. -
Page 3: Configure The Pci Adapter
Section 3 Section 3 Configure the PCI Adapter Note to Windows XP Users: You must disable the Wireless Zero Configuration Utility in order to use the WLAN Monitor. Please refer to the following steps to disable the Wireless Zero Configuration Utility. Step 1 Double-click on the Wireless Network Connection Icon in the system tray, then click on Properties or Advanced. -
Page 4: Technical Support
Step 5 Verify all the settings are correct and click OK. Step 6 Verify the SSID you have selected is in the Preferred WLANs box and click Apply. Section 4 Step 7 A blue circle will surround the SSID you have chosen. Click OK. Step 8 Restart your computer to complete the wireless network connection.
