Garmin GMR FANTOM 18 Nstallation Instructions

Important Safety Information
Failure to follow these warnings, cautions, and notices could result in personal injury, damage to the vessel or
device, or poor product performance.
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
The radar transmits electromagnetic energy. To avoid possible personal injury, damage to the vessel or device,
or poor product performance, ensure that the radar is installed according to the recommendations in these
instructions and that all personnel are clear of the path of the radar beam before transmitting. When properly
installed and operated, the use of this radar conforms to the requirements of ANSI/IEEE C95.1-1992 Standard
for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields.
To avoid possible personal injury, do not look directly at the antenna at close range when the radar is
transmitting. Eyes are the most sensitive part of the body to electromagnetic energy.
When connecting the power cable, do not remove the in-line fuse holder. To prevent the possibility of injury or
product damage caused by fire or overheating, the appropriate fuse must be in place as indicated in the
product specifications. In addition, connecting the power cable without the appropriate fuse in place voids the
product warranty.
This device should be used only as a navigational aid. Using the device for any purpose requiring precise
measurement or direction, distance, location, or topography may result in personal injury or damage to the
vessel.
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
Opening the device may result in personal injury and/or damage to the device. This device contains no user-
serviceable parts, and should be opened only by a Garmin
from opening the unit by anyone other than a Garmin authorized service technician will not be covered by the
Garmin warranty.
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.
Software Update
You must update the Garmin chartplotter software when you install this device. For instructions on updating
the software, see your chartplotter owner's manual at support.garmin.com.
Tools Needed
• Drill
3
• 9.5 mm ( / in.) drill bit
8
1
• 32 mm (1 / in.) drill bit (optional)
4
13
• 4 mm ( / in.) hex wrench
32
1
• 13 mm ( / in.) wrench and torque wrench
2
• Marine sealant
April 2021
GMR FANTOM
™
INSTALLATION INSTRUCTIONS
18/24
™
WARNING
CAUTION
® authorized service technician. Any damage resulting
NOTICE
GUID-B8D36679-F674-4078-A6D7-4474077E7BC2 v3
