We recommend that you read this manual carefully so that you can fully take
advantage of the advanced and convenient functions of the Portable PA Speaker
and Microphone System. We also recommend that you keep this manual in a
safe and handy place for future reference.
CAUTION
WARNING! DON'T OPEN THE MACHINE TO AVOID ELECTRIC SHOCK, PLEASE ASK
HELP FROM PROFESSIONAL TECHNICIANS.
SAFETY INSTRUCTION
1. Read this manual carefully before using. Retain for future reference.
2. All warnings on the speaker and in the operating instructions should be adhered to.
3. Do not use this apparatus near water.
4. Do not block any of the ventilation openings. Install in accordance with the
manufacturers instructions. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including ampli ers) that produce heat.
Do not install the speaker in an airtight location.
5. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
6. Switch OFF and unplug then use a soft cloth to clean the exterior of the unit if it
becomes dirty. If necessary, use a damp cloth that has been wrung out well to
wipe it.
7. Unplug this apparatus during lightning storms or when unused for long periods of
time.
8. Keep foreign objects and liquid from entering the unit to avoid a short circuit, re
and electrical accidents.
9. Place the speaker in a dry location.
10. Refer all servicing to quali ed service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture , does not operate normally, or
has been dropped.
2
www.PyleUSA.com
Control & Layout
Front Panel & System
1. SD Card Input
2. Screen
3. EQ Selectors
4. Remote Control
Receiving Window
5. Input Selectors
6. Repeat Control
7. EQ Switch
8. Line-in (AUX) Input
9. Audio Output Jack
10. DC Input Jack
11. FM Antenna
12. Voltage Selector Swicth
13. Power Switch
14. USB Input
15. Play/Pause Control
16. Next Song/Volume Up
17. Previous Song/Volume Down
18. Full Voltage Indicator
19. Volume Control
20. Charge Indicator
21. Mic Input Jack
22. Mic Priority Switch
23. Mic Volume Control
24. Echo Control
25. Guitar Volume Control
26. Guitar Input Jack
27. AC Input Jack
SD/MMC CARD
USB
3
www.PyleUSA.com
