TOTAL ACCESS 234 SHDSL NTU
Quick Start Guide
T
A
234 LED
OTAL
CCESS
S
LED
Color
Indication
PWR
Off
No power present.
Green (solid)
Power present.
SHDSL
Off
Unit is powered off.
Green (solid)
Port is trained with no active alarm conditions.
Yellow (solid)
Port is trained with minor active alarm
condition.
Red (solid)
Port is attempting to train or is trained with a
major alarm condition.
LLOOP
Off
No local loop is active.
Red (solid)
A local loop is active.
RLOOP
Off
No remote loop is active.
Red (solid)
A remote loop is active.
BERT
--
Not applicable with this product.
LNK
Off
No Ethernet link present.
Green (solid)
The 10BaseT Ethernet link is up.
Yellow (solid)
The 100BaseT Ethernet link is up.
TD
Off
No transmit activity on Ethernet port.
Green (blinking)
Transmit activity on Ethernet port.
RD
Off
No receive activity on Ethernet port.
Green (blinking)
Receive activity on Ethernet port.
Quick Start Guide, 61200708L1-13B, January 2005
10/100B
ASE
Pin
1
2
3
4,5
6
7,8
C
ONSOLE
Pin
1
2
3
4
5
6
7, 9
8
WAN-SHDSL N
Pin
1
2
3
4
5
6-8
Technical Support 1-888-4ADTRAN or +1-256-963-8716
For more detailed documentation, visit us online at
T E
P
P
THERNET
ORT
INOUT
Name
Description
TX1
Transmit Positive
TX2
Transmit Negative
RX1
Receive Positive
—
Unused
RX2
Receive Negative
—
Unused
P
P
ORT
INOUT
Name
Description
DCD
Data Carrier Detect (output)
RD
Receive Data (output)
TD
Transmit Data (input)
DTR
Data Terminal Ready (input)
SG
Signal Ground
DSR
Data Set Ready Tied to pin 1 (output)
—
Unused
CTS
Clear to Send Tied to pin 1 (output)
P
(RJ-45)
ETWORK
INOUT
Name
Description
Tip 2
4-wire Loop 2 Pair Tip
Ring 2
4-wire Loop 2 Pair Ring
—
Not connected
Tip 1
2-wire Pair Tip,
4-wire Loop 1 Pair Ring
Ring 1
2-wire Pair Ring,
4-wire Loop 1 Pair Ring
—
Unused
Copyright © 2005 ADTRAN, All Rights Reserved
www.adtran.com
P/N 1200708L1
